- Page 1 V20241115 Ceiling Fan and Light Instruction Manual C F N - 4 2 W D - B F C F N - 4 2 W D - N F Make A House Home C F N - 4 2 W D - W F...
- Page 2 Always wear appropriate protective gear. Third-Party Products Vonluce shall not be liable for any damages or losses resulting from the use of third- party products in conjunction with Vonluce products. Customers shall refer to the third-party's guidelines or/and warranties (if any) for any third-party products used.
- Page 3 Preface Vonluce is a team of dedicated home enthusiasts with a mission to offer you high- quality products at affordable prices, all from the comfort of your own home. Our goal is to transform your house into a place you truly call home.
-
Page 4: Table Of Contents
Contents 1 Safety Information .................. 1 General Instructions ..................1 Electricity ......................1 Installation, Use, and Maintenance ..............2 2 Package List ................... 4 2.1 Parts Diagram ...................... 4 2.2 Tools Not Included but Helpful ................5 3 Preparation ..................... 6 4 Installation .................... -
Page 5: Safety Information
1 Safety Information 1.1 General Instructions • Read ALL these instructions carefully BEFORE installation and use. Keep ALL these instructions properly for future reference. • ONLY install and use this fan in accordance with ALL these instructions. • Provide ALL these instructions to anyone who will use or service this fan. •... -
Page 6: Installation, Use, And Maintenance
1 Safety Information • NEVER leave this device connected to power when performing ANY cleaning, lubrication, or wiring repair tasks. For tests or other purposes that require power to be restored, wear INSULATED hand protection and other necessary PPE ALL the way. To test the motor and blades, ALWAYS keep a safe distance while the blades ARE in motion. - Page 7 1 Safety Information • DO NOT place ANY body parts or foreign objects in the path of the blades. NEVER hold up your hands, children, pets, or other objects NEAR or UNDER this fan when it is operating. Exercise caution when working around or cleaning this fan. •...
-
Page 8: Package List
2 Package List 2.1 Parts Diagram Check that ALL parts ARE present and display NO defects UPON unpacking and BEFORE installation. If ANY part is missing or damaged, contact customer service and DO NOT attempt to install this product. Failure to do so can result in failures and accidents, leading to equipment damage and personal injury. M4 Flat Washers (×2) Locking Bolts (×7) M4 Spring Washers (×2) -
Page 9: Tools Not Included But Helpful
2 Package List 2.2 Tools Not Included but Helpful Flathead Screwdriver Phillips Screwdriver Power Screwdriver Adjustable Wrench Wiring Handbook AC Tester Light Pliers Wire Stripper Wire Cutter Electrical Tape Tape Measure Vernier Caliper Work Gloves Goggles Ladder... -
Page 10: Preparation
3 Preparation Turn off Your Power Begin installation by removing fuses or turning off circuit breakers to the wiring you will be using. Use your compatible UL listed junction box if you already have one installed. Failure to disconnect the power supply prior to installation may result in serious injury or death. -
Page 11: Installation
4 Installation • Read the Safety Information section BEFORE beginning your work. • Be sure to make proper preparations as described in Section 3. • Seek professional assistance from CERTIFIED electricians if necessary. Note: • Estimated Installation Time: 120 min. •... -
Page 12: Separating The Mounting Bracket And Canopy
4 Installation 4.1 Separating the Mounting Bracket and Canopy Parts Mounting Bracket & Canopy ×1 Steps Unscrew Bolts A. Loosen Bolts B. Rotate the canopy until the heads of Bolts B come out of the L-shaped slots. Disconnect the canopy from the mounting bracket. Mounting Bracket Canopy... -
Page 13: Installing The Mounting Bracket On A Junction Box
4 Installation 4.2 Installing the Mounting Bracket on a Junction Box Parts Mounting Bracket M4 Fasteners M5 Fasteners ×1 ×2 ×4 Steps Pass your building’s supply and ground wires through the central hole of the mounting bracket. Secure the mounting bracket to your junction box with appropriate fasteners. •... -
Page 14: Connecting The Canopy To The Fan Motor Assembly
4 Installation 4.3 Connecting the Canopy to the Fan Motor Assembly Parts Canopy Motor Assembly Locking Plate Locking Bolts ×1 ×1 ×1 ×6 Steps Pass the safety cable and electrical wires from the fan motor assembly through the canopy. Place the canopy on the top of the motor assembly, aligning their bolt holes. Cable &... - Page 15 4 Installation Use the locking plate and bolts to secure the canopy to the motor assembly as shown. Note: Tighten ALL these bolts COMPLETELY to prevent excessive noise and wobble. Locking Plate...
