VMIC VMICPCI-7755 Product Manual

Intel pentium iii processor with 133mhz front-side bus
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
VMICPCI-7755
Intel Pentium III Processor
with 133MHz Front-Side Bus
Product Manual
12090 South Memorial Parkway
Huntsville, Alabama 35803-3308, USA
w
w
(256) 880-0444
(800) 322-3616
Fax: (256) 882-0859
500-657755-000 Rev. E

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VMICPCI-7755 and is the answer not in the manual?

Questions and answers

Related Manuals for VMIC VMICPCI-7755

Summary of Contents for VMIC VMICPCI-7755

  • Page 1 VMICPCI-7755 Intel Pentium III Processor with 133MHz Front-Side Bus Product Manual 12090 South Memorial Parkway Huntsville, Alabama 35803-3308, USA (256) 880-0444 (800) 322-3616 Fax: (256) 882-0859 500-657755-000 Rev. E...
  • Page 3 VMIC reserves the right to make any changes, without notice, to this or any of VMIC’s products to improve reliability, performance, function, or design. VMIC does not assume any liability arising out of the application or use of any product or circuit described herein; nor does VMIC convey any license under its patent rights or the rights of others.

  • Page 5: Table Of Contents

    Table Of Contents Overview ..................Intel 815E Chipset .
  • Page 6 Video Graphics Adapter ..............Chapter 3 - Embedded PC/RTOS Features .
  • Page 7 Appendix A - Connector Pinouts ............J1 Connector Pinout .
  • Page 8 Help Window ................First Boot .
  • Page 9 VMICPCI-7755 21154 SROM Code ........
  • Page 11 Figure 1-2 Installing a PMC Card on the VMICPCI-7755 ........
  • Page 13 VMICPCI-7755 I/O Address Map ........

  • Page 15: Overview

    Overview Introduction VMIC’s VMICPCI-7755 is a full featured Pentium III compatible computer in a single-slot, passively cooled, Eurocard form factor that utilizes the advanced technology of Intel’s 815E chipset running at a front-side bus rate of 133 MHz. The VMICPCI-7755 is compliant with the CompactPCI Specification Rev. 2.1 and features...
  • Page 16 VMICPCI-7755 is capable of executing many of today’s embedded operating systems such as VxWorks, QNX, Solaris, LynxOS and Microsoft’s embedded Windows NT. The embedded features of the VMICPCI-7755 are described in Chapter 3 of this manual. The VMICPCI-7755 is suitable for use in applications ranging from...

  • Page 17: Intel 815E Chipset

    Intel 815E Chipset Intel 815E Chipset The VMICPCI-7755 incorporates the latest Intel chipset technology, the 815E. This chipset departs from previous generation devices by utilizing a new Advanced Hub Architecture (AHA). The AHA allows for increased system performance by separating many high-bandwidth I/O accesses (like IDE or USB devices) from PCI accesses, relieving bottlenecks on the PCI bus.

  • Page 18: Figure 1 Vmicpci-7755 Block Diagram

    PC87366 Expansion 1 Expansion 2 PS/2 Keyboard PCI Bus (32 bit) Mouse Ethernet Embedded Interface Controller PCI Bridge FPGA Intel 82559ER Intel 21154 Timers Watchdog Timer 10BaseT 32 Kbyte CompactPCI Bus (64 Bit) 100BaseTX NVRAM Figure 1 VMICPCI-7755 Block Diagram...

  • Page 19: Organization Of The Manual

    Chapter 1 - Installation and Setup describes unpacking, inspection, hardware jumper settings, connector definitions, installation, system setup and operation of the VMICPCI-7755. Chapter 2 - Standard Features describes the unit design in terms of the standard PC memory and I/O maps, along with the standard interrupt architecture.

  • Page 20: References

    Intel 815 Chipset Family: 82815 Graphics and Memory Controller Hub (GMCH) June 2000, Order Number 290687-001 Intel 82801 BA I/O Controller Hub 2 (ICH2) June 2000, Order Number 290687-001 Intel 21154 Embedded PCI-to-PCI Bridge for VMIC’s CompactPCI CPU 500-000210-000 VMIC 12090 South Memorial Pkwy...
  • Page 21 Wakefield, MA 01880 (617) 224-1100 (617) 224-1239 (FAX) www.picmg.org The following is useful information related to remote Ethernet booting of the VMICPCI-7755: Microsoft Windows NT Server Resource Kit Microsoft Corporation ISBN: 1-57231-344-7 www.microsoft.com The following is useful information related to the operation of the I...

  • Page 22: Safety Summary

    Failure to comply with these precautions or with specific warnings elsewhere in this manual violates safety standards of design, manufacture and intended use of this product. VMIC assumes no liability for the customer’s failure to comply with these requirements. Ground the System To minimize shock hazard, the chassis and system cabinet must be connected to an electrical ground.

  • Page 23: Warnings, Cautions And Notes

    Warnings, Cautions and Notes Warnings, Cautions and Notes STOP informs the operator that a practice or procedure should not be performed. Actions could result in injury or death to personnel, or could result in damage to or destruction of part or all of the system. WARNING denotes a hazard.
  • Page 24 VMICPCI-7755 Product Manual...

  • Page 25: Chapter 1 - Installation And Setup

    All claims arising from shipping damage should be filed with the carrier and a complete report sent to VMIC Customer Service along with a request for advice concerning the disposition of the damaged item(s).

  • Page 26: Hardware Setup

    CPU are illustrated in Figure 1-1 on page 27. The definitions of the CPU board jumpers and connectors are included in Table 1-1 through Table 1-4. Please note that the VMICPCI-7755 offers two PMC sites designated PMC #1 and PMC #2 as shown in Figure 1-1 on page 27.

  • Page 27: Figure 1-1 Vmicpci-7755 Pmc And Jumper Locations

    Hardware Setup PMC 1 PMC 2 Figure 1-1 VMICPCI-7755 PMC and Jumper Locations...

