Metal canopy bed queen
Hide thumbs

Advertisement

Available languages

Available languages

Table of Contents

Weight Limit: 600 Lb / 272 Kg
C.W. - 2022/10/20
2022 Dorel Home Products All Rights Reserved
Metal Canopy Bed
Thank you for purchasing from DHP!
Questions, concerns, missing parts?
CONTACT OUR CUSTOMER SERVICE DEPARTMENT
BEFORE RETURNING PRODUCT TO THE RETAILER.
If parts are missing or damaged, we will gladly ship your
replacement parts free of charge.
Visit www.dhpfurniture.com/eng/replacement-parts
or call Toll-Free 1-800-267-1739.
You can also chat with us at www.dhpfurniture.com
Date of Purchase
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY
INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
4608039(Black)
Queen
Lot Number (TAKEN FROM CARTON)
B34460803900-067846-C
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 4608039 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Dorel Home Products 4608039

Summary of Contents for Dorel Home Products 4608039

  • Page 1 You can also chat with us at www.dhpfurniture.com Date of Purchase Lot Number (TAKEN FROM CARTON) THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. C.W. - 2022/10/20 B34460803900-067846-C 2022 Dorel Home Products All Rights Reserved...

  • Page 2: Limited 1-Year Warranty

    Limited 1 year Warranty Read Before Beginning Assembly DHP warrants this product to be free from defects in material and workmanship Work in a spacious area and near where the unit will be used, preferably on a and agrees to remedy any such defect. This warranty covers one year from the carpet, or use a piece of the cardboard packaging to protect your floor and product.

  • Page 3: Parts List

    PARTS LIST...
  • Page 4 Upper Front/Rear Rail Headboard 1 PC 2 PCS 22 PCS 2 PCS 1 PC PART NUMBERS IMPORTANT: 4608039 PART (Black) LABELS Each part has a unique part number. Please T1024810 reference the appropriate part number when contacting customer service for replacement T1024820 parts.
  • Page 5 42 PCS 44 PCS 1 PC Slat Spacer Bracket 4 PCS 44 PCS PART NUMBERS IMPORTANT: 4608039 PART Each part has a unique part number. Please (Black) LABELS reference the appropriate part number when T1024900 contacting customer service for replacement parts.

  • Page 6: Hardware List

    Please do not completely tighten all the hardware, until the entire assembly is complete, unless otherwise indicated in the step-by-step instructions. 4608039(Black) HP # : T4608039-00 The screw(s), bolt(s) to be used at each step are shown in actual size in the lower right corner of the...
  • Page 7 Step 1 Insert I into A and attach it with Attach I to A with...
  • Page 8 Step 2 Insert B and attach it into I with Attach B to I with...
  • Page 9 Step 3 Attach T to C X 2 with Make sure that the holes on both C are located on the same side.
  • Page 10 Step 4 Attach H X 2 to G X 2 with When done, flip assembly over.
  • Page 11 Step 5 Wide side of the slot should Attach sub-assembly G from previous be facing up ! step to A, B and C with...
  • Page 12 Step 6 Attach L1 X 2 to X with...
  • Page 13 Step 7 Attach sub- assembly X & L1 from previous step to H X 2 with Hint: To easily secure the parts, hold with wrench while tightening with allen key...
  • Page 14 Step 8 Insert S X 4 into M X 2 with...
  • Page 15 Step 9 Insert K X 2 onto S X 4 with...
  • Page 16 Step 10 Insert sub-assembly M/K/S from previous step into the slots of A, B and C.
  • Page 17 Step 11 Attach U X 4 to A/B/C with...
  • Page 18 Step 12 Insert O1 into G as illustrated, then lock O1 into place with Y.
  • Page 19 Step 13 13.1 Press W onto O1 as illustrated. 13.2 Attach Q to W alternating left and right as illustrated. 13.1 13.2...

  • Page 20: Helpful Hints

    CAUTION: This unit is intended for use only with the products and/or maximum Helpful Hints weights indicated. Use with other products and/or products heavier than the maximum weights indicated may result in instability or cause possible injury. Move your new furniture carefully, with two people lifting and carrying the unit to its new location.
  • Page 21 Preguntas, inquietudes, partes que faltan? CONTACTE 4608039(Negro) NUESTRO DEPARTAMENTO DE SERVICIO AL CLIENTE ANTES DE DEVOLVER EL PRODUCTO A LA TIENDA. Si le faltan piezas o las que se incluyen est n da adas, con mucho Metal Canopy Bed gusto le enviaremos sus piezas de reemplazo sin cargo extra.
  • Page 22 Partes Paquete de componentes Piezas de reemplazo, visite www.dhpfurniture.com/spa/replacement-parts 4608039(Negro) # de Paquete : T4608039-00 IMPORTANTE La lista de n meros de piezas que aparece a continuaci n es exclusiva de su producto. Por favor, mant ngalo a mano cuando solicite piezas de repuesto.
  • Page 23 Paso 12 Instrucciones Inserte O1 dentro de G, a continuaci ó n, bloquee O1 en su lugar con Y como se muestra. Paso 1 I X 2 en Insertar Paso 13 13.1 Presione W sobre O1 como se ilustra. Una la parte T con A con 13.2 Una Q con W alternando izquierda y derecha.

  • Page 24: Informations Sur La Garantie

    Des questions, des pr occupations ou des pi ces 4608039(Noir) manquantes? CONTACTEZ NOTRE SERVICE LA CLIENT LE AVANT DE RETOURNER LE PRODUIT AU D TAILLANT. Si des pièces sont manquantes ou endommagées, nous Lit à baldaquin en métal expédierons volontiers vos pièces de rechange gratuitement.
  • Page 25 Quincaillerie Pour des pi ces de rechange, visitez www.dhpfurniture.com/fre/replacement-parts IMPORTANT: La liste des références ci-dessous est propre à votre produit. 4608039(Noir) # de Paquet : T4608039-00 Veuillez l'avoir sous la main lorsque vous appelez pour des pièces de rechange. Tout dans 1 grande(s) bo te(s)! Remarque: Sauf indication contraire dans les instructions, ne pas resserrer Avant de jeter les bo tes en carton, assurez-vous qu'elles soient vides.

  • Page 26: Conseils Utiles

    Instructions Étape 12 Ins é rer O1 en G, puis verrouiller O1 en place avec Y, tel qu'illustr é . Étape 1 Étape 13 Ins é rer I X 2 à A avec 13.1 Appuyez sur W sur O1 tel qu'illustr . é Attacher T à...
