- Page 1 O W N E R S M A N U A L P o w e r A m p l i f i e r s...
-
Page 2: Equipment Installation
EC Declaration of Conformity to Appropriate Standards Normally your Naim equipment will have been installed by the dealer who sold it to you even if you live outside their immediate vicinity. Your dealer is responsible for making sure that the system sounds exactly as it should and information given here is not intended to reduce this responsibility in any way. -
Page 3: Getting Started
Legal consumer protection varies from country to country. In most territories a dealer must be prepared to take back any Naim equipment he has sold you if he cannot make it work to your satisfaction in your own home. A problem may be due to a fault in any part of the system or its installation so it is essential to make full use of your local dealer’s... - Page 4 If there is a known problem in your locality it is advisable to arrange for a home demonstration before purchase to find out if Naim equipment is likely to be affected. Susceptibility to radio frequency interference is related to the wide internal bandwidth necessary for high sound quality.
- Page 5 4.3 fuse carrier Should the plug fuse carrier be damaged or lost, the correct replacement must be obtained from your dealer or from Naim direct. Do not use the plug until the fuse carrier is replaced. 4.4 plug fuses Replace only with ASTA or BS 1362 approved fuses.
- Page 6 For the best results Naim Audio’s own speaker cable should be used to connect a loudspeaker to the output of the power amplifiers. Special Naim Audio loudspeaker connectors are supplied to make the connection to the power amplifier(s).
-
Page 7: Specifications
nap 500 rear, connection to na ps500 right to preamp power to preamp power left loudspeaker ch2 supply. right, ch2 supply. left, ch1 loudspeaker ch1 na ps500 rear mains input Socket 1 Socket 2 Specifications nap 500 Standby power consumption (quiescent) 60VA Working power consumption signal dependent... - Page 8 To reset, turn the amplifier off for two minutes. loudspeaker cable For the best results Naim Audio’s own speaker cable should be used to connect a loudspeaker to the output of the power amplifiers. Special Naim Audio loudspeaker connectors are supplied to make the connection to the power amplifier(s).
- Page 9 nap 135 rear, channel one - left left mains input to power supply loudspeaker ch1 Socket 1 nap 135 rear, channel two - right right mains input to power supply loudspeaker ch2 Socket 2 Specifications nap 135 Power output Continuous, 8 ohms 75 watts Transient 500VA...
- Page 10 For the best results Naim Audio’s own speaker cable should be used to connect a loudspeaker to the output of the power amplifiers. Special Naim Audio loudspeaker connectors are supplied to make the connection to the power amplifier(s). IT IS ESSENTIAL THAT THESE ARE USED, IN ORDER TO COMPLY WITH CURRENT SAFETY REGULATIONS.
- Page 11 nap 250 rear left loudspeaker ch1 to power supply right mains input loudspeaker ch2 nap 250 Specifications nap 250 Power output Continuous, 8 ohms 70 watts per channel Transient 400VA Voltage gain +29dB Input impedance 18 kilohms Frequency response -3dB @ 3Hz & 50kHz Mains supply 100V.
- Page 12 nap 150 rear left loudspeaker ch1 to preamplifier or power supply power mains input right loudspeaker ch2 nap 150 Specifications ch 2 nap 150 Power output Continuous, 8 ohms 50 watts per channel Transient 250VA Voltage gain +29dB Input impedance 18 kilohms Frequency response -3dB @ 3Hz &...
- Page 13 IEC 801-3 3V/m 20dB (performance criterion A) IEC 801-4 1KV (AC lines) 0.5KV (signal lines) (performance criterion B) OWNPA issue 2 May 2001 • • Naim Audio Southampton Road Salisbury England SP1 2LN Tel: +44 (0)1722 332266 www.naim-audio.com 1 2 1 2...