-
Page 16: Connecting The Electrical Wires
4 Installation 4.4 Connecting the Electrical Wires • Again, ensure that power has been cut BEFORE working with the wiring. • Use the wire nuts provided with your fan. • Secure each connection with electrical tape (not included). NEVER modify or remove ANY wire plugs. •... - Page 17 4 Installation Safety Cable Antenna Motor Assembly Black ("AC IN L") Green or Bare Copper (Ground) White ("AC IN L") Green (Ground) Black Gray White Yellow Gray Black White Yellow...
- Page 18 4 Installation Fit the receiver into the tray inside the canopy and at the top of the fan motor assembly. Ensure that the black antenna remains extended and NOT tangled with any electrical wires. Tuck all the connections neatly into the junction box. Antenna Canopy...
-
Page 19: Hanging The Fan Body
4 Installation 4.5 Hanging the Fan Body Parts Mounting Bracket Canopy ×1 ×1 Steps Push up the fan body, placing the canopy against the mounting bracket with Bolts B in the L-shaped slots. Rotate the fan body until Bolts B are locked into place. Fasten the canopy to the bracket using Bolts A removed in Section 4.1 on Page 8. -
Page 20: Installing The Fan Blades
4 Installation 4.6 Installing the Fan Blades Parts Blades Motor Assembly Blade Bolts ×3 ×1 ×6 Steps Fit a fan blade on the bottom of the fan motor assembly, aligning their bolt holes. Making sure the blade is straight, attach two blade bolts to secure it in place. Repeat these steps for the remaining blades. -
Page 21: Installing The Light
4 Installation 4.7 Installing the Light • NEVER modify or remove the wire plug. • NEVER connect the LED light kit to ANY other power sources or switches. Parts LED Light Kit Shade Motor Assembly ×1 ×1 ×1 Steps Remove the Phillips bolts from the bottom of the fan motor assembly. Feed the wire plug of the fan motor assembly through the middle of the LED light kit. -
Page 22: Test
4 Installation Position the light’s mounting plate against the motor, aligning their bolt holes. Secure the LED light kit into place using the bolts removed in Step 1. Fit the shade onto the LED light kit, rotating until it sits well on the tabs of the light plate. Ensure that the shade is firmly connected to avoid loosening and falling during use. -
Page 23: Remote Control
5 Remote Control 5.1 Introduction This remote operates within a range of 30 feet (10 m) using two 1.5 V AAA batteries (not included). If the remote is not to be used for a prolonged period, it is recommended to remove the batteries for better service life. If needed, install the remote holder on a wall or any other suitable flat surface using appropriate fasteners. -
Page 24: Color Temperature
5 Remote Control 5.3 Color Temperature The LED light has 3 color settings: Warm White (3000 K), Cool White (4500 K), and Daylight (6000 K). To adjust the light settings, Press on the remote to turn on the LED light. Within 10 seconds, press to turn off the light. -
Page 25: Troubleshooting
6 Troubleshooting Read the Safety Information section BEFOREHAND and follow ALL related instructions therein for EACH task. Problem Solutions Pair the remote with your fan. Reconnect the fan to power. Within 10 seconds, hold until you hear 3 consecutive beeps. Replace the remote’s batteries with new identical ones. -
Page 26: Disposal
6 Troubleshooting Problem Solutions Check that all fasteners are securely tightened. Use the provided balancing kit (a clip and two weights) to adjust the blades if their tips have an unequal distance from the ceiling while well fastened. Turn off the fan. Place the balancing clip on the trailing edge of Clip a blade. -
Page 27: Customer Support And Policies
Guaranteed Response Within 24 Hours We are dedicated to ensuring your satisfaction. At Vonluce, no inquiries are left unanswered for more than 24 hours. We treat each inquiry with the utmost seriousness, going above and beyond to provide a satisfactory response. - Page 28 Contact Us Thank you for choosing our products! If you have any questions or comments, contact us at contact@b2ccspro.com and we'll resolve your issue ASAP! For a .pdf copy of the latest version of these instructions, use the appropriate app on your smartphone to scan the QR code to the right.