  • Page 28: Table 1-1 Cpu Board Connectors

    VMICPCI-7755 Product Manual Table 1-1 CPU Board Connectors Connector Function Mouse/Keyboard Ethernet USB, COM1, IDE COM2, Floppy Video E30, E36, E40 Factory Reserved Do Not Use C Header J8, J10, J11 PMC Slot 1 J12, J14, J15 PMC Slot 2...

  • Page 29: Power Requirements

    50mA 75mA The VMICPCI-7755 provides power to the two PMC sites in accordance with the PMC specification. The maximum current provided on the +5V supply is 1.5A per PMC site. The maximum current provided on the +3.3V supply is 1.5A per PMC site.

  • Page 30: Installation

    The following steps describe the VMIC-recommended method for installation and powerup of the VMICPCI-7755: 1. If a PMC module is to be used, connect it to the VMICPCI-7755 prior to board installation (as shown in Figure 1-2 on page 32). Refer to the Product Manual for the PMC module for configuration and setup.

  • Page 31: Bios Setup

    Configuration’. The CMOS configuration controls many details concerning the behavior of the hardware from the moment power is applied. The VMICPCI-7755 is shipped from the factory with hard drive type configuration set to AUTO in the CMOS. Details of the VMICPCI-7755 BIOS setup program are included in Appendix C.

  • Page 32: Figure 1-2 Installing A Pmc Card On The Vmicpci-7755

    VMICPCI-7755 Product Manual Third Party PMC Expansion Board Standoff Figure 1-2 Installing a PMC Card on the VMICPCI-7755...

  • Page 33: Front/Rear Panel Connectors

    The VMICPCI-7755 provides front-panel access for both PMC expansion sites, the VGA connector, the 10/100 Ethernet connector, the manual reset switch, a mouse and keyboard and the status LEDs. A drawing of the VMICPCI-7755 front-panel is shown in Figure 1-3. The front-panel connectors and indicators are labeled as follows: •...

  • Page 34: Led Definition

    VMICPCI-7755 Product Manual LED Definition PMC 1 Switch Reset - Allows the system to be reset from the front panel. LED 1 System - Indicates BIOS Boot is in progress. When LED is off, CPU has finished POST and is ready, (Red LED).

  • Page 35: Table 1-4 Status Indications

    Front/Rear Panel Connectors In addition, the front-panel LEDs are used to indicate various modes of operational status that can occur with the VMICPCI-7755. The table below is a summary of these indications. Table 1-4 Status Indications State Indication Board is in Reset “LAN 10BaseT/100BaseT”...
  • Page 36 VMICPCI-7755 Product Manual...

  • Page 37: Chapter 2 - Standard Features

    Video Graphics Adapter ..........50 Introduction The VMICPCI-7755 is an Intel Pentium III processor-based single board computer compatible with modern industry standard desktop systems. The VMICPCI-7755 therefore retains industry standard memory and I/O maps along with a standard interrupt architecture.

  • Page 38: Cpu Socket

    Windows NT 4.0 service pack level 3. It is recommended that an emergency repair disk be kept up-to-date and easily accessible. The VMICPCI-7755 includes 32 Kbyte of non-volatile SRAM which can be accessed by the CPU at any time, and is used to store system data that must not be lost during power-off conditions.

  • Page 39: I/O Port Map

    I/O Port Map I/O Port Map Like a desktop system, the VMICPCI-7755 includes special input/output instructions that access I/O peripherals residing in I/O addressing space (separate and distinct from memory addressing space). Locations in I/O address space are referred to as ports.
  • Page 40 $500 - CFF 2048 Reserved * While these I/O ports are reserved for the listed functions, they are not implemented on the VMICPCI-7755. They are listed here to make the user aware of the standard PC usage of these ports.

  • Page 41: Interrupts

    The interrupt number in HEX and decimal are also defined for real and protected mode in Table 2-3 on page 42. The interrupt hardware implementation on the VMICPCI-7755 is standard for computers built around the PC architecture, which evolved from the IBM PC/XT. In the IBM PC/XT computers, only eight interrupt request lines exist, numbered from IRQ0 to IRQ7 at the PIC.

  • Page 42: Table 2-3 Pc Interrupt Vector Table

    VMICPCI-7755 Product Manual Table 2-2 PC Hardware Interrupt Line Assignments (Continued) AT FUNCTION COMMENTS Mouse Math Coprocessor AT Hard Drive Flash Drive Table 2-3 PC Interrupt Vector Table INTERRUPT NO. REAL MODE PROTECTED MODE LINE Divide Error Same as Real Mode...
  • Page 43 Interrupts Table 2-3 PC Interrupt Vector Table (Continued) INTERRUPT NO. REAL MODE PROTECTED MODE LINE BIOS Keyboard I/O Same as Real Mode BIOS Printer I/O Same as Real Mode ROM BASIC Entry Point Same as Real Mode Bootstrap Loader Same as Real Mode Time of Day Same as Real Mode Control/Break Handler...

  • Page 44: Pci Interrupts

    For a single function device, only INTA# may be used while the other three interrupt lines have no meaning. Figure 2-1 on page 46 depicts the VMICPCI-7755 interrupt logic pertaining to CompactPCI operations and the PMC site.

  • Page 45: Pci Device Interrupt Map

    DEVICE ADDRESS PCI IRQ DEVICE COMPONENT Request MAP ID Line SELECT PCI-to-PCI Bridge Intel 21154 0x1011 0x0026 AD26 REQ0 Timer/SRAM FPGA VMIC Proprietary 0x114A 0x6504 AD20 INTD PMC1 AD31 INTC REQ3 PMC2 AD30 INTA REQ2 Ethernet Controller Intel 82559ER 0x8086...

  • Page 46: Figure 2-1 Connections For The Pc Interrupt Logic Controller

    VMICPCI-7755 Product Manual INTR 8259 MASTER- PORTS $020-$021 Unused Floppy Keybd Interrupt Com 2 Com 1 Unused Timer 8-15 Control IRQ0 IRQ1 IRQ2 IRQ3 IRQ4 IRQ5 IRQ6 IRQ7 8259 SLAVE- PORTS $0A0-$0A1 Real-Tm Mouse Math Flash IRQ2 Hard Drv Drive...

