- Page 2 This appliance may become a safety hazard if these instructions and safety precautions are ignored. In the event of an emergency: immediately remove plug from power socket. This product is intended for household and similar use only. The manufacturer accepts no responsibility and the guarantee will not apply in the event of any commercial use, inappropriate use or failure to comply with the instructions.
-
Page 3: Table Of Contents
Contents Introduction 1.1 Product overview ..............1 1.2 Indicator light description ............1 1.3 Indications ................2 Operating 2.1 First use or after a long period of non-use........ 3 2.2 Brewing..................4 Function Description 3.1 after a long period of non-use ..........5 3.2 Power saving mode.............. - Page 4 Machine abnormal alarm and warning function 4.1 Water shortage alarm............... 10 4.2 Descaling alarm................ 10 4.3 Recharge status indication............10 4.4 NTC abnormal alarm..............11 4.5 Blocking alarm................11 4.6 Overheating alarm..............11 4.7 Abnormal Capsule Storage Alarm..........11 4.8 Excessive use alarm..............12 4.9 Alarm for water pump working overtime........
-
Page 5: Introduction
1.Introduction Cup warmer Capsule mouth Capsule baffle button Front panel Indicator light Capsule box Water tank Drip tray grid Drip box External water pipe interface USB interface 232 interface Switch (optional) >> Indicator light description Power cord interface Warm-up function: 6 button lights flashing (flashing frequency is 1 time/second) Standby mode: The 6 button lights are always on, and the background light is half bright (the button light is off when any one of the capsule baffle, capsule box, and water tank are opened Power saving mode:the indicator light is all off, the backlight is half bright... -
Page 6: Indications
>> Indications Capsule system description: Automatic drop structure: N DISC. Note ： 1.This is a safety warning sign; 2.It is used to remind people of unexpected safety risks; 3.Standardize operations in accordance with safety information to avoid accidental injury. Tips: This sign is used to prompt the optimized operation of a certain function of the machine. -
Page 7: First Use Or After A Long Period Of Non-Use
2.Operating instructions 2.1 First use (or after a long period of non-use) Method 1 Pull out the water tank and open the water tank cover. Fill the water tank with clean drinking water . Method 2 Connect with the bottled water. And do not connect the water tap directly. -
Page 8: Brewing
2.2 Brewing When the baffle of the capsule box is removed, do not put your fingers into the brewing chamber! Push the baffle and insert Close it and place a cup. Press the corresponding drink a capsule. 6 volume buttons stay on. button, The buzzer "beep"... -
Page 9: Function Description
3. Function description 3.1 Stand by After the warm-up is completed, it enters the standby mode. The 6 button lights are always on and the background light is half on, so you can brew drinks at any time. 3.2 Power saving mode In standby mode, if there is no action for 28 minutes (the button is touched or the capsule box is the baffle is opened/closed, or the water tank is removed/in- serted, or the collecting tray is removed/inserted), the machine enters into... -
Page 10: Cup Volume Setting
3.4 Cup volume setting Enter the cup volume setting: Press the Americano, Ristretto, Espresso buttons at the same time for 3 seconds in the standby mode, after a "di", the 6 button lights flash (the gear motor drives the capsule holder to close at the same time), you can use any key to adjust the flow rate. -
Page 11: Restore Factory Settings
3.6 Descaling When the machine has brewed a total of 45L of coffee, the descaling indicator flashes at a frequency of 1 Hz to remind consumers of descaling. The descaling solution may be harmful. Avoid contact with eyes, skin and surfaces. According to the hardness of the water, the following table will indicate the descaling frequency needed to make your machine reach the best condition. -
Page 12: Descaling Function
Water hardness: Recommended cleaning cycle: CaCO3 (40ml) >38 >21 380 mg/l H(High) >25 >14 250 mg/l 1200 >13 >7 180 mg/l 1800 French grade M(Medium) >7 >4 70 mg/l 2800 German grade L(Low) <5 <3 50 mg/l 3500 CaCO 3Calcium carbonate 3.7 Water hardness selection Enter into water hardness selection: In the power saving mode, long press the Ristretto, Espresso, Hot Water buttons... -
Page 13: Water Hardness Selection
» The factory setting is highest hardness level. Americano+, Espresso buttons flash together 5 times/5s (2hz/s). It's 600 brewings which needs to descale. » When hardness level reduces one, The Americano+, Espresso buttons flash together 4 times/5s (2hz/s). It's 1200 brewings which needs to descale. »... -
Page 14: Machine Abnormal Alarm And Warning Function
4.Machine abnormal alarm and warning function 4.1 Water shortage alarm When lack of water or water tank removed, the indicator light flashes. While the lack of water is displayed during the normal operation, this brewing could be finished. >>The flashing frequency is 2 times/second Then you need to fill up the water tank. -
Page 15: Ntc Abnormal Alarm
4.4 NTC abnormal alarm When the machine detects NTC abnormality, the product will automatically shut down the boiler and water pump and cannot work. All button indicators flash at the same time and continue to flash; the background light is off, the buzzer will beep 10 times and then stop beeping. At this time, the machine is malfunctioning and needs to be turned off and repaired before it can be used. -
Page 16: Excessive Use Alarm
4.8 Overuse alarm After the machine is working and continuously brewing 1.5L of water, the machine program will automatically use it to trigger a protective alarm. Americano A mericano+the indicator light flashes simultaneously at 、 2Hz/sec, and the buzzer "didi" Ring (2 times/sec) 10 times to stop. >>The flashing frequency is 2 times/second. -
Page 17: Random List
5.2 Random list Coffee machine body Drip tray Large water tank Manual Warranty card External water pipe Power cable 5.3 Technical parameters Please select the correct voltage on the label on the bottom of the appliance and use the corresponding power supply. 220-240V~ 50-60Hz 1400-1600W 127V~ 60Hz 1600W 100V~ 50-60Hz 1450W... -
Page 18: Troubleshooting
5.4 Troubleshooting Keys do not ·plug off and plug on again function ·call service center ·check if there is foreign matter or capsule stuck in chamber. Handle can not be ·check if the capsule is as designated. fully pressed down ·call service center.
