- Page 1 User Manual * Lens tubes sold separately Model ID: OVATIONE260WWIP...
-
Page 2: Edition Notes
Edition Notes The OVATION E-260WW IP User Manual includes a description, safety precautions, installation, programming, operation, and maintenance instructions for the OVATION E-260WW IP as of the release date of this edition. Trademarks Chauvet, Chauvet Professional, the Chauvet logo, and Ovation, are registered trademarks or trademarks of Chauvet &... -
Page 3: Table Of Contents
7 Ch / 4 Ch / 3 Ch / 2 Ch..................13 Standalone Configuration................Static Mode ......................13 Focus Mode ........................Auto Programs ....................14 Gobo Rotator (for use with Ovation GR-1 IP, sold separately) ......14 OVATION E-260WW IP User Manual Rev. 12... - Page 4 Gobo Power (for use with Ovation GR-1 IP, sold separately) ......14 Information ......................15 Factory Reset..................... 15 Error Codes....................5. Maintenance................Product Maintenance ..................6. Technical Specifications ............Contact Us ..................Warranty & Returns..................OVATION E-260WW IP User Manual Rev. 12...
-
Page 5: Before You Begin
The product has XLR sockets for DMX input and output. • Notice: This control circuit is isolated and belongs to the Class 2 data port. The control circuit has a cumulative leakage current of less than 3.5 mA. OVATION E-260WW IP User Manual Rev. 12... -
Page 6: Safety Notes
The minimum ambient temperature is -22°F (-30°C). Do not operate the product at lower temperatures. • To eliminate unnecessary wear and improve its lifespan, during periods of non-use completely disconnect the product from power via breaker or by unplugging it. OVATION E-260WW IP User Manual Rev. 12... -
Page 7: Fcc Statement Of Compliance
LEDs, contributing to shorter lifespans if always used at full intensity. The average LED lifespan is 40,000 to 50,000 hours. To extend LED lifespan, maintain proper ventilation around the product, and limit the overall intensity. OVATION E-260WW IP User Manual Rev. 12... -
Page 8: Introduction
Adjustable PWM (Pulse Width Modulation) to avoid flickering on camera Product Overview Name Name Safety loop Rotator power out Pattern holder slot Display Accessory slot Menu buttons Framing shutter (x4) Powerkon in/out Barrel rotation knobs 5-pin in/out OVATION E-260WW IP User Manual Rev. 12... -
Page 9: Product Dimensions
Introduction Product Dimensions 19.52 in 496 mm 20.7 in 527 mm 13.54 in 344 mm OVATION E-260WW IP User Manual Rev. 12... -
Page 10: Setup
Green/Yellow Green/Yellow Green Power Linking It is possible to power link OVATION E-260WW IP products. See the table below for the current draw at each voltage and frequency: 100 V, 60 Hz 120 V, 60 Hz 208 V, 60 Hz... -
Page 11: Remote Device Management
DMX cabling. Check the DMX controller’s User Manual or with the manufacturer as not all DMX controllers have this capability. The OVATION E-260WW IP supports RDM protocol that allows feedback to make changes to menu map options. -
Page 12: Mounting
Only loosen or tighten the bracket knobs manually. Using tools could damage the knobs. Procedure The OVATION E-260WW IP comes with a yoke. The user can directly attach a mounting clamp (sold separately) to this yoke. Make sure the clamp is capable of supporting the weight of this product. For the Chauvet Professional line of mounting clamps, go to http://www.trusst.com/products. -
Page 13: Manual Beam Focus Control
Accessory Slot The OVATION E-260WW IP has an accessory slot, which holds a drop-in iris, a motorized pattern device, or various other optional accessories (sold separately). Loosen the thumbscrews on the slot cover. (Note: Do not remove the thumbscrews). -
Page 14: Operation
Navigates downwards through the menu list or decreases the value when in a function Control Options Set the OVATION E-260WW IP starting address in the 001-512 DMX range. This enables control of up to 32 products in the 6Ch personality. -
Page 15: Menu Map
Shows total hours the LED has been powered on Information Version V_._ Shows installed software version _ _ _ _ _ _ _ _ _ _ _ _ Shows product ID Reset Factory Reset to factory defaults OVATION E-260WW IP User Manual Rev. 12... -
Page 16: Dmx Configuration
To set the starting address in DMX mode: 1. Go to the DMX Address main level. 2. Select the starting address (001–512). Personality Highest Address 2 Ch 3 Ch 4 Ch 7 Ch OVATION E-260WW IP User Manual Rev. 12... -
Page 17: Dmx Channel Assignments And Values
Select the desired value (0–255). Focus Mode Focus mode allows for focusing of the OVATION E-260WW IP without changing any menu settings. Press and hold <ENTER> for 3 seconds. The output intensity will increase to 100%. 2. Press <MODE> to exit focus mode and restore the settings... -
Page 18: Auto Programs
Go to the Gobo Rotator main level. Select the desired value (0–255). Master/Slave To set the OVATION E-260WW IP product to master or slave mode: 1. Go to the Master/Slave main level. 2. Select from Master (sends control signal) or Slave (receives control signal). -
Page 19: Information
Check the wire connection or has poor connection The thermistor is not welded properly Replace the board or weld the thermistor Temperature shows The temperature control connector Check the temperature control wire 125°C short circuited connector OVATION E-260WW IP User Manual Rev. 12... -
Page 20: Maintenance
6. Softly drag any dirt or grime to the outside of the transparent surface. 7. Gently polish the transparent surfaces until they are free of haze and lint. Always dry the transparent surfaces carefully after cleaning them. OVATION E-260WW IP User Manual Rev. 12... -
Page 21: Technical Specifications
DMX I/O Connector Channel Range 5-pin XLR 2, 3, 4 or 7 Ordering Product Name Item Name Item Code UPC Number OVATION E-260WW IP OVATIONE260WWIP 03121239 781462215873 UL 1573 CSA C22.2 No. 166 E113093 OVATION E-260WW IP User Manual Rev. 12... -
Page 22: Contact Us
For warranty terms and conditions and return information, please visit our website. For customers in the United States and Mexico: www.chauvetlighting.com/warranty-registration. For customers in the United Kingdom, Republic of Ireland, Belgium, the Netherlands, Luxembourg, France, and Germany: www.chauvetlighting.eu/warranty-registration. OVATION E-260WW IP User Manual Rev. 12...
