Leedarson ZW0301 Quick Start Manual

Door window sensor
Hide thumbs
1
2
3
4
5
6
7
8
9
Table of Contents

Advertisement

Quick Links

Download this manual

Door window sensor

Contents:
Door window sensor .......................................................................................................................................... 1
1. In the box ............................................................................................................................................. 2
2. Product introduction ............................................................................................................................ 2
3. Z-Wave specification ............................................................................................................................ 4
4. Product Installation .............................................................................................................................. 7
5. Safety Information ............................................................................................................................... 8
6. Maintenance ........................................................................................................................................ 8
7. FCC compliance notice ......................................................................................................................... 9
We build your success in IoT.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ZW0301 and is the answer not in the manual?

Questions and answers

Related Manuals for Leedarson ZW0301

Summary of Contents for Leedarson ZW0301

  • Page 1: Table Of Contents

    We build your success in IoT. Door window sensor Contents: Door window sensor ............................1 1. In the box ............................. 2 2. Product introduction ..........................2 3. Z-Wave specification ..........................4 4. Product Installation ..........................7 5. Safety Information ..........................8 6.

  • Page 2: In The Box

    Door/Window sensor 2. Product introduction The Leedarson door window sensor is designed for use with scenes in home automation and security systems, the door window sensor lets you know when door or windows is opened and can trigger different actions in response to that open action (or close action).
  • Page 3 Sensor Specification Detection Technology TMR Sensor Detection Range 20mm±5mm Communication Protocol Z-Wave mesh/ Z-Wave Long Range Z-Wave mesh: US/CA: 908.4, 908.42, 916 MHz Radio Frequency Z-Wave LR: US/CA: 912 and 920 MHz 1000’ in an open-air, interference free, line of Wireless Range sight environment.

  • Page 4: Z-Wave Specification

    0x07 (Notification sensor) Specific device type 0x01 (Specific type notification sensor) Role type 0x06 (reporting sleeping end device) Installer Icon Type 0x0C06 (Door/Window Alarm) Icon Type 0x0C06 (Door/Window Alarm) Product Type ID 0x0301 Product ID 0x0001 Manufacture ID 0x0300 (Leedarson MFID)
  • Page 5 0x5E - COMMAND_CLASS_ZWAVEPLUS_INFO, version 2 0x59 - COMMAND_CLASS_ASSOCIATION_GRP_INFO, version 3 0x85 - COMMAND_CLASS_ASSOCIATION, version 2 0x80 - COMMAND_CLASS_BATTERY, version 3 0x70 - COMMAND_CLASS_CONFIGURATION, version 4 0x5A - COMMAND_CLASS_DEVICE_RESET_LOCALLY, version 1 0x7A - COMMAND_CLASS_FIRMWARE_UPDATE_MD, version 5 0x87 - COMMAND_CLASS_INDICATOR, version 3 Z-Wave command classes 0x72 - COMMAND_CLASS_MANUFACTURER_SPECIFIC, version 2 0x8E - COMMAND_CLASS_MULTI_CHANNEL_ASSOCIATION, version 3...

  • Page 6: Configuration Parameters

    Association Group Name Notes 1) Supported Nodes: 5; 1 Lifeline 2) Profile: 0x0001; 3)Command Class:0x80035A0187037105; 1) Supported Nodes: 5; 2 Basic Set 2) Profile: 0x7107; 3)Command Class:0x2001; Configuration Parameters Name Notes 1) Format: Unsigned Interger; 2)Size: 1 Byte, Max 0xFF, Min 0x00, Default 0x00; 1 Sensor Status 3)Read only: Yes;...

  • Page 7: Product Installation

    4. Product Installation QR code and DSK i.The QR code are stocked to the side of the case, DSK is included in the QR code. ii.The DSK code can be found on the DSK label which is attached on the packaging box. PACKAGE DEVICE Installation steps:...

  • Page 8: Safety Information

    5. Safety Information Battery Safety Information: • This product contains a coin/button cell battery. If the coin/button cell battery is swallowed, it can cause severe internal burns in just 2 hours and can lead to death. Keep away from babies and small children at all times.

  • Page 9: Fcc Compliance Notice

    How to join a door/window sensor? After the sensor is reset to the factory setting, the device running to SmartStart mode to scan Z-Wave network, user can scan device QR code to add it to Z-Wave hub via APP. This product is just for indoor use only. Should be affixed indoors and away from sources of moisture. This product has low voltage detection reminder.