  • Page 47: Table 2-5 Nmi Register Bit Descriptions

    Interrupts The PCI-to-PCI Bridge has the capability of generating a Non-Maskable Interrupt (NMI) via the PCI SERR# line. Table 2-5 describes the register bits that are used by the NMI. The SERR interrupt is routed through logic back to the NMI input line on the CPU.

  • Page 48: Integrated Peripherals

    Integrated Peripherals The VMICPCI-7755 incorporates a National Semiconductor Super I/O (SIO) chip. The SIO provides the VMICPCI-7755 with a standard floppy drive controller, two 16550 UART-compatible serial ports keyboard and mouse ports, and general purpose I/O for system monitoring functions. The floppy and serial port signals are available via the CompactPCI backplane connectors and can be accessed with the appropriate transition utility board.

  • Page 49: Ethernet Controller

    Ethernet Controller Ethernet Controller The network capability is provided by the Intel 82559ER Ethernet Controller. This Ethernet controller is PCI bus based and is software configurable. The VMICPCI-7755 supports 10BaseT and 100BaseTx Ethernet. 10BaseT A network based on the 10BaseT standard uses unshielded twisted-pair cables, providing an economical solution to networking by allowing the use of existing telephone wiring and connectors.

  • Page 50: Video Graphics Adapter

    VMICPCI-7755 Product Manual Video Graphics Adapter The SVGA port on the VMICPCI-7755 is controlled by the Intel Graphic and Memory Controller Hub (GMCH) chip with 4 Mbyte video DRAM. The GMCH is hardware and BIOS compatible with the industry EGA and SVGA standards supporting both VESA high-resolution and extended video modes.

  • Page 51: Chapter 3 - Embedded Pc/Rtos Features

    Watchdog Timer for synchronizing and controlling multiple events in embedded applications. The VMICPCI-7755 also provides a bootable Flash Disk system and 32 Kbyte of non-volatile SRAM. Also, the VMICPCI-7755 supports an embedded intelligent CompactPCI bridge to allow compatibility with the most demanding CompactPCI applications.

  • Page 52: Compactpci Bus Bridge

    The VMICPCI-7755 incorporates a PCI peripheral device that performs PCI bridging functions for embedded and intelligent I/O applications. The PCI device acts as a gateway to an intelligent subsystem. It allows the local VMICPCI-7755 processor to configure and control the on-board local subsystem independent from the CompactPCI bus host processor.

  • Page 53: I2C Support

    C bus with a single pair of pull-up resisters located on the system controller, backplane or any other connected system device. The controller can issue interrupts to the VMICPCI-7755 when handshaking on the C-bus. When the I C-bus controller drives the interrupt active, software must service and then clear the interrupt.

  • Page 54: Embedded Pci Functions

    The “Device ID” field indicates that the device is for CompactPCI products (65) and indicates the supported embedded feature set. The “Vender ID” and “Subsystem Vendor ID” fields indicate VMIC’s PICMG assigned Vender ID (114A). The “Subsystem ID” field indicates the model number of the product (7755).

  • Page 55: Timers

    Timers Timers General The VMICPCI-7755 provides four user-programmable timers (two 16-bit and two 32-bit) which are dedicated completely to user applications and are not required for any standard system function. Each timer is clocked by independent generators with selectable rates of 2MHz, 1MHz, 500kHz and 250kHz. Each timer may be independently enabled and each is capable of generating a system interrupt on timeout.

  • Page 56: Timer Control Status Register 2 (Tcsr2)

    VMICPCI-7755 Product Manual Each timer has an independently selectable clock source which is selected by the bit pattern in the “Timer x Clock Select” field as follows: Clock Rate 2MHz 1MHz 500kHz 250kHz Each timer can be independently enabled by writing a “1” to the appropriate “Timer x Enable”...

  • Page 57: Timer 1 & 2 Load Count Register (Tmrlcr12)

    Timers result, it is not possible to capture the values of all four timers at a give instance in time. However, by setting this bit to “1”, all four timer outputs will be latched only on reads to the Timer 1 & 2 Current Count Register (TMRCCR12). Therefore, to capture the current count of all four timers at the same time, perform a read to the TMRCCR12 first (with a 32-bit read), followed by a read to TMRCCR3 and TMRCCR4.

  • Page 58: Timer 4 Load Count Register (Tmrlcr4)

    VMICPCI-7755 Product Manual Timer 4 Load Count Register (TMRLCR4) Timer 4 is 32-bits wide and obtains its load count from the Timer 4 Load Count Register (TMRLCR4), located at offset 0x18 from the address in BAR1. The mapping of bits in this register are as follows:...

  • Page 59: Timer 4 Current Count Register (Tmrccr4)

    Timers When this field is read, the current count value is latched and returned. There are two modes that determine how the count is latched depending on the setting of the “Read Latch Select” bit in the WDT Control Status Register (CSR2). See the CSR2 register description for more information on these two modes.

  • Page 60: Timer 4 Irq Clear (T4Ic)

    VMICPCI-7755 Product Manual Timer 4 IRQ Clear (T4IC) The Timer 4 IRQ Clear (T4IC) register is used to clear an interrupt caused by Timer 4. Writing to this register, located at offset 0x3C from the address in BAR1, causes the interrupt from Timer 4 to be cleared.

  • Page 61: Watchdog Timer

    Watchdog Timer Watchdog Timer General The VMICPCI-7755 provides a programmable Watchdog Timer (WDT) which can be used to reset the system if software integrity fails. WDT Control Status Register (WCSR) The WDT is controlled and monitored by the WDT Control Status Register (WCSR) which is located at offset 0x08 from the address in BAR1.

