Battery BacPac
™
User ManUal

Advertisement

loading
Need help?

Need help?

Do you have a question about the ABPAK-304 and is the answer not in the manual?

Questions and answers

Related Manuals for GoPro ABPAK-304

Summary of Contents for GoPro ABPAK-304

  • Page 1 Battery BacPac ™ User ManUal...
  • Page 2 GoPro adds new camera features through software updates. An update to the original HD HERO and the HD HERO2 is required for compatibility with the Battery BacPac. To download, visit gopro.com/update.
  • Page 3 Battery BacPac FeatUres 1. Attaches to your GoPro camera to double* battery capacity. 2. Plugs into any USB charging source (PC, wall, auto charger). 3. Displays the battery level and charge status in LCD window. 4. Displays the charge and record activity with LED light.
  • Page 4 Battery BacPac tO gOPrO caMera AttAcHing BAttERy BAcPAc The Battery BacPac can be attached to the original HD HERO, HD HERO2 and HERO3 cameras. 1. Slide hooked end of the Battery BacPac (A) into groove on the right side of camera body (B).
  • Page 5 REmOving BAttERy BAcPAc 1. Pull back on the left side of the Battery BacPac marked with arrow to disconnect from the HERO Port. 2. Slide hooked end of the Battery BacPac (A) out of the camera groove (B).
  • Page 6 DOOrs Attaching the Battery BacPac to your GoPro camera will require the use of a deeper backdoor when used with the housing. Two different backdoors are supplied with the Battery BacPac: one Standard (waterproof) and one Skeleton (non-waterproof). The Skeleton backdoor al- lows for improved audio capture and camera cooling.
  • Page 7 When connected and powered On, the Battery BacPac serves as an initial source of power. Once the Battery BacPac is depleted, your GoPro will switch over to draw from the battery inside the camera. The battery switch over happens automatically and does NOT interrupt recording.
  • Page 8 cHEcking BAttERy BAcPAc POWER LEvEL Press the Battery BacPac button (A) once and LCD (B) will illuminate to show power level. 100-70% 70-40% 40-10% <10%...

  • Page 9: Direct Charge

    charging DiREct cHARgE 1. Connect the Battery BacPac to a computer or a USB compatible charger via included USB cable. 2. While charging, the Battery BacPac will display an animated icon. 3. When completely charged, the Battery BacPac will display a full battery icon. PAss-tHROugH cHARging For the original HD HERO or the HD HERO2 cameras: A pass-through charge is NOT possible.

  • Page 10: Important Safety And Handling Information

    iMPOrtant saFety anD hanDling inFOrMatiOn WARning: Failure to follow these safety instructions could result in fire, electric shock or other injury or damage to the Battery BacPac or other property. Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries according to instructions.
  • Page 11 using cOnnEctORs AnD PORts Never force a connector into a port; check for obstructions on the port. If the connector and port do not join with reasonable ease there may be a mismatch. Be sure the connector matches the port and that connections line up.
  • Page 12 Learn about more GoPro products at: gopro.com 130-02319-000 reVa Please recycle...
