Washer
User manual
WF50A86**A*

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WF50A8600AE/US-00 and is the answer not in the manual?

Questions and answers

Related Manuals for Samsung WF50A8600AE/US-00

Summary of Contents for Samsung WF50A8600AE/US-00

  • Page 1 Washer User manual WF50A86**A*...

  • Page 2: Table Of Contents

    Contents Safety information What you need to know about the safety instructions Important safety symbols Important safety precautions CALIFORNIA PROPOSITION 65 WARNING Critical installation warnings Installation cautions Critical usage warnings Usage cautions Critical cleaning warnings Regulatory notice FCC Notice IC Notice Open Source Announcement Installation Unpacking your washer...
  • Page 3 Maintenance Self Clean+ Emergency drain Cleaning Recovery from freezing Care for an extended period of non-use Cleaning the exterior Cleaning the interior Troubleshooting Checkpoints Information codes Specifications Fabric care chart Protecting the environment Declaration of conformity Specification sheet English 3...

  • Page 4: Safety Information

    Safety information Congratulations on your new Samsung washer. This manual contains important information on the installation, use and care of your appliance. Please take some time to read this manual to take full advantage of your washer’s many benefits and features.

  • Page 5: Important Safety Precautions

    Important safety precautions WARNING To reduce the risk of fire, electric shock, or injury to persons when using your appliance, follow basic precautions, including the following: 1. Read all instructions before using the appliance. 2. Do not wash or dry articles that have been previously cleaned in, washed in, soaked in, or spotted with gasoline, dry-cleaning solvents, other flammable or explosive substances as they give off vapors that could ignite or explode.

  • Page 6: Critical Installation Warnings

    Safety information Critical installation warnings WARNING The installation of this appliance must be performed by a qualified technician or service company. • Failure to do so may result in electric shock, fire, an explosion, problems with the product, or injury. The appliance is heavy, therefore take care when lifting it.

  • Page 7: Installation Cautions

    Do not use an electric transformer to power the washer. • This may result in electric shock or fire. Do not use a damaged power plug, damaged power cord, or loose wall socket. • This may result in electric shock or fire. Do not pull or bend the power cord excessively.
  • Page 8 Safety information In the event of a gas leak (such as propane gas, LP gas, etc.), ventilate immediately without touching the power plug. Do not touch the appliance or power cord. • Do not use a ventilating fan. • A spark may result in an explosion or fire. Do not let children play in or on the washer.

  • Page 9: Usage Cautions

    • Failure to do so may result in electric shock or fire. If any foreign substance enters the appliance, unplug the power plug and contact your nearest Samsung Customer Service. • This may result in electric shock or fire.
  • Page 10 Using the product for business purposes qualifies as a product misuse. If the product is used for business purposes, it will not be covered by the standard warranty provided by Samsung and no responsibility can be attributed to Samsung for malfunctions or damages resulting from such misuse.
  • Page 11 • Do not use the liquid detergent container (on applicable models only) for powdered detergent. Remove the container and put powdered detergent directly into the Main wash compartment. Do not place any objects (such as shoes, food waste, animals) other than laundry into the washer. •...

  • Page 12: Critical Cleaning Warnings

    Safety information Take care that children’s fingers are not caught in the door when you close it. • Failure to do so may result in injury. Critical cleaning warnings WARNING Do not clean the appliance by spraying water directly onto it. Do not use a strong acidic cleaning agent.

  • Page 13: Regulatory Notice

    Regulatory notice FCC Notice CAUTION Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with Part 15 of FCC Rules. Operation is Subject to following two conditions: 1.

  • Page 14: Ic Notice

    Regulatory notice IC Notice The term “IC” before the radio certification number only signifies that Industry Canada technical specifications were met. Operation is subject to the following two conditions: 1. This device may not cause interference, and 2. This device must accept any interference, including interference that may cause undesired operation of the device.

