- Page 1 INSTRUCTION MANUAL #11020 “COMBI TIRE” BEAD BREAKER AME INTERNATIONAL WWW.AMEINTL.NET...
-
Page 2: Safety Information
Description The 11020 Bead Breaker is used on all types of rims except 5-piece earthmover rims. It is ideal for use with truck, farm tractor, grader, com-bine, and skidder tires. The 11020 can be used with a model (15000), (15020), (15004), or equivalent 10,000 psi [700 bar] pump. -
Page 3: Removing The Wheel
11020 INSTRUCTION MANUAL CAUTION! BEFORE USING THIS TOOL, READ INSTRUCTIONS THOROUGHLY. THE USE OF THIS TOOL IN ANY OTHER APPLICATION IS BOTH A VOID OF WARRANTY AND CAN LEAD TO INJURY OR EVEN DEATH. Operating Instructions REMOVING THE WHEEL 1. Chock the wheels opposite of the jack. - Page 4 11020 INSTRUCTION MANUAL POSITIONING THE BEAD BREAKER Positioning the bead breaker, so that the wedge-shaped teeth will grab evenly under the rim flange when clamping the jaw tightens. (See Fig. 2.) NOTE: Make sure the bead breaker is about 30°, or at least 12 inches [0,3 m], to the one side of the flange butt weld.
- Page 5 11020 INSTRUCTION MANUAL 5. Continue to apply hydraulic pressure until the bead breaking ram extends about 1/2 - 3/4 inch [13-19 mm] from the bead breaker. (See Fig. 7.) NOTE: Never try to break the tire bead with only one push.
- Page 6 11020 INSTRUCTION MANUAL CAUTION! BEFORE USING THIS TOOL, READ INSTRUCTIONS THOROUGHLY. THE USE OF THIS TOOL IN ANY OTHER APPLICATION IS BOTH A VOID OF WARRANTY AND CAN LEAD TO INJURY OR EVEN DEATH. 3. Clean and repaint rim parts as neccessary.
- Page 7 11020 INSTRUCTION MANUAL Finishing the Tire Inflation 1. Inflate the tire to 20 psi [1,38 bar]. 2. Check the tire bead for proper seating. 3. Continue inflating the tire to 40 psi [2,76 bar]. If the tire bead is not fully seated, see the Warning below.
-
Page 8: Parts Breakdown
11020 INSTRUCTION MANUAL Parts Breakdown AME INTERNATIONAL WWW.AMEINTL.NET... - Page 9 11020 INSTRUCTION MANUAL Parts Breakdown ITEM PRODUCT NO. DESCRIPTION 11010-001 SCREW, HEX HD. CAP (7/16-14 X 2); TORQUE TO 30/40 FT.LBS 11010-002 HANDLE, STRAP PIVOT 11010-003 PISTON, (SINGLE JAW) 11010-004 BODY, CYLINDER (SINGLE JAW); TORQUE TO 125/140 FT.LBS 11010-005 ROD WIPER...
