WatchPAT™ 300
Operation Manual
Itamar Medical REF OM2196381
Caution: Federal law restricts this device to sale by or on the order of a licensed healthcare
practitioner
Copyright © 2023-2024 Itamar Medical Ltd. WatchPAT and PAT are trademarks or registered trademarks of
Itamar Medical Ltd., a subsidiary of ZOLL Medical Corporation, in the United States and/or other countries.