  • Page 15: Open Source Announcement

    Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: The official Declaration of conformity may be found at http://www.samsung.com, go to Support > Search Product Support and enter the model name.

  • Page 16: Installation

    Unpack your washer and inspect it for shipping damage. Make sure you have received all the items shown on the next page. If your washer was damaged during shipping, or you do not have all of the items, call 1-800-SAMSUNG (1-800-726-7864). To prevent personal injury or strain, wear protective gloves whenever lifting or carrying the unit.

  • Page 17: What's Included

    What’s included Make sure all the parts are included in the product package. If you have a problem with the washer or the parts, contact a local Samsung customer centre or the retailer. 01 Release lever 02 Detergent drawer 03 Door...
  • Page 18 • Bolt caps: The number (3 to 6) of bolt caps provided depends on the model. • The appearance of the washer and provided accessories may differ with the model. • To purchase an accessory or lost part, contact a local Samsung service center or the retailer. CAUTION •...

  • Page 19: Installation Requirements

    Installation requirements Electrical supply and grounding • AC 120 V / 60 Hz / 15 AMP fuse or circuit breaker is required. • Use an individual branch circuit. Connect only the washer to the circuit. To ensure proper grounding, the washer comes with a power cord featuring a three-prong grounding plug for use in a properly installed and grounded outlet.

  • Page 20: Water Temperature

    Installation Drain Samsung recommends a standpipe 18 in. (460 mm) high. The drain hose must be connected through the hose clip to the standpipe, and the standpipe must fully cover the drain hose. Flooring For best performance, the washer must be installed on a solid floor. Wood floors may need to be reinforced to minimize vibration and/or unbalanced loads.

  • Page 21: Clearance Requirement

    Clearance requirement This clearance requirement is applicable for washers only. NOTE • For dryer’s clearance requirement, see the dryer’s user manual. • If the washer and dryer have different clearance requirements, use the one with the larger value. Alcove or closet installations Minimum clearance for stable operation: Sides Rear...
  • Page 22 78.5 in. (1994 mm) Side by side installation WARNING • Samsung’s washers and dryers can be stacked to maximize usable space. • The dryer feet need to be removed to stack the washer and dryer. You can purchase an optional stacking kit from your Samsung retailer.

  • Page 23: Step-By-Step Installation

    Step-by-step installation STEP 1 Select a location Location requirements: • A solid, level surface without carpeting or flooring that may obstruct ventilation • No direct sunlight • Adequate room for ventilation and wiring • Ambient temperature always higher than the freezing point (32 °F / 0 °C) •...

  • Page 24: Step 3 Adjust The Leveling Feet

    Kinked hoses may cause water leaks. • If there is a water leak, stop using the washer and contact a local Samsung service center. A water leak may cause electric shock. • Do not stretch the water hoses by force. If a hose is too short, replace the hose with a longer hose.
  • Page 25 1. Attach the water hoses to the hot and cold water taps, and then hand tighten the water hose fittings until they are tight. Then, use pliers to tighten the fittings by an additional two-thirds of a turn. To avoid damaging the fittings, do not overtighten them.
  • Page 26 Installation 5. Open the water taps, and check for leaks. STEP 5 Connect the drain hose To a Laundry Tub or Drain Pipe 1. Check the height (A) of your drain system and make sure the minimum and maximum heights shown below are met. Minimum 18 in.
  • Page 27 3. Route the drain hose to the drain system. CAUTION • If using a standpipe, make sure the standpipe and drain hose connection is not airtight. • If using a standpipe, make sure the drain hose is inserted at least 6 in. (152 mm) but no more than 8 in. (203 mm) into the standpipe.

  • Page 28: Before You Start

    Before you start Initial setup • When you turn on the washer for the first time, the screen shows the initial setup process. Follow the on-screen instructions to complete it. • Once you select a language, the language selection screen will not reappear. However, you must complete a wash cycle once to stop the tutorial screen from reappearing.

