- Page 1 Ezee-On MODEL 2070 FRONT-END LOADER OWNERS’ MANUAL PARTS LIST Manufactured Vegreville, Alberta Ezee-On Mfg. Ltd. Canada Printed in Canada 614A...
-
Page 2: Warranty
This warranty is void if equipment is used for other than agricultural purposes. The sole obligation of EZEE-ON under this warranty is limited to the repair or replacement of those part(s) (F.O.B. EZEE-ON Factory) of the equipment which EZEE-ON in its sole discretion, determines to have failed as a result of defects in material or workmanship occurring prior to the expiration of one year ("Warranty Period") from delivery by EZEE-ON or its selling dealer ("Dealer") to the original purchaser ("Purchaser"). - Page 3 CYLINDER SEAL KITS EZEE-ON MFG. LTD. RESERVES THE RIGHT to make improvements in design and changes in specifications at any time without notice and without incurring any obligation to install them on units previously sold. Specifications, descriptions, and illustrative material herein are as accurate as known at time of publication, but are subject to change without notice.
-
Page 4: General Safety
LOADER SAFETY RECOMMENDATIONS Watch for this symbol. It identifies important safety messages. When you see this symbol, read the safety message carefully. GENERAL SAFETY 1. Never allow anyone to ride on any portion of the loader or tractor. The person may fall and be seriously or fatally injured. 2. -
Page 5: Maintenance Safety
MAINTENANCE SAFETY 1. Do not disassemble or loosen hydraulic components when there is pressure within those components. Parts and fluid could fly out at a high velocity, resulting in serious injury. Always relieve the pressure in the hydraulic system. 2. Always use wood or cardboard as a backstop, and wear gloves and eye protection when searching the hydraulic system for leaks. Hydraulic fluid escaping under pressure can cause personal injury by penetrating the skin. -
Page 6: Operation Safety
TRANSPORT SAFETY Continued: 3. Never transport the loader with the bucket (or any other attachment) in the "DUMP" position. If the hydraulic system failed, or if the hydraulic lever was accidentally operated, the loader will drop, causing the bucket (or attachment) to dig into the ground. This may result in serious injury or death to the operator and serious damage to the tractor and loader, especially if the tractor is moving at a high rate of speed. -
Page 7: Safety Decals
OPERATION SAFETY Continued:. 8. When raising a load, level attachment at higher lifting ranges to prevent material from falling on to tractor and/or operator. Falling material may cause serious injury or death to operator and serious damage to tractor and loader. 9. - Page 8 LOADER ASSEMBLY INSTRUCTIONS 1. Attach mount brackets to tractor, see instructions in bolt package. 2. See ILL. 1.Install four (4) grease fittings in main frame, arrow 2, and two (2) grease fittings in each hydraulic cylinder, arrow 4 and 5. Arrow G indicates grease fitting location.
- Page 9 After adjustment is complete install bolt in cross tube and secure with nut. When attaching Ezee-A-Tach carrier frame on Model 2070 loader, secure the main frame to bottom pin “B” shown in ILL.
- Page 10 ASSEMBLY INSTRUCTIONS Continued: 10. CONNECTING HYDRAULIC SYSTEM - See ILL. 3. IMPORTANT: CLEANLINESS IS ABSOLUTELY NECESSARY TO PREVENT CONTAMINATION WHEN HOOKING UP HYDRAULIC COMPONENTS. HANDLE THE FITTINGS CAREFULLY. DO NOT REMOVE THE CAPS FROM THE PIPE AND HOSE ENDS UNTIL ALL FITTINGS ARE INSTALLED.
- Page 11 CONNECTING HYDRAULIC SYSTEM continued: d) Connect one (1) 3/8" x 46" hydraulic hose, arrow 5, to each side of 3/8" tee, arrow 6, on the #4 Oil Line. Then fasten the opposite end of each hose to the 3/8" female-female swivel adapter, arrow 2, on each bucket cylinder. e) Install one (1) 3/8"...
- Page 12 CONNECTING HYDRAULIC SYSTEM Continued: To mount the loader on the tractor, raise the rear of the yoke by extending the lift cylinders. Drive the tractor between the uprights of the yoke. Align mounting tubes on inside of yoke with mounting channel. Move tractor forward sliding yoke mounting tubes into mount channels until the mounting tubes lock behind latches.
-
Page 13: Operation
OPERATION 1. LOADER MOUNTING INSTRUCTIONS: TO MOUNT, THE LOADER MUST BE SITTING ON THE GROUND IN POSITION SHOWN ABOVE IN ILL.4. If the loader is sitting flat on ground, as shown in ILL.1, it can be raised into the position shown in ILL.4 by attaching the hydraulic lines to the tractor hydraulic system and extending the lift cylinders. - Page 14 3. EZEE-A-TACH SYSTEM (OPTIONAL) The EZEE-A-TACH system allows the operator to quickly install and remove attachment to and from loader. To install attachment proceed as follows: STEP 1 With the spring-loaded locking pins in the “UP” position and carrier tipped forward, drive the carrier between the brackets of the attachment.
- Page 15 OPERATION Continued: CAUTION: DO NOT TRY LIFTING LOADS BEYOND THE CAPACITY OF THE LOADER. POSSIBLE TRACTOR UPSET CAUSED BY TRACTOR INSTABILITY COULD RESULT IN SERIOUS INJURY OR DEATH TO THE OPERATOR AND SERIOUS DAMAGE TO THE LOADER AND TRACTOR. 6. IMPORTANT: DO NOT ATTEMPT TO LIFT A LOAD AT THE CORNER OF THE BUCKET.
