- Page 1 VMIVME-1129 128-bit Digital Input Board with Built-In-Test Product Manual 12090 South Memorial Parkway Huntsville, Alabama 35803-3308, USA (256) 880-0444 (800) 322-3616 Fax: (256) 882-0859 500-001129-000 Rev. D...
- Page 2 12090 South Memorial Parkway Huntsville, Alabama 35803-3308, USA (256) 880-0444 (800) 322-3616 Fax: (256) 882-0859...
- Page 3 VMIC reserves the right to make any changes, without notice, to this or any of VMIC’s products to improve reliability, performance, function, or design. VMIC does not assume any liability arising out of the application or use of any product or circuit described herein; nor does VMIC convey any license under its patent rights or the rights of others.
- Page 4 12090 South Memorial Parkway Huntsville, Alabama 35803-3308, USA (256) 880-0444 (800) 322-3616 Fax: (256) 882-0859...
-
Page 5: Table Of Contents
Table of Contents List of Figures ..............7 List of Tables . - Page 6 VMIVME-1129 128-bit Digital Input Board with Built-In-Test Address Selection Jumpers............31 Before Applying Power: Checklist .
-
Page 7: List Of Figures
List of Figures Figure 1-1 VMIVME-1129 Block Diagram ..........................17 Figure 1-2 VMIVME-1129 Test and Input Data Registers ....................18 Figure 1-3 Basic Input Circuit Topology............................ 19 Figure 2-1 Physical Location of Jumpers ..........................24 Figure 2-2 Basic Current Sinking Input ............................. 25 Figure 2-3 Basic Voltage Sourcing Input .......................... - Page 8 VMIVME-1129 128-bit Digital Input Board with Built-In-Test...
-
Page 9: List Of Tables
List of Tables Table 2-1 Threshold Voltages ............... . . 23 Table 2-2 Header Assignments . - Page 10 VMIVME-1129 128-bit Digital Input Board with Built-In-Test...
-
Page 11: Overview
Overview Introduction Features The VMIVME-1129 Digital Input Board is designed to read a voltage from a variety of devices. The signals may originate from electronic switching circuits, standard logic circuits, mechanical switch contacts, relay contacts, Opto 22 type signal conditioning modules, or numerous other sources. -
Page 12: Functional Description
VMIVME-1129 128-bit Digital Input Board with Built-In-Test Functional Description The VMIVME-1129 Board has input circuitry that permits the user to select and configure the basic input functions. The input functions and threshold levels are built into the circuitry. The configuration of the board by the user sets up these functions. -
Page 13: Reference Material
7825 East Gelding Dr., No. 104 Scottsdale, AZ 85260 (480) 951-8866 FAX: (480) 951-0720 www.vita.com The following Application and Configuration Guides are available from VMIC to assist the user in the selection, specification, and implementation of systems based on VMIC's products. Title Document No. -
Page 14: Safety Summary
Because of the danger of introducing additional hazards, do not install substitute parts or perform any unauthorized modification to the product. Return the product to VMIC for service and repair to ensure that safety features are maintained. Dangerous Procedure Warnings Warnings, such as the example below, precede only potentially dangerous procedures throughout this manual. -
Page 15: Safety Symbols Used In This Manual
Overview Safety Symbols Used in This Manual Indicates dangerous voltage (terminals fed from the interior by voltage exceeding 1000 V are so marked). Protective conductor terminal. For protection against electrical shock in case of a fault. Used with field wiring terminals to indicate the terminal which must be connected to ground before operating equipment. - Page 16 VMIVME-1129 128-bit Digital Input Board with Built-In-Test...