  • Page 62: Wdt Keepalive Register (Wkpa)

    VMICPCI-7755 Product Manual The “WDT Enable” bit is used to enable the Watchdog Timer function. This bit must be set to “1” in order for the Watchdog Timer to function. Note that since all registers default to zero after reset, the Watchdog Timer is always disabled after a reset. The Watchdog Timer must be re-enabled by the application software after reset in order for the Watchdog Timer to continue to operate.

  • Page 63: Nvsram

    NVSRAM NVSRAM The VMICPCI-7755 provides 32KBytes of non-volatile SRAM. This memory is mapped in 32K of address space starting at the address in BAR0. This memory is available at any time and supports byte, short word and long word accesses from the PCI bus.

  • Page 64: Flash Disk

    Flash Disk. Configuration The Flash Disk resides on the VMICPCI-7755 as the secondary IDE bus master device (the secondary IDE bus slave device is not assignable). The default setting in the Phoenix BIOS ‘STANDARD CMOS SETUP’ screen is the ‘AUTO’ setting. In the Phoenix BIOS ‘PERIPHERAL SETUP’...

  • Page 65: Functionality

    Following the creation of the partitioning scheme, the partitions can be formatted to contain the desired file system. As discussed earlier, a typical system consists of the VMICPCI-7755 with its resident Flash Disk configured as the Secondary IDE device, a hard drive attached to the Primary IDE interface, and a floppy drive attached to the floppy interface.
  • Page 66 VMICPCI-7755 Product Manual 3. Set Flash Disk Master to “AUTO”. 4. Set boot device to floppy. 5. Boot DOS from the floppy, and verify that the System Configuration Screen shows only the Flash Disk. 6. Run FDISK. 7. Delete all current partitions (any data currently stored in the partitions will be lost).

  • Page 67: Remote Ethernet Booting

    Remote Ethernet Booting Remote Ethernet Booting The VMICPCI-7755 is capable of booting from a server over a network utilizing Lanworks BootWare BIOS. The BootWare BIOS gives you the ability to remotely boot the VMICPCI-7755 using a variety of network protocols. The Ethernet must be connected through the LAN front panel (RJ-45) connector to boot remotely.
  • Page 68 VMICPCI-7755 Product Manual...

  • Page 69: Chapter 4 - Maintenance

    8. Quality of cables and I/O connections If products must be returned, contact VMIC for a Return Material Authorization (RMA) Number. This RMA Number must be obtained prior to any return. VMIC Customer Service is available at: 1-800-240-7782.
  • Page 70 VMICPCI-7755 Product Manual...
  • Page 71 PMC Connector Pinout ..........80 Introduction The VMICPCI-7755 CompactPCI Peripheral SBC has several connectors for its I/O ports. Wherever possible, the VMICPCI-7755 uses connectors and pinouts typical for any desktop PC.

  • Page 72: Figure A-1 J1 Connector And Pinout

    VMICPCI-7755 Product Manual J1 Connector Pinout The VMICPCI-7755 utilitizes a high-density 110-pin, low inductance, and controlled impedance connector. This connector meets the IEC-1076 international standard for CompactPCI connectors. An additional external metal shield is required. The large number of ground pins ensures adequate shielding and grounding for low ground bounce and reliable operation in noisy environments.

  • Page 73: Figure A-2 J2 Connector And Pinout

    J2 Connector Pinout J2 Connector Pinout The VMICPCI-7755 J2 connector is a 2mm “Hard Metric” CompactPCI connector, with 5 rows of 22 pins each. J2 is required for system slot CPUs. An additional external metal shield, labeled row F, is also used. This connector’s controlled impedance minimizes unwanted signal reflections.

  • Page 74: Figure A-3 J3 Connector And Pinout

    VMICPCI-7755 Product Manual J3 Connector Pinout The J3 connector is a 5 row, 19 pins each, 2mm “Hard Metric” CompactPCI connector. An additional external metal shield is also used, labeled row F. Figure A-3 illustrates the J3 connector and the connector pinout. This connector is used to route the I/O signals of the PMC Site #2 and the serial and floppy drive signals to the backplane I/O.

  • Page 75: Figure A-4 J4 Connector (Optional) And Pinout

    J4 Connector Pinout (Optional) J4 Connector Pinout (Optional) The VMICPCI-7755 utilitizes a high-density 110-pin, low inductance, and controlled impedance connector. This connector meets the IEC-1076 international standard for CompactPCI connectors. An additional external metal shield is required. The large number of ground pins ensures adequate shielding and grounding for low ground bounce and reliable operation in noisy environments.

  • Page 76: Figure A-5 J5 Connector And Pinout

    VMICPCI-7755 Product Manual J5 Connector Pinout The VMICPCI-7755 J5 connector is a 2mm “Hard Metric” CompactPCI connector, with 5 rows of 22 pins each. An additional external metal shield is also used, labeled row F. This connector is used to route the I/O signals of PMC Site #1, and the IDE, serial and USB signals to the backplane I/O.

  • Page 77: Figure A-6 Ethernet Connector And Pinout

    Ethernet Connector Pinout (J6) Ethernet Connector Pinout (J6) The pinout diagram for the Ethernet 10BaseT and 100BaseTx connector is shown in Figure A-6. ETHERNET CONNECTOR (10BaseT, 100BaseTx) Signal Name Transmit Data Transmit Data Receive Data TX_CT_OUT Transmit Center Tap Out TX_CT_OUT Transmit Center Tap Out Receive Data...

  • Page 78: Figure A-7 Video Connector And Pinout

    VMICPCI-7755 Product Manual Video Connector Pinout (P3) The video port uses a micro DB9 connector. Figure A-7 illustrates the connector and pinout. Video Connector Direction Function Green Blue Horizontal Sync Vertical Sync DDC Data DDC Clock Ground Figure A-7 Video Connector and Pinout NOTE: An adapter to convert the micro DB9 connector to a standard female high-density DB15 connector is available as an option (order # 360-000168-004).

