- Page 1 ASSEMBLY INSTRUCTIONS CARLSSON SLIDE DOOR DESK ITEM CODE: OTCAR120OB / OTCAR120WE 1 Carton This design and instruction booklet is subject to copyright www.officeworks.com.au For spare parts or hardware email hardware@kyvas.com.au 1/14...
-
Page 2: Tools Required
Important Estimated Assemble Time: 50min Assembly Video · To view an assembly video, go to https://www.officeworks.com.au/ · Search the product by item code or name: · Click on the icon to watch the video. Tools Required CAUTION: Do not use tools other than those required, as this can damage your new item. - Page 3 Part Overview 3/14...
-
Page 4: Part List
Part List Parts located in Carton - OTCAR120OB / OTCAR120WE 4/14... -
Page 5: Hardware List
Hardware List Hardware Pack located in Carton - OTCAR120OB / OTCAR120WE (M6*25mm) (M6*14mm) (M6*35mm) X 4pcs X 10pcs X 5pcs Allen Key (Φ6*44mm) X 1pc X 1pc X 10pcs (Φ8*30mm) (Φ7*50mm) (Φ15*12mm) X 12pcs X 10pcs X 10pcs Sticker Wrench X 10pcs X 1pc Other hardware located in Carton - OTCAR120OB / OTCAR120WE... - Page 6 Step 1 x 10pcs x 6pcs Step 2 Tighten cam locks once panel is in place. x 6pcs 6/14...
- Page 7 Step 3 Tighten cam locks once panel is in place. x 4pcs Step 4 x 10pcs 7/14...
- Page 8 Step 5 x 2sets Step 6 8/14...
- Page 9 Step 7 x 6pcs Step 8 *Note: Ensure sliding Panel (x2) is completely in grooves of top & bottom panel before fully tightening I screws. x 1pc x 10pcs 9/14...
- Page 10 Step 9 x 4pcs Step 10 *Note: Do not tighten the screws A fully until you have completed Step 14. x 2pcs x 1pc 10/14...
- Page 11 Step 11 *Note: Do not tighten the screws A fully until you have completed Step 14. x 2pcs x 1pc Step 12 x 10pcs x 1pc 11/14...
- Page 12 Step 13 *Note: Do not tighten the screws C fully until you have completed Step 14. x 5pcs x 1pc x 1pc *Note: Now fully tighten screws A and then screws C. Step 14 *Note: Before fully tighten all C screws,ensure both the part 4 are taut. x 1pc x 1pc 12/14...
-
Page 13: Care Advice
Maximum Load Capacity: Desk Top - 40 kg Storage - 10kg Your CARLSSON SLIDE DOOR DESK is now complete and ready for use! Care Advice · Keep away and protect from direct sunlight and heat. · Do not place sharp materials (knife, fork, etc) directly onto your furniture as sharp material may scrape and damage the finish. - Page 14 Warranty 3 years Product Warranty – valid for Australian customers only Officeworks Ltd warrants that this product will be free from defects and work as intended for 3 years from the date of purchase by the original customer. If the product has any defects or does not work as intended during the Warranty Period, Officeworks will, at its election and at its expense, repair or replace the product.