-
Page 17: Chapter 1 - Theory Of Operation
The written data will overwrite the external input level. The VMIVME-1129 has input noise filters for the external inputs. Figure 1-1 below is a block diagram of the basic functions of the VMIVME-1129 Board stated above. These blocks will be discussed in more detail in the following sections. -
Page 18: Test Registers
If the data written is different from the data read, there is a problem. Figure 1-2 below is a block diagram of the Test and Input Data Registers of the VMIVME-1129 Board. Test... -
Page 19: Input Circuitry
Input Circuitry Input Circuitry Figure 1-3 below shows the basic topology for each input. The BIT (Built-in-Test) Register is shown with only one of its eight lines (each register controls eight input circuits). The comparator output goes to an Input Data Register (IDR). When the board is selected, these registers are clocked. -
Page 20: Input Types
VMIVME-1129 128-bit Digital Input Board with Built-In-Test Input Types The VMIVME-1129-000 inputs can be configured in one of two types, either as voltage sourcing or current sinking. In the voltage sourcing input setup, R1's jumper is grounded. The input must be a voltage across R1. RP4 has its jumper going to a voltage the user chooses. -
Page 21: Chapter 2 - Configuration And Installation
CHAPTER Configuration and Installation Contents Unpacking Procedures ........... 22 Board Configuration . -
Page 22: Unpacking Procedures
All claims arising from shipping damage should be filed with the carrier and a complete report sent to VMIC, together with a request for advice concerning the disposition of the damaged item(s). -
Page 23: Board Configuration
Board Configuration Board Configuration The VMIVME-1129 circuitry permits the user to configure the inputs based on the application. The following sections of the manual are intended to instruct the user in the implementation of these input configurations. The user must first decide which input topology to use: the inputs can receive either current sinking;... -
Page 24: Figure 2-1 Physical Location Of Jumpers
VMIVME-1129 128-bit Digital Input Board with Built-In-Test Backplane Connectors (P1 and P2) end of Board BOTH Figure 2-1 Physical Location of Jumpers... -
Page 25: Figure 2-2 Basic Current Sinking Input
Board Configuration Input Bias Header High +1.25 V C1xx VEXT Px +5 V Filter Register +5 V +1.25 V Module User Input CHxx 24 K 15 k 3.3 k C0xx 0.47 uF 15 k LM339 33 k 33 k VEXT Px +5 V +1.25 V Input Bias Header Low... - Page 26 VMIVME-1129 128-bit Digital Input Board with Built-In-Test Table 2-2 Header Assignments Header Location of Associated Channels Ref. Des. VEXT CH07 - CH00 P2-C32 CH15 - CH08 P2-C30 CH23 - CH16 P2-C28 CH31 - CH24 P2-C26 CH64 - CH71 P2-C16 CH72 - CH79...
-
Page 27: Figure 2-4 Input Circuitry Jumper Configurations
Board Configuration INPUT BIAS HIGH JUMPER LOCATION T = CS T = CS T = CS T = VS = +5 V = +1.25 V = Eq 2 = +3.35 V = +1.25 V V = Eq 1 = Eq 1 = Eq 1 = Eq 1 INPUT... -
Page 28: Address Modifiers
VMIVME-1129 128-bit Digital Input Board with Built-In-Test Address Modifiers The VMIVME-1129 is configured at the factory, as shown in Figure 2-5, to respond to short supervisory I/O access. This configuration can be changed by installing jumpers at the appropriate locations in header E17 as shown in the corresponding figures. -
Page 29: Figure 2-7 Jumper Configuration For Short Nonprivileged Access
Address Modifiers BOTH Figure 2-7 Jumper Configuration for Short Nonprivileged Access BOTH Figure 2-8 Jumper Configuration for Standard Nonprivileged Access BOTH Figure 2-9 Jumper Configuration for Short Addressing and Supervisory or Nonprivileged Access BOTH Figure 2-10 Jumper Configuration for Standard Addressing and Supervisory or Nonprivileged Access... -
Page 30: Figure 2-11 Base Address Select Jumpers
VMIVME-1129 128-bit Digital Input Board with Built-In-Test NOTE: The example shown is for a short I/O base address of FF00 Hexadecimal (FFFFFF00 for Standard I/O access. Figure 2-11 Base Address Select Jumpers... -
Page 31: Address Selection Jumpers
The VMIVME-1129 is designed with a bank of address select jumpers that specify the beginning board address for data transfers. The address selection jumpers are shown in Figure 2-11 on page 30. The VMIVME-1129 is factory configured to respond to FF00 HEX. -
Page 32: I/O Cable And Front Panel Connector Configuration
VMIVME-1129 128-bit Digital Input Board with Built-In-Test I/O Cable and Front Panel Connector Configuration The input connectors (P3 and P4) on the VMIVME-1129 are 96-pin DIN standard and were selected by VMIC because of their high quality. Although these connectors are generally used with flat-ribbon cables, a variety of cables and mating connectors are available for most user requirements. - Page 33 I/O Cable and Front Panel Connector Configuration Table 2-3 P3 Pin - Channel Assignments ROW C Pin CHANNEL No. ROW C Pin CHANNEL No. All Pins in Row B are grounded. NOTE: ROW A Pin CHANNEL No. ROW A Pin CHANNEL No.