  • Page 79: Figure A-8 Keyboard/Mouse Connector And Pinout

    Ground +5 V Mouse Clock Keyboard Clock Shield Chassis Ground *An adapter cable is included with the VMICPCI-7755 to separate the keyboard and mouse connector. Figure A-8 Keyboard/Mouse Connector and Pinout Table A-1 Keyboard/Mouse Y Splitter Cable Keyboard Mouse Function...

  • Page 80: Table A-2 Pmc #1 (J11)/Pmc #2 (J15) Connector Pinout

    VMICPCI-7755 Product Manual PMC Connector Pinout PMC #1 (J11)/PMC #2 (J15) Connector and Pinout The PCI Mezzanine Card (PMC) carries the same signals as the PCI standard; however, the PMC standard uses a completely different form factor. Tables A-2 through A-5 are the pinouts for the PMC connectors (J8, J10, J11, J12, J14 and J15).

  • Page 81: Table A-3 Pmc #1 (J10)/Pmc #2 (J14) Connector Pinout

    PMC Connector Pinout PMC #1 (J10)/PMC #2 (J14) Connector and Pinout Table A-3 PMC #1 (J10)/PMC #2 (J14) Connector Pinout PMC Connector (J10/J14) PMC Connector (J10/J14) Left Side Right Side Left Side Right Side Name Name Name Name +12 V +5 V TRDY +3.3 V...

  • Page 82: Table A-4 Pmc #1 J8 Connector Pinout

    VMICPCI-7755 Product Manual PMC #1 (J8) Connector and Pinout Table A-4 PMC #1 J8 Connector Pinout PMC Connector (J8) PMC Connector (J8) Left Side Right Side Left Side Right Side Connected Connected Connected Connected Name Name Name Name J8-1 J5 pin E22...

  • Page 83: Table A-5 Pmc #2 J12 Connector Pinout

    PMC Connector Pinout PMC #2 (J12) Connector and Pinout Table A-5 PMC #2 J12 Connector Pinout PMC Connector (J12) PMC Connector (J12) Left Side Right Side Left Side Right Side Connected Connected Connected Connected Name Name Name Name J12-1 J3 pin E22 J12-2 J3 pin D22 J12-33...
  • Page 84 VMICPCI-7755 Product Manual...
  • Page 85 Status of PCI Devices Listed in Windows Device Manager ....95 Introduction The VMICPCI-7755 provides high-performance video, Ultra ATA storage device control and Local Area Network (LAN) access by means of on-board PCI-based adapters and associated software drivers.

  • Page 86: Using Usb Keyboard/Mouse With Microsoft Windows Oss

    VMICPCI-7755 Product Manual Using USB Keyboard/Mouse with Microsoft Windows OSs This section applies if either a USB keyboard or USB mouse is connected. It does not apply if a PS/2 keyboard and mouse are used. Windows 98 SE/Windows 2000 The use of a USB keyboard/mouse with an operating system that supports USB devices requires changing the default BIOS settings before and after the installation of Windows 98 SE/2000.

  • Page 87: Bios Setup

    BIOS Setup BIOS Setup To enable/disable Legacy USB Support and/or assign an interrupt to the USB controller, perform the appropriate actions as outlined below: 1. Immediately after the CPU has been powered on or reset, press F2 to enter the ‘Phoenix BIOS Setup Utility’.

  • Page 88: Microsoft Windows 98 Se Software Driver Installation

    VMICPCI-7755 Product Manual Microsoft Windows 98 SE Software Driver Installation 1. Prior to installing Windows 98 SE, ensure the BIOS is set to assign an interrupt to the USB controller. Also ensure ‘Installed OS’ is set to ‘Win98/Win2000’. See ‘BIOS Setup’ on page 87 for guidelines on changing BIOS settings.

  • Page 89: Ultra Ata Storage Driver Installation

    Microsoft Windows 98 SE Software Driver Installation Ultra ATA Storage Driver Installation 1. If not already present, insert the ‘Windows Drivers’ CD-ROM. 2. Click ‘Start’, ‘Run’, ‘Browse’. In the ‘Look in’ pull-down selection menu, select the ‘Windows Drivers’ CD-ROM. Double-click on the ‘Win98’ folder. Double-click on the ‘UltraATA’...
  • Page 90 VMICPCI-7755 Product Manual 3. Select ‘PCI Ethernet Controller’ (found under ‘Other devices’) and click ‘Properties’. 4. In the ‘PCI Ethernet Controller Properties’ windows, click on the ‘Driver’ tab. Click ‘Update Driver’. Click ‘Next’ twice. Ensure ‘Floppy disk drives’ is the only location selected and click ‘Next’.

  • Page 91: Microsoft Windows Nt 4.0 Software Driver Installation

    Microsoft Windows NT 4.0 Software Driver Installation Microsoft Windows NT 4.0 Software Driver Installation 1. Follow the normal Windows NT 4.0 installation until the ‘Windows NT Workstation Setup’ window that states ‘Windows NT needs to know how this computer should participate on a network’ is displayed. 2.

  • Page 92: Ethernet Adapter Driver Installation

    VMICPCI-7755 Product Manual 2. If not already present, insert the ‘Windows Drivers’ CD-ROM. Click ‘Start’, ‘Run’, ‘Browse’. In the ‘Look in’ pull-down selection menu, select the ‘Windows Drivers’ CD-ROM. Double-click on the ‘WinNT’ folder. Double-click on the ‘LAN’ folder. Double-click on ‘Makedisk’. Click ‘OK’.

  • Page 93: Microsoft Windows 2000 Software Driver Installation

    Microsoft Windows 2000 Software Driver Installation Microsoft Windows 2000 Software Driver Installation 1. Prior to installing Windows 2000, ensure the BIOS is set to assign an interrupt to the USB controller. Also ensure ‘Installed O/S’ is set to ‘Win98/Win2000’. See “BIOS Setup”...

