- Page 1 INSTRUCTION MANUAL #11950 BEAD SEAT BAND INSTALLER FOR 49” - 63” OTR TIRES AME INTERNATIONAL WWW.AMEINTL.NET...
-
Page 2: Safety Information
11950 INSTRUCTION MANUAL WARNING! To avoid serious personal injury, always wear proper protective gear, such as hard hats, safety glasses, gloves, and steel toe shoes when using hydraulic equipment. Failure to chock the wheels and crib the vehicle can result in serious injury or death. - Page 3 11950 INSTRUCTION MANUAL Assembly Instructions | BOX 1 Clamp Assembly 1. Remove all off the contents from the box. Refer to Parts Breakdown to identify all parts are present. Step 1 Step 1 Step 2 Step 2 Step 3 2. Take Manual Screw T-Handle (Part #8) and slide in through hole in the front of the Threaded Frame (Part #6B) 3.
- Page 4 11950 INSTRUCTION MANUAL Step 5 Step 5 5. Insert the Bead Plate Support (Part #6A) in between the front end of the Threaded Frame (Part #6b). Move around until it is at desired length. Be sure holes are lined up.
- Page 5 11950 INSTRUCTION MANUAL Step 8 Step 8 8. Put the Tire Bead Plate (Part #11) onto the Bead Plate Support (Part #6A) with the front face of the Tire Bead Plate (Part #11) at an angle. Line up the holes and place the Clevis Pins (Part #2) through the holes of the Tire Bead Plate (Part #11) 9.
- Page 6 11950 INSTRUCTION MANUAL Assembly Instructions | BOX 2 Push Assembly 1. Remove all off the contents from the box. Refer to Parts Breakdown to identify all parts are present. Step 1 2. Remove Rubber Cap covering threads on the Hydraulic Cylinder (Part #9).
- Page 7 11950 INSTRUCTION MANUAL 4. Remove the Smooth Saddle (Part #10) from it’s box and apply Loctite Blue 242 to the threads. 5. Insert the Smooth Saddle (Part #10) onto the top of the Hydraulic Cylinder and hand tight- en until snug.
- Page 8 11950 INSTRUCTION MANUAL CAUTION! BEFORE USING THIS TOOL, READ INSTRUCTIONS THOROUGHLY. THE USE OF THIS TOOL IN ANY OTHER APPLICATION IS BOTH A VOID OF WARRANTY AND CAN LEAD TO INJURY OR EVEN DEATH. The Bead Seat Band Installer should only be used by persons properly trained according to OSHA regulation #29CFR19010 “Servicing Single-Piece &...
- Page 9 11950 INSTRUCTION MANUAL 3. Adjust the bottom. Remove the pins. Then adjust bottom of the Bead Seat Band Installer to the bottom of the bead seat. (Figure 3) After, reinstall pins. (Figure 4) 4. Activate Bead Seat Band Installer to push bead seat band on tire bead.
- Page 10 11950 INSTRUCTION MANUAL 7. Rotate the Bead Seat Band Installer again from 3 o’clock to 6 o’clock (Figure 6) Then rotate the Bead Band Holder from 6 o’clock to 9 o’clock. 8. Rotate the Bead Seat Band Installer again from 6 o’clock to 9 o’clock (Figure 6) Then rotate the Bead Band Holder from 9 o’clock to 12 o’clock.
-
Page 11: Parts Breakdown
11950 INSTRUCTION MANUAL Parts Breakdown ITEM PRODUCT NO. DESCRIPTION 11950-001 BESSEY MORPAD 11950-002 CLEVIS PIN 11950-003 STRAP FOR BSB-ISNT 11950-004 HITCH PIN W/C 3/4” x 7” W/ LINCH PIN 13050 10” HYDRAULIC CYLINDER 11950-006 FRAME 11950-007 ADAPTER NUT FOR HAND SCREW...
