- Page 1 DOOR DETECTOR CDZ SERIES 03.G5.CDZ.174.FX6 USER MANUAL Version UM.G5.CDZ.174.FX6.E23 Manufactured under ISO 9001...
- Page 2 INSTALLATION INSTRUCTIONS Securely fix the transmitter and receiver to the car/car doors through the fixing holes with the bolts provided, ensuring that the labels are pointing outwards. Ensure that both the receiver and the transmitter are at the same level. Fix the power supply on the car top.
- Page 3 SAFETY INSTRUCTIONS · Keep connection cables away from high voltage and/or high current wires. · Keep connection cables away from door motor and door drive. · Avoid exposing the receiver (RX) lens to direct sunlight or other infrared sources. · Prior to power-on, clean the lenses with a soft, damp cloth. ·...
- Page 4 POWER SUPPLY SETTING AND WIRING Input voltage: 15-30VDC or 220VAC±15%, 50/60Hz Relay Buzzer NC NO COM STATUS AC/DC Select either AC or DC input AC in DC in Select buzzer ON or OFF Buzzer on Buzzer off Select relay output Select transistor NPN or PNP output Output model Relay output...
