- Page 1 ASSEMBLY INSTRUCTIONS COASTER FINE FURNITURE Fine Furniture for every stage of life 181370 SERVING CART REVISION 0 : 08/18/2022 PAGE 1 OF 9 COASTERFURNITURE.COM...
-
Page 2: Assembly Tips
181370 ITEM: ASSEMBLY INSTRUCTIONS ASSEMBLY TIPS: 1. Remove hardware from box and sort by size. 2. Please check to see that all hardware and parts are present prior to start of assembly. 3. Please follow attached instructions in the same sequence as numbered to assure fast & easy assembly. WARNING! 1. - Page 3 181370 ITEM: ITEM: ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS PARTS IDENTIFICATION PARTS IDENTIFICATION FRONT CROSSBAR BACK CROSSBAR BOTTOM CROSSBAR 2PCS MIDDLE CROSSBAR 2PCS TOP SUPPORT CROSSBAR BOTTOM SUPPORT CROSSBAR FRONT SUPPORT CROSSBAR PAGE 3 OF 7 PAGE 3 OF 9 COASTERFURNITURE.COM COASTERFURNITURE.COM...
-
Page 4: Hardware Identification
181370 ITEM: ASSEMBLY INSTRUCTIONS PARTS IDENTIFICATION BACK SUPPORT CROSSBAR GLASS HOLDER 3PCS WHEEL 4PCS HARDWARE IDENTIFICATION LONG BOLT 4PCS 6PCS (20 x 20 mm BLK) (1/4" x 25mm SR) SUCTION CUP ADHESIVE 16PCS 2PCS ∅ 10 x 2mm) (13 x 30mm) SMALL BOLT ALLEN WRENCH 17PCS... - Page 5 181370 ITEM: ASSEMBLY INSTRUCTIONS STEP 1 Do not tighten until each step is completed or instructed. STEP 2 PAGE 5 OF 9 COASTERFURNITURE.COM...
- Page 6 181370 ITEM: ASSEMBLY INSTRUCTIONS STEP 3 STEP 4 PAGE 6 OF 9 COASTERFURNITURE.COM...
- Page 7 181370 ITEM: ASSEMBLY INSTRUCTIONS STEP 5 STEP 6 PAGE 7 OF 9 COASTERFURNITURE.COM...
- Page 8 181370 ITEM: ASSEMBLY INSTRUCTIONS STEP 7 STEP 8 PAGE 8 OF 9 COASTERFURNITURE.COM...
- Page 9 181370 ITEM: ASSEMBLY INSTRUCTIONS Product Size : 826 X 330 X 1048 H (MM) Product Size : 32 " X 13" X 41 " Note : Dimension tolerance ±5% PAGE 9 OF 9 COASTERFURNITURE.COM...
