- Page 1 DOOR DETECTOR - LUX SERIES WITH POWER SUPPLY USER MANUAL Version UM.LUX.ENG.25B...
-
Page 2: Installation Instructions
INSTALLATION INSTRUCTIONS Securely fix the transmitter and receiver to the car/car doors through the fixing holes with the bolts provided, ensuring that the labels are pointing outwards. Ensure that both the receiver and the transmitter are at the same level. Fix the power supply (LX5) to the car top. -
Page 3: Notes On Handling
NOTES ON HANDLING · Keep the connection cables away from high voltage and/or high current wires. · Keep the connection cables away from the door motor and door drive. · Avoid direct sunlight or other infrared ingress to the receiver (RX). ·... -
Page 4: Power Supply
LED STRIP IN PROFILES A fuzzy algorithm is taken to calculate the position of the doors, which only functions in dynamic installation and adjusts distances and times based on the speed of the door operating system. The information below is for general guidance. -
Page 5: Packing List
POWER SUPPLY WIRING: NO COM STATUS BUZZER FUNCTION: Buzzer functions Buzzer on Buzzer off Buzzer delay Delay 20s Delay 30s Buzzer active Infinite Buzzer setting Intermittent Constant PACKING LIST Power supply 1 piece Receiver (RX) 1 piece Cables 2 cables User manual 1 copy Transmitter (TX)
