  • Page 1 C712 SYSTEM CONTROL CENTER...
  • Page 3 C712 SYSTEM CONTROL CENTER...
  • Page 4 1. Read all instructions - Read the safety and operating instructions before IMPORTANT operating the instrument. SAFETY 2. Retain Instructions - Retain the safety and operating instructions for future INSTRUCTIONS reference. 3. Heed warnings - Adhere to warnings and operating instructions. THESE 4.
  • Page 5: Important Safety Instructions

    17. CAUTION: TO PREVENT ELECTRICAL SHOCK DO NOT USE THIS IMPORTANT (POLARIZED) PLUG WITH AN EXTENSION CORD, RECEPTACLE OR OTHER SAFETY OUTLET UNLESS THE BLADES CAN BE FULLY INSERTED TO PREVENT INSTRUCTIONS BLADE EXPOSURE. ATTENTION: POUR PEVENIR LES CHOCS ELECRIQUES PAS UTILISER THESE CETTEFICHE POLARISEE AVEC UN PROLONGATEUR, UNE PRISE DE INSTRUCTIONS...
  • Page 6 The serial number and purchase date are important to you for possible insurance claim or future service. Record this information here. Serial Number Purchase Date INTRODUCTION TABLE OF HOW TO INSTALL THE C712 CONTENTS FRONT PANEL CONTROLS, SWITCHES AND PUSHBUTTONS 6, 7 REAR PANEL AND HOW TO MAKE CONNECTIONS 7 -10...
  • Page 7 A pair of Balanced Outputs is also included to take advantage of the greater noise reduc- tion capabilities of balanced cables. The C712 can be placed upright on a table or shelf, standing on its own plastic feet. It also can be installed in an optional Mclntosh L70 equipment cabinet. Follow the mounting INSTALL instructions enclosed with the L70 cabinet.
  • Page 8: Front Panel Controls, Switches And Pushbuttons

    The last page of this manual folds out to show photographs of the front and rear FRONT PANEL panels of the C712. This will help you in identifying and locating the controls and CONTROLS, switches on the C712 front panel, and the connectors on the rear panel. The letters SWITCHES and numbers on the photographs refer to the paragraphs that follow.
  • Page 9: The Rear Panel And How To Make Connections

    TAPE COPY switch. K. POWER Press the red POWER button to turn the C712 system ON. Press again to turn it OFF. The rear panel SWITCHED AC Outlet turns on with the POWER switch. Use good quality shielded cables to interconnect the associated equipment used with the THE REAR PANEL C712.
  • Page 10 6. TAPES 1 and 2 Connect a cable from the left channel output of a tape recorder to the C712 L (Left) channel TAPE 1 or 2 INPUT. Connect a cable from the right channel output to the corresponding R (Right) TAPE 1 or 2 INPUT.
  • Page 11 9. CD1 and CD2 Connect a cable from the left channel output of a CD player to the C712 L (Left) CD1 IN- PUT. Connect a cable from the right channel output to the C712 R (Right) CD1 INPUT. Con- nect a second CD player to the C712 CD2 inputs in a similar manner.
  • Page 12: Power Control

    The SUM DATA PORT can be used to connect to a Mclntosh RCT-2 Remote Control Translator. Any IR signal transmitted to a C712 IR sensor results in data signals at this port. The RCT-2 is a learning device that will allow the C712 to remotely control most major brands of accessory components.
  • Page 13: Next Track

    6. ACC OFF, ACC ON The ACC (Accessory) On or OFF pushbuttons function when the optional RCT-2 Remote Control Translator is being used with the C712. They can be programmed to turn the AC power of an accessory component on or off.
  • Page 14: Specifications

    HOW TO INSTALL BATTERIES IN THE C712 HAND HELD REMOTE CONTROLLER C712 HAND HELD Slide open the battery compartment. Insert two type AAA batteries into the REMOTE compartment, making sure to observe the battery polarities indicated in the battery CONTROLLER compartment.
  • Page 15 CUSTOM INSTALLATION DRAWING...
  • Page 17 The letters and numbers correspond to the paragraphs on pages 7, 8, 9, and 10.
  • Page 18 04050400 BE012003...