  • Page 94: Ethernet Adapter Driver Installation

    VMICPCI-7755 Product Manual 2. Click ‘Start’, ‘Run’, ‘Browse’. In the ‘Look in’ pull-down selection menu, select the ‘Windows Drivers’ CD-ROM. Double-click on the ‘Win2000’ folder. Double-click on the ‘Video’ folder. Double-click on ‘Setup’. Click ‘OK’. 3. At the ‘Intel 810/810E/815/815E/815EM Chipset Graphics Drivers’ window, click ‘Next’.

  • Page 95: Status Of Pci Devices Listed In Windows Device Manager

    After installing all of the drivers provided on the Windows Drivers CD-ROM, Device Manager will still indicate that several PCI devices do not have drivers loaded. These devices are the PCI-to-PCI bridge and the VMIC proprietary FPGA. Although these devices are listed as non-functioning by Windows, the hardware is functioning as...
  • Page 96 VMICPCI-7755 Product Manual...

  • Page 97: System Bios Setup Utility

    Exit Menu ............111 Introduction The VMICPCI-7755 utilizes the BIOS (Basic Input/Output System) in the same manner as other PC/AT compatible computers. This appendix describes the menus and options associated with the VMICPCI-7755 BIOS.

  • Page 98: First Boot

    VMICPCI-7755 Product Manual First Boot The VMICPCI-7755 has a First Boot menu enabling the user to, on a one time basis, select a drive device to boot from. This feature is useful when installing from a bootable disk. For example, when installing Windows NT from a CD, enter the First Boot menu and use the arrows keys to highlight ATAPI CD-ROM Drive.

  • Page 99: Main Menu

    Main Menu Main Menu The Main menu allows the user to select QuickBoot, set the system clock and calendar, record disk drive parameters, and set selected functions for the keyboard. Qu‚rv‘ÃTr‡ˆƒÃV‡vyv‡’ H6DI 6q‰hprq Trpˆ…v‡’ Q‚r… 7‚‚‡ @‘v‡ D‡r€ÃTƒrpvsvpÃCryƒ Rˆvpx7‚‚‡ÃH‚qr) b@hiyrqd T’†‡r€ÃUv€r) b $)#%)!"d 6yy‚†Ã‡urÆ’†‡r€Ã‡‚...

  • Page 100: Legacy Diskette

    PGDN Primary Master/Slave The VMICPCI-7755 is capable of utilizing one IDE hard disk drive on the Primary Master bus. The default setting is Auto. The Primary Slave is assigned to the CD-ROM (if installed). If a setting other than Auto is selected the user must match the settings to the hardware.

  • Page 101: Keyboard Features

    Main Menu Secondary Master The Secondary Master is the resident Flash Disk (if installed). The default setting is Auto. Keyboard Features The Keyboard Features allows the user to set several keyboard functions. Qu‚rv‘ÃTr‡ˆƒÃV‡vyv‡’ H6DI D‡r€ÃTƒrpvsvpÃCryƒ Fr’i‚h…qÃArh‡ˆ…r† Tryrp‡†ÃQ‚r…‚Ã†‡h‡r Iˆ€G‚px) b6ˆ‡‚d s‚…ÃIˆ€G‚px Fr’Ã8yvpx) b9v†hiyrqd Fr’i‚h…qÃ6ˆ‡‚Srƒrh‡ÃSh‡r) b"†rpd...

  • Page 102: Keyboard Test

    VMICPCI-7755 Product Manual Keyboard Auto-Repeat Delay (sec) If the Key Click is enabled, this determines the delay before a character starts repeating when a key is held down. The options are: 1/4, 1/2, 3/4 or 1 second. The default is 1/2.

  • Page 103: Flow Control

    Main Menu Flow Control Enables or disables Flow Control. The options are No Flow Control, XON/XOFF or CTS/RTS. The default is CTS/RTS. Console Connection Indicates whether the console is connected directly to the system, or if a modem is being used to connect. The options are: Direct or Via Modem. The default is Direct. Continue C.R.

  • Page 104: Advanced Menu

    VMICPCI-7755 Product Manual Advanced Menu Selecting Advanced from the Main menu will display the screen shown below. Qu‚rv‘ÃTr‡ˆƒÃV‡vyv‡’ 69W6I8@9 Hhv Trpˆ…v‡’ Q‚r… 7‚‚‡ @‘v‡ D‡r€ÃTƒrpvsvpÃCryƒ # 6q‰hprqÃ8uvƒ†r‡Ã8‚‡…‚y # 8hpurÃHr€‚…’ Tryrp‡Ã‡urƒr…h‡vt # DPÃ9r‰vprÃ8‚svtˆ…h‡v‚ †’†‡r€Ãv†‡hyyrq Sr†r‡Ã8‚svtˆ…h‡v‚Ã9h‡h bI‚d ‚Ã’‚ˆ…Æ’†‡r€Ãuvpu D†‡hyyrqÃPT) bP‡ur…d ’‚ˆÃvyyȆrÀ‚†‡ Gh…trÃ9v†xÃ6ppr††ÃH‚qr) b9PTd p‚€€‚y’...

  • Page 105: Cache Memory

    Advanced Menu Video Boot Type Select “Onboard Video’ to enable the onboard video controller as the boot display device. Select “Disable Onboard Video’ to disable the onboard video controller. Enable Memory Gap If enabled, turn system RAM off to free address space for use with an option card. Either a 128KB conventional memory gap, starting at 512KB, or a 1MB extended memory gap, starting at 15MB, will be created in the system RAM.

  • Page 106: Reset Configuration Data

    VMICPCI-7755 Product Manual I/O Device Configuration Select this menu to configure your I/O devices, if required. Qu‚rv‘ÃTr‡ˆƒÃV‡vyv‡’ 69W6I8@9 D‡r€ÃTƒrpvsvpÃCryƒ DPÃ9r‰vprÃ8‚svtˆ…h‡v‚ 8‚svtˆ…rÆr…vhyÂ…‡Ã6 Tr…vhyÂ…‡Ã6) b6ˆ‡‚d ˆ†vtƒ‡v‚†) Tr…vhyÂ…‡Ã7) b6ˆ‡‚d b9v†hiyrqd I‚Ã8‚svtˆ…h‡v‚ Ay‚ƒƒ’Ãqv†xÃp‚‡…‚yyr…) b@hiyrqd b@hiyrqd V†r…Ã8‚svtˆ…h‡v‚ QT!ÃH‚ˆ†r b6ˆ‡‚Ã9r‡rp‡d b6ˆ‡‚d 7DPTÂ…ÃPTÃpu‚‚†r† PTÃ8‚‡…‚yyrq 9v†ƒyh’rqÐur p‚‡…‚yyrqÃi’ÃPT A Cryƒ...

