TEM MODUL TM11 Series Instruction Manual

MODUL switch instruction manual
1M button 2M button
(TM11xx) (TM12xx)
Neon lamp,
Bathroom set 3x20A
LED lamp
(IAxx) (CM25)
User instructions
Before installation, read the instructions carefully and check that the product is not damaged. This avoids the
possibility of a fault that could cause personal injury or damage to the electrical wiring. The instructions are
intended for all users; show this document to a qualified person before installing the switches.
Safety instructions
Please read the instructions carefully and follow the safety instructions. In the event of not observing the
safety and operating instructions, we do not accept any liability for damage to products and persons. Due to
the risk of electric shock, only qualified personnel may carry out the installation!
Keep the product out of the reach of children or unauthorised persons. Do not disassemble the product as
this will void the warranty. If not properly installed, the product may be permanently damaged. The product
is intended for indoor use and in covered outdoor areas in the temperature range between -20°C and +45°C.
It should not be exposed to moisture, rain, or water.
1M button indicator 2M button indicator
(TM11xxIN) (TM12xxIN)
Set switches IP44 2M Mounting frame
(CM22)
Switch
(SMxx)
Cover plate
(OLxx, OSxx, OPxx,
(NMxx)
OGxxxxM)
Two-way with
cord
(SM62)
