- Page 1 ASSEMBLY INSTRUCTIONS COASTER FINE FURNITURE Fine Furniture for every stage of life 181367 SERVING CART REVISION 0 : 08/01/2022 PAGE 1 OF 8 COASTERFURNITURE.COM...
-
Page 2: Assembly Tips
181367 ITEM: ASSEMBLY INSTRUCTIONS ASSEMBLY TIPS: 1. Remove hardware from box and sort by size. 2. Please check to see that all hardware and parts are present prior to start of assembly. 3. Please follow attached instructions in the same sequence as numbered to assure fast & easy assembly. - Page 3 181367 ITEM: ITEM: ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS PARTS IDENTIFICATION PARTS IDENTIFICATION FRAME BRACKET 8PCS WHEEL 2PCS WHEEL WITH LOCK 2PCS PAGE 3 OF 7 PAGE 3 OF 8 COASTERFURNITURE.COM COASTERFURNITURE.COM...
-
Page 4: Hardware Identification
181367 ITEM: ASSEMBLY INSTRUCTIONS HARDWARE IDENTIFICATION SHORT BOLT 8PCS (3/16" x 9mm SR) MEDIUM BOLT 8PCS (3/16" x 15mm SR) LONG BOLT 2PCS (3/16" x 32mm SR) SUCTION CUP 8PCS ∅ 19 x 9mm) ROUND CAP 2PCS ∅ 18mm SR) - Page 5 181367 ITEM: ASSEMBLY INSTRUCTIONS STEP 1 Do not tighten until each step is completed or instructed. STEP 2 PAGE 5 OF 8 COASTERFURNITURE.COM...
- Page 6 181367 ITEM: ASSEMBLY INSTRUCTIONS STEP 3 STEP 4 PAGE 6 OF 8 COASTERFURNITURE.COM...
- Page 7 181367 ITEM: ASSEMBLY INSTRUCTIONS STEP 5 STEP 6 COMPLETE PAGE 7 OF 8 COASTERFURNITURE.COM...
- Page 8 181367 ITEM: ASSEMBLY INSTRUCTIONS Product Size : 527 DIA X 787 H (MM) Product Size : 20.75" X 31" 20.75" Note : Dimension tolerance ±5% PAGE 8 OF 8 COASTERFURNITURE.COM...