  • Page 107: Legacy Usb Support

    Advanced Menu Local Bus IDE Adapter This enables or disables the intergrated local bus IDE adapter. The options are: Disabled, Primary, Secondary or Both. The default is Both. Assign Interrupt To USB Enabled assigns an interrupt to the USB. The default is Enabled. Legacy USB Support Enabled supports a legacy keyboard and mouse on the USB.

  • Page 108: Security

    VMICPCI-7755 Product Manual Security Utilize this screen to set a user password. Qu‚rv‘ÃTr‡ˆƒÃV‡vyv‡’ Trpˆ…v‡’ D‡r€ÃTƒrpvsvpÃCryƒ Trpˆ…v‡’ Tˆƒr…‰v†‚…ÃQh††‚…q ÃÃÃTr‡ÃV†r…ÃQh††‚…q bÃ@‡r…Ãd p‚‡…‚y†Ã6ppr††Ã‡‚Çur ÃÃÃTr‡ÃTˆƒr…‰v†‚…ÃQh††‚…q b@‡r…d †r‡ˆƒÃˆ‡vyv‡’ ÃÃÃQh††‚…qÃi‚‚‡) b9v†hiyrqd ÃÃÃAv‘rqÃqv†xÃi‚‚‡Ã†rp‡‚… bI‚…€hyd ÃÃÃ9v†xr‡‡rÃhppr††)ÃÃà bV†r…d A Cryƒ Tryrp‡ÃD‡r€8uhtrÃWhyˆr†A(Tr‡ˆƒÃ9rshˆy‡† ↑ ↓ @T8@‘v‡ Tryrp‡ÃHrˆ@‡r…Tryrp‡Ã#ÃTˆiHrˆA Th‰rÃhqÃ@‘v‡ ← → Password On Boot Enables password entry on boot.

  • Page 109: Power

    Power Power This screen, selected from the Main screen, allows the user to configure power saving options on the VMICPCI-7755. Qu‚rv‘ÃTr‡ˆƒÃV‡vyv‡’ QPX@S Hhv 6q‰hprq Trpˆ…v‡’ 7‚‚‡ @‘v‡ D‡r€ÃTƒrpvsvpÃCryƒ 8QVÃUu…‚‡‡yvtÃ9‚ÃUu…r†u‚yq b9v†hiyrqd 8QVÃUu…‚‡‡yvtÃihpxÃu’†‡r…r†v† b 8d Hh‘v€ˆ€ÃQ‚r…Æh‰vt† Uu…‚‡‡yvtÃÈ b$Èd p‚†r…‰r†Ã‡urÃt…rh‡r†‡ h€‚ˆ‡Ã‚sÆ’†‡r€Ãƒ‚r… Q‚r…ÃTh‰vt†) b9v†hiyrqd Hh‘v€ˆ€ÃQr…s‚…€hpr...

  • Page 110: Boot Menu

    VMICPCI-7755 Product Manual Boot Menu The Boot priority is determined by the stack order, with the top having the highest priority and the bottom the least. The order can be modified by highlighting a device and, using the <+> or <-> keys, moving it to the desired order in the stack. A device can be boot disabled by highlighting the particular device and pressing <Shift 1>.

  • Page 111: Exit Menu

    Exit Menu Exit Menu The Exit menu allows the user to exit the BIOS program, while either saving or discarding any changes. This menu also allows the user to restore the BIOS defaults if desired. Qu‚rv‘ÃTr‡ˆƒÃV‡vyv‡’ @‘v‡ Hhv 6q‰hprq Q‚r… 7‚‚‡...
  • Page 112 VMICPCI-7755 Product Manual...
  • Page 113 BIOS Features Setup ..........116 Introduction The VMICPCI-7755 includes a LANWorks option which allows the VMICPCI-7755 to be booted from a network. This appendix describes the procedures to enable this...

  • Page 114: Boot Menus

    First Boot menu. Selecting “Managed PC Boot Agent (MBA)” to boot from the LAN in this screen applies to the current boot only, at the next re-boot the VMICPCI-7755 will revert back to the setting in the Boot menu.
  • Page 115 Boot Menus Qu‚rv‘ÃTr‡ˆƒÃV‡vyv‡’ 7‚‚‡ H6DI 6q‰hprq Trpˆ…v‡’ Q‚r… @‘v‡ D‡r€ÃTƒrpvsvpÃCryƒ HhhtrqÃQ8Ã7‚‚‡Ã6tr‡ÃH76 ÃSr€‚‰hiyrÃ9r‰vpr†) Fr’†Ãˆ†rqÇ‚ÉvrÃ‚… ÃCh…qÃ9…v‰r p‚svtˆ…rÃqr‰vpr†) ÃÃ6U6QDÃ89SPHÃ9…v‰r 1@‡r…3Ãr‘ƒhq†Ã‚… ÃSr€‚‰hiyrÃ9r‰vpr†) p‚yyhƒ†r†Ãqr‰vpr†Ãv‡u hÃÂ…Ã 18‡…yÃÃ@‡r…3Ãr‘ƒhq† 1Tuvs‡Ãà 3Ãrhiyr†Ã‚… qv†hiyr†ÃhÃqr‰vpr 13ÃhqÃ13À‚‰r†Ã‡urà qr‰vprȃÂ…Ãq‚ 13Àh’À‚‰rÃ…r€‚‰hiyr qr‰vprÃir‡rrÃCh…qà 9v†xÂ…ÃSr€‚‰hiyrÃ9v†x 1q3Ã…r€‚‰rÃhÃqr‰vpr ‡uh‡Ãv†Ã‚‡Ãv†‡hyyrq A Cryƒ Tryrp‡ÃD‡r€8uhtrÃWhyˆr†A(Tr‡ˆƒÃ9rshˆy‡† ↑ ↓ @T8@‘v‡ Tryrp‡ÃHrˆ@‡r…Tryrp‡Ã#ÃTˆiHrˆA Th‰rÃhqÃ@‘v‡ ← →...