  • Page 29: Laundry Guidelines

    Laundry guidelines STEP 1 Sort Sort the laundry according to these criteria: • Care Label: Sort the laundry into cottons, mixed fibers, synthetics, silks, wools, and rayon. • Color: Separate whites from colors. • Size: Mixing different sized items together in the drum improves the washing performance. •...
  • Page 30 Before you start STEP 4 Determine the load capacity Do not overload the washer. Overloading may cause the washer to wash improperly. NOTE When washing bedding or bedding covers, the wash time may be lengthened or the spin efficiency may be reduced. For bedding or bedding covers, the recommended maximum spin level is Level 2 or Level 3, and the load capacity is 3.0 kg or less.

  • Page 31: Detergent Drawer Guidelines

    Detergent drawer guidelines The washer provides a three-compartment dispenser: the front-left compartment for the main wash, the front-right for fabric softeners, and the rear-right for the liquid chlorine bleach. A. Main-wash compartment: Add main-wash detergent, water softener, soaking detergent, color–safe, and/or stain removers. B.
  • Page 32 Before you start 3. Add fabric softener to the softener compartment. Do not exceed the max line (B). WARNING • Powdered fabric softener is not recommended. Use liquid fabric softener only. • Concentrated fabric softener must be diluted with water before being added. •...
  • Page 33 To use oxygen boosters or color-safe bleach Oxygen boosters or color-safe bleach can increase washing performance. Make sure to add the oxygen booster or color-safe bleach after putting the laundry into the drum. NOTE To use both powdered detergent and powdered oxygen booster or powdered color-safe bleach, it is more effective to put them together into the drum before loading the laundry.

  • Page 34: Operations

    Operations Multi-control panel Tap to turn the washer on or off. • After connecting the washer and the dryer with the multi-control cable, only the washer will turn on when you tap the button. Once the washer turns on, tap DRYER to turn on the dryer. •...
  • Page 35 Tap to confirm your selection of function or setting. 06 OK • The button is inactive when the selected function or setting is not supported. Tap the desired button to change the default dry cycle settings. • Dryness: Tap to change the dry level. You can select from levels 1 to 5, but the available level depends on the selected cycle.
  • Page 36 Operations Icon descriptions Wi-Fi • This icon indicates that the washer is connected to Wi-Fi. • This icon indicates the door is locked and cannot be opened. Door Lock • The door locks automatically during a cycle and this indicator turns on. •...

  • Page 37: Operating A Cycle

    Operating a cycle 1. Tap to turn the power on. 2. Tap DRYER or WASHER. Tap WASHER to select the washer and use its features. Tap DRYER to select the dryer and use its features. 3. Turn the Navigation dial to select the cycle you want. For more information on Cycle overview, see page 38.

  • Page 38: Cycle Overview

    Operations Cycle overview NOTE For more information on the dryer’s cycles, please see the dryer’s user manual. Cycle descriptions You can add or delete cycles to personalize the cycle list in the My Cycles option. See page 43 for more information.
  • Page 39 Cycle Description • For denim and jeans. • Wash inside out. Denim • Denim and jeans often contains excess dye and may run during the first few washes. Wash light and dark colored items separately. • Specific for machine-washable wool for loads less than 2.0 kg. •...

  • Page 40: Cycle Chart

    Operations Cycle chart Use this chart to set the best cycle and options for your laundry. Temp. Spin Soil level 1 : Tap Cold 1 : Extra Low 1 : Extra Light 2 : Cold 2 : Low 2 : Light 3 : Warm 3 : Medium 3: Normal...
  • Page 41 Functions Cycle Temp. Spin Soil level Rinse+Spin      Self clean+    Option Cycle Super speed Extra rinse Pre soak Normal   Heavy Duty    Super speed   Small load  Delicates ...

