Summary of Contents for Honeywell NOTIFIER INERTIA NI-2012
Page 1
A P P R O V A L S Australian Standard AS4428.5:1998 Amdt 1 New Zealand Standard NZS4512:2003 CSIRO Approval No. XF2236/R1 C-Tick Approval No. N1336 NOTIFIER INERTIA NI-2012 AND NI-2017 NPS Power Supply Series PERATORS ANUAL 01/07/2011 Rev: 1.04...
Amendments 1 & 2) as well as the EMI susceptibility requirements of Clause C3.5 in AS4428.0:1997. CAUTION: Radio communication devices should not be used in the vicinity of fire panels or associated ancillary devices and systems Copyright (c) 2011, Honeywell Ltd (Trading as Notifier Inertia)
System Design Installation And Commissioning. AS-1668.1 AUSTRALIAN STANDARD FOR SAA Mechanical Ventilation And Air Conditioning Fire Precautions In Buildings With Air-handling Systems. NZS-4512 NEW ZEALAND STANDARD FOR Fire Detection and Alarm Systems in Buildings. Copyright (c) 2011, Honeywell Ltd (Trading as Notifier Inertia)
CAUTION!! This ribbon is not to be used for power transfer and damage may occur to the board if the ribbon cable is connected to the panel while the power supply is on. Copyright (c) 2011, Honeywell Ltd (Trading as Notifier Inertia)
Page 7
D4 – Data bit 4/0 D5 – Data bit 5/1 D6 – Data bit 6/2 D7 – Data bit 7/3 CAUTION!! This ribbon is not to be connected to the NI-2012-02 Display board. Copyright (c) 2011, Honeywell Ltd (Trading as Notifier Inertia)
Should the output voltage of power supply fall below 20.6 Volts, both the output and batteries will be disconnected to prevent permanent damage to the batteries. Power is restored once mains power is restored, or good batteries are installed on the system. Copyright (c) 2011, Honeywell Ltd (Trading as Notifier Inertia)
In the manual mode a battery test is only performed while the battery test input is active. A battery fault is latched while this input remains active. An active input on the battery test inhibit input will prevent a battery test from being performed and terminate an active battery test. Copyright (c) 2011, Honeywell Ltd (Trading as Notifier Inertia)
Battery Test/Reset Relay Fault Display Board Switch Outputs (when fitted) Signal Ribbon to Status Indicators Heartbeat Indicator Power Connector to Panel Mode Setting Switch Power input from Power Battery Supply Terminal Copyright (c) 2011, Honeywell Ltd (Trading as Notifier Inertia)
Page 11
Fit Link at J6 NI-2012 Power Supply Interface (PSI) NI-2012 (PSI) Dipswitch Settings: Normal operation: All off NZ Operation: 1 on, all others off Manual mode: 2 on, all others off Copyright (c) 2011, Honeywell Ltd (Trading as Notifier Inertia)
Page 12
Page 10 NOTIFIER INERTIA NPS Series Manual Copyright (c) 2011, Honeywell Ltd (Trading as Notifier Inertia)
Page 13
NOTIFIER INERTIA NPS Series Manual Page 11 Copyright (c) 2011, Honeywell Ltd (Trading as Notifier Inertia)
Page 14
Page 12 NOTIFIER INERTIA NPS Series Manual Copyright (c) 2011, Honeywell Ltd (Trading as Notifier Inertia)