  • Page 116: Bios Features Setup

    VMICPCI-7755 Product Manual BIOS Features Setup After the Managed PC Boot Agent has been enabled, there are several boot options available to the user. These options are RPL (default), TCP/IP, Netware and PXE. The screens below show the defaults for each boot method.

  • Page 117: Netware

    BIOS Features Setup Netware HhhtrqÃQ8Ã7‚‚‡Ã6tr‡ÃH76É"!Ã7DPTÃD‡rt…h‡rq pÃ8‚ƒ’…vtu‡Ã (('ÃG6IX‚…x†ÃUrpu‚y‚tvr†Ã8‚Ãhƈi†vqvh…’ÂsÃ"8‚€Ã8‚…ƒ‚…h‡v‚ 6yyÃ…vtu‡†Ã…r†r…‰rq 8‚svtˆ…h‡v‚ 7‚‚‡ÃHr‡u‚q) Ir‡h…r Q…‚‡‚p‚y '!! 8‚svtÃHr††htr) @hiyrq Hr††htrÃUv€r‚ˆ‡) %ÃTrp‚q† 7‚‚‡Ãshvyˆ…rÃQ…‚€ƒ‡) Xhv‡Ãs‚…Ãxr’ 7‚‚‡ÃAhvyˆ…r) Ir‘‡Ã77TÃqr‰vpr V†rÃpˆ…†‚…Ãxr’†Ã‡‚Ãrqv‡)ÃVƒ9‚ÃpuhtrÃsvryqÃGrs‡Svtu‡ÃpuhtrÉhyˆr @T8ǂĈv‡ÃA(Ã…r†‡‚…rÃ…r‰v‚ˆ†Ã†r‡‡vt†ÃA Ç‚Æh‰r HhhtrqÃQ8Ã7‚‚‡Ã6tr‡ÃH76É"!Ã7DPTÃD‡rt…h‡rq pÃ8‚ƒ’…vtu‡Ã (('ÃG6IX‚…x†ÃUrpu‚y‚tvr†Ã8‚Ãhƈi†vqvh…’ÂsÃ"8‚€Ã8‚…ƒ‚…h‡v‚ 6yyÃ…vtu‡†Ã…r†r…‰rq 8‚svtˆ…h‡v‚ 7‚‚‡ÃHr‡u‚q) V†rÃpˆ…†‚…Ãxr’†Ã‡‚Ãrqv‡)ÃVƒ9‚ÃpuhtrÃsvryqÃGrs‡Svtu‡ÃpuhtrÉhyˆr @T8ǂĈv‡ÃA(Ã…r†‡‚…rÃ…r‰v‚ˆ†Ã†r‡‡vt†ÃA Ç‚Æh‰r...
  • Page 118 VMICPCI-7755 Product Manual...

  • Page 119: Directory \21154

    CPU card (for example, the VMICPCI-7756) and a system controller CPU (for example, the VMICPCI-7755). Directory \fpga This directory contains code used to test the functions of the VMIC-designed FPGA such as timers, SRAM controller and Watchdog Timer.

  • Page 120: Directory \I2C

    This directory contains memory and PCI access routines used by many of the sample code applications. Directory \vlm This directory contains code that demonstrates how to read the voltages from the analog inputs of the super I/O component on the VMICPCI-7755.

  • Page 121: Vmicpci-7755 21154 Srom Code

    Appendix Serial ROM for the 21154 Introduction The VMICPCI-7755 is shipped with a default configuration for the SROM used to load the 21154 Embedded PCI bridge chip at power up and reset. The contents of the SROM are as follows: VMICPCI-7755 21154 SROM Code ;Preload enable (bit 7 set for preload enable)
  • Page 122 VMICPCI-7755 Product Manual ;Secondary Class Code :0D 00 :0E 80 :0F 06 ;Secondary Min GNT, Max Lat :10 00 :11 00 ;Downstream Mem 0 - CSRs only (Set a 4K window size) FFFFF000 :12 00 :13 F0 :14 FF :15 FF ;Downstream Mem 1 or I/O (Set 256 byte I/O window size) FFFFFF01...
  • Page 123 ;Expansion ROM (Set 1 MB expansion ROM size) :26 01 :27 F0 ;Upstream Mem 0 or I/O (Set 256 byte I/O window size) FFFFFF01 :28 01 :29 FF :2A FF :2B FF ;Upstream Mem 1 (Set 256 MB memory window size) F0000000 :2C 00 :2D 00 :2E 00...
  • Page 124 VMICPCI-7755 Product Manual :3C 00 :3D 00 :3E 00 :3F 00 :40 00 :41 00 :42 00 Upstream or Outbound means going out to the CompactPCI backplane from the local processor, Downstream or Inbound means coming into the local CPU bus from the CompactPCI backplane.
  • Page 125 Index Numerics installation Intel 815 Chipset 49, 77 100BaseTx Intel 82559 Ethernet Controller 49, 77 10BaseT interrupt line assignment 31, 44 BIOS jumper locations BIOS setup BIOS setup screens LPT1 Parallel I/O LPT2 Parallel I/O CMOS configuration connectors CPU board diagram Customer Service master interrupt controller DMA controller...
  • Page 126 VMIVME-7755 Product Manual Serial I/O (COM1,2,3 & 4) SERR interrupt System BIOS Setup Utility unpacking procedures vector interrupt table 89, 91, 93 video driver installation Windows 2000 Installation Windows 98 SE Installation Windows NT 4.0...

Table of Contents