  • Page 42: Options

    Operations Options Using Options 1. Tap Options. 2. Turn the Navigation dial to select the desired additional function. 3. Tap OK to change the selected function’s settings or start the function. NOTE • To return to the main screen, tap Options again or turn the Navigation dial to select Back and tap OK. •...

  • Page 43: Child Lock

    My Cycles Add or remove cycles to create a personal cycle list. 1. Tap Options. 2. Turn the Navigation dial to select My Cycles, and then tap OK. You can only edit a cycle to create a personal cycle when the washer is not operating. 3.

  • Page 44: System Functions

    Operations System Functions Using System Functions 1. Tap and hold Options for 3 seconds. 2. Turn the Navigation dial and select the desired system function, and then tap OK. 3. Tap OK to change the selected function’s settings or start the function. NOTE To return to the main screen, tap Options again or turn the Navigation dial to select Back and tap OK.

  • Page 45: Self Diagnosis

    Calibration You can run calibration again for accurate weight detection. 1. Tap and hold Options for 3 seconds. 2. Turn the Navigation dial to select Calibration, and then tap OK. Calibration does not start if the door is not closed properly. The drum rotates clockwise and anticlockwise for about 3 minutes.

  • Page 46: Special Features

    Operations Special features Smart control You can connect to the SmartThings app and control your washer remotely. Connecting your washer 1. Download and open the SmartThings app on your smartphone or tablet (Android & iOS). 2. Tap to turn on the washer. 3.
  • Page 47 Stay Connect Set up the Stay Connect function in your SmartThings app to keep Smart Control turned on at the end of a cycle. Your washer stays connected to the app so you can send additional instructions, whether you are at home or away.

  • Page 48: Smartthings

    You don’t need a separate app to create your account. NOTE If you have a Samsung account, use the account to log in. A registered Samsung smartphone or tablet user automatically logs in. To register your appliance to SmartThings 1.

  • Page 49: Maintenance

    Maintenance Keep the washer clean to prevent deteriorated performance and to preserve its life cycle. WARNING Certain internal parts are intentionally not grounded and may present a risk of electric shock only during servicing. Service personnel – Do not contact the following parts while the appliance is energized: Control board, heat sink, motor, inlet valve and pump.

  • Page 50: Emergency Drain

    Maintenance Emergency drain In case of a power failure, drain the water inside the drum before taking out the laundry. 1. Power off and unplug the washer from the electrical outlet. 2. Gently press the top area of the filter cover to open. 3.

  • Page 51: Cleaning

    Cleaning Surface of the washer Use a soft cloth with a nonabrasive household detergent. Do not spray water onto the washer. Mesh filter Clean the mesh filter of the water hose once or twice a year. 1. Turn off the washer, and unplug the power cord. 2.
  • Page 52 Maintenance Debris filter It is advisable to clean the debris filter every 2 months to prevent its clogging. A clogged debris filter may reduce the bubble effect. 1. Turn off the washer, and unplug the power cord. 2. Drain the remaining water inside the drum. See the Emergency drain section.

  • Page 53: Detergent Drawer

    Detergent drawer 1. Open the drawer. 2. While holding down the release lever (A), remove the drawer. 3. Remove the liquid detergent container from the drawer. 4. Clean the drawer components in running water using a soft brush. NOTE Other parts of the drawer can also be removed. They can fall out if you hold the drawer upside down.
  • Page 54 Maintenance Door diaphragm 1. Open the door, and then empty the drum. 2. Combine 3/4 cups of liquid chlorine bleach and 1 gallon of warm tap water. 3. Wearing rubber gloves, use a soft, clean cloth dipped in the water and bleach solution to clean the diaphragm.

  • Page 55: Recovery From Freezing

    Recovery from freezing The washer may freeze when the temperature in its location drops below 32 °F (0 °C). 1. Turn off the washer, and then unplug the power cord. 2. Pour warm water over the water tap to loosen the water hose. 3.