- Page 34 VMIVME-1129 128-bit Digital Input Board with Built-In-Test Table 2-4 P4 Pin - Channel Assignments ROW C Pin CHANNEL No. ROW C Pin CHANNEL No. All Pins in Row B are grounded. NOTE: ROW A Pin CHANNEL No. ROW A Pin CHANNEL No.
-
Page 35: Figure 2-13 P2 Connector Pin Layout
I/O Cable and Front Panel Connector Configuration P2 Connector C B A Pin No. C B A ISOMETRIC VIEW Rear View of Board Figure 2-13 P2 Connector Pin Layout... - Page 36 VMIVME-1129 128-bit Digital Input Board with Built-In-Test Table 2-5 P2 Connector Pin Assignments ROW A ROW B ROW C +5 V VEXT CH 120_127 VEXT CH 112_119 VEXT CH 104_111 VEXT CH 96_103 VEXT CH 88_95 VEXT CH 80_87 +5 V...
-
Page 37: Chapter 3 - Programming
Programming IntroductionI The VMIVME-1129 is a snapshot board. The user simply performs a read or write operation within the board's address space and the appropriate transfer is performed. The only setup involved with this board deals with the Control and Status Register. - Page 38 VMIVME-1129 128-bit Digital Input Board with Built-In-Test Table 3-1 Address Map (Continued) RELATIVE ADDRESS* MNEMONIC NAME/FUNCTION XXX1 1100 DR6U TEST REGISTER 6 UPPER BYTE XXX1 1101 DR6L TEST REGISTER 6 LOWER BYTE XXX1 1110 DR7U TEST REGISTER 7 UPPER BYTE...
-
Page 39: Board Id Register (Bd Id)
Board ID Register (BD ID) Board ID Register (BD ID) The BD ID Register is a read-only register. Its data is fixed at $2900. You can write to this address; however, the data you write will be lost and there will be no effect on the board. -
Page 40: Control And Status Register Bit Definitions
VMIVME-1129 128-bit Digital Input Board with Built-In-Test Control and Status Register Bit Definitions The Control and Status Register (CSR) is a 16-bit register that is used to control the board's Fail LED and the test registers' outputs. Table 3-3 shows the bits used to perform these functions. -
Page 41: Input Registers Bit Definitions
Input Registers Bit Definitions Input Registers Bit Definitions The following table (Table 4.4-1) lists the input channels and their associated register bit locations. The internal data bit can be used as a guide to locate an input channel when you are doing a longword transfer. When doing word or byte transfers the even address bytes will go to bits 15 through 8 on the VMEbus data bus while the odd address bytes go to bits 7 through 0. - Page 42 VMIVME-1129 128-bit Digital Input Board with Built-In-Test Table 3-4 Input Data Registers Bit Map (Continued) XXX1 1000 DATA REGISTER 4 UPPER BYTE (Read /Write) Bit 31 Bit 30 Bit 29 Bit 28 Bit 27 Bit 26 Bit 25 Bit 24...
-
Page 43: Built-In-Test Programming
Built-In-Test Programming Built-In-Test Programming Built-in-test is activated when either or both test mode bits in the CSR are cleared. When test mode is active, data written to a data register will overwrite the external inputs. Then when the same register is read, the data stored in the test register should be read. - Page 44 VMIVME-1129 128-bit Digital Input Board with Built-In-Test...
-
Page 45: Maintenance
• Quality of cables and I/O connections If the product must be returned, contact VMIC for a Return Material Authorization (RMA) Number. This RMA Number must be obtained prior to any return. Contact VMIC customer Service at 1-800-240-7782, or... -
Page 46: Maintenance Prints
VMIVME-1129 128-bit Digital Input Board with Built-In-Test Maintenance Prints User level repairs are not recommended. The drawings and tables in this manual are for reference purposes only.