  • Page 56: Cleaning The Exterior

    Maintenance Cleaning the exterior 1. Turn off the water taps after finishing the day’s washing. This will shut off the water supply to your washer and prevent the unlikely possibility of damage from escaping water. Leave the door open to allow the inside of your washer to dry out. 2.

  • Page 57: Troubleshooting

    Troubleshooting If there is any problem, check the information message on the LCD screen and follow the on-screen instructions. If the problem persists, please contact the service center. Checkpoints If you encounter a problem with the washer, first check the table below and try these suggestions. Problem Action •...
  • Page 58 Troubleshooting Problem Action • Make sure the washer is installed on a level, solid floor that is not slippery. If the floor is not level, use the levelling feet to adjust the height of the washer. • Make sure the shipping bolts are removed. •...
  • Page 59 Problem Action • Make sure you use the recommended types of detergent as appropriate. • Use high efficiency (HE) detergent to prevent oversudsing. Excessive suds. • Reduce the detergent amount for soft water, small loads, or lightly soiled loads. • Non-HE detergent is not recommended. Cannot add additional •...
  • Page 60 Troubleshooting Problem Action • Make sure the door is properly closed. • Make sure all hose connections are tight. • Make sure the end of the drain hose is correctly inserted and secured to the drain system. Leaks water. • Avoid overloading. •...

  • Page 61: Information Codes

    Information codes If the washer fails to operate, you may see an information code on the screen. Check the table below and try the suggestions. Code Action Water is not draining. • Make sure the drain hose is not frozen or clogged. •...
  • Page 62 The Main Door lock/unlock is not working properly. • Turn the machine off, and restart the cycle. • If the information code remains, contact a customer service centre. If any information code keeps appearing on the screen, contact a local Samsung service centre. English...

  • Page 63: Specifications

    Specifications Fabric care chart The following symbols provide garment care Normal direction. The clothing care labels include Permanent press/Wrinkle resistant/ symbols for drying, bleaching, drying and ironing, Wrinkle control or dry cleaning when necessary. The use of symbols ensures consistency among garment Gentle/Delicates manufacturers of domestic and imported items.

  • Page 64: Protecting The Environment

    Specifications Warning symbols for laundering Dry-clean Do not wash Dry-clean Do not wring Do not dry-clean Do not bleach Line dry/Hang to dry Do not tumble dry Drip dry No steam (added to iron) Dry flat Do not iron Protecting the environment •...

  • Page 65: Specification Sheet

    Specification sheet Front loading washer Type WF50A86**A* Water pressure (psi (kPa)) 20-116 (137-800) NET weight (lb (kg)) 216 (98.0) Spin revolution 1200 rpm Heating rating 900 W Washing 200 W Washing and 1150 W Power heating 120 V consumption Spin 550 W Drain 80 W...

  • Page 66: Limited Warranty (U.s.a.)

    Warranty service can only be performed by a SAMSUNG authorized service center. The original dated bill of sale must be presented upon request as proof of purchase to SAMSUNG or SAMSUNG’s authorized service center to receive warranty service.
  • Page 67 Visits by an authorized servicer to explain product functions, maintenance or installation are not covered by this limited warranty. Please contact SAMSUNG at the number below for assistance with any of these issues.

  • Page 68: Limitation Of Remedies

    LOSS OF REVENUE OR PROFITS, FAILURE TO REALIZE SAVINGS OR OTHER BENEFITS REGARDLESS OF THE LEGAL THEORY ON WHICH THE CLAIM IS BASED, AND EVEN IF SAMSUNG HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. Some states do not allow exclusion or limitation of incidental or consequential damages, so the above limitations or exclusions may not apply to you.
  • Page 69 Memo...
  • Page 70 Memo...
  • Page 71 Memo...
  • Page 72 Scan this with your smartphone QUESTIONS OR COMMENTS? COUNTRY CALL OR VISIT US ONLINE AT U.S.A 1-800-SAMSUNG (726-7864) www.samsung.com/us/support DC68-04067B-01...