- Page 16 MAINTENANCE & STORAGE 1. Check the hoses and oil lines periodically for signs of ruptures and leaks. CAUTION: ALWAYS USE A PIECE OF WOOD OR CARDBOARD AS A BACKSTOP AGAINST SPURTING FLUID. ALWAYS WEAR GLOVES AND EYE PROTECTION WHEN SEARCHING THE HYDRAULIC SYSTEM FOR LEAKS. HYDRAULIC FLUID ESCAPING UNDER PRESSURE CAN CAUSE PERSONAL INJURY BY PENETRATING SKIN.
- Page 17 MODEL 2070 PARTS INDEX PAGE H-Frame, Yoke, and Bucket Ezee-A-Tach System Hydraulic System Cylinder Parts Cylinder Seal Kits PAINT & DECALS PART QTY. DESCRIPTION REQ’D DF13002 Ezee-On Decals A75764 Read Manual Decal L3216 Falling Load Decal L014/L017 Caution Decal L015...
- Page 18 Page 16...
- Page 19 2070-4 Super Wide Yoke Assembly c/w 4 Pins LB1805 2070-2-Z Wide Yoke Assembly c/w 4 Pins - Zetor LB1804 2070-3-Z Extra Wide Yoke Assembly c/w 4 Pins - Zetor LB1795 Main Frame Assembly c/w 4 Pins LB1751 60" Bucket Assembly c/w 4 Pins (Standard) LB1757 72"...
- Page 20 EZEE-A-TACH SYSTEM - (Optional) REF. PART QTY. DESCRIPTION REQ'D LB2501 Model 2070 Loader Ezee-A-Tach Carrier c/w attaching pins and locking pins LA2533 Ezee-A-Tach Bracket - R.H. Side - Weld-On LA2534 Ezee-A-Tach Bracket - L.H. Side - Weld-On LA2507 Locking Pin L25103...
- Page 21 MODEL 2070 HYDRAULIC SYSTEM (FOR MODELS PRIOR TO SERIAL NO. 45175) REF. PART. QTY. DESCRIPTION REQ'D 255, 279 Lift Cylinder - See Cylinder Parts List instructions on page 21 272, 285 Bucket Cylinder - See Cylinder Parts List instructions on page 21...
- Page 22 MODEL 2070 HYDRAULIC SYSTEM (FOR MODELS WITH SERIAL NO #45175 & UP) REF. PART. QTY. DESCRIPTION REQ'D 255, 279 Lift Cylinder - See Cylinder Parts List instructions on page 21 Bucket Cylinder - See Cylinder Parts List instructions on page 21...
- Page 23 Part Number Part Description - Herd Plate, etc. 10 Means Fits Any Size of Cylinder 25 Means Used Most Commonly on 2-1/2" Cylinders 30 Means Used Most Commonly on 3" Cylinders MODEL 2070 CYLINDER SPECIFICATIONS CODE C.C. PARTS LIST DIAMETER...
- Page 24 HYDRAULIC BUCKET CYLINDER ASSEMBLY N4 TYPE (w/OIL LINE PORT) (FOR MODELS PRIOR TO SERIAL NO. 40100) REF. PART CYLINDER CODE DESCRIPTION 30TU10 Tube Assembly - 3" x 18" 10SH14 Shaft - 1-1/2" x 18" - w/1" stud 10OR21 O-Ring - 1" I.D. x 1-1/8" O.D. 30CU2 U-Cups - 2-1/2"...
- Page 25 HYDRAULIC BUCKET CYLINDER - N6 TYPE (W/OIL LINE PORT) (FOR MODELS WITH SERIAL NO# from 41251 to 43155) CYLINDER CODE REF. PART DESCRIPTION 30TU28 Tube Assembly - 3" x 18" - w/oil Line Port & 1-1/2" O.D. Cross Tube 10SH14 Shaft - 1-1/2"...
- Page 26 HYDRAULIC BUCKET CYLINDER N6 TYPE (W/OIL LINE PORT) (FOR MODELS WITH SERIAL NO. From 43156 to 45146) CYLINDER CODE REF. PART DESCRIPTION 30TU35 Tube Assembly - 3" x 18" - w/oil line 1-3/4" O.D. Cross tube 10SH14 Shaft - 1-1/2" x 18" w/1" Stub 10OR21 O-Ring - 1"...
- Page 27 HYDRAULIC BUCKET CYLINDER - Model 2070 N6 TYPE (W/90 DEGREE PORT) (FOR MODELS WITH SERIAL NO# 45147 & UP) CYLINDER CODE REF. PART DESCRIPTION 30TU36 Tube Assembly - 3" x 18" - Order N6 type w/90 deg. port 10SH14 Shaft - 1-1/2" x 18" w/1" Stub 10OR21 O-Ring - 1"...
- Page 28 HYDRAULIC LIFT CYLINDER ASSEMBLY N4 TYPE (FOR MODELS PRIOR TO SERIAL NO. 40695) REF. PART CYLINDER CODE DESCRIPTION 30TU26 Tube Assembly - 3" x 27" 10SH9 Shaft - 1-1/2" x 27" - w/3/4" stub 10OR9 O-Ring - 3/4" I.D. x 7/8" O.D. 30CU2 U-Cup - 2-1/2"...
- Page 29 HYDRAULIC LIFT CYLINDER ASSEMBLY N6TYPE (W/90 DEGREE PORT) REF. PART CYLINDER CODE DESCRIPTION 30TU26 Tube Assembly - 3" x 27" 10SH9 Shaft - 1-1/2" x 27" - w/3/4" stub 10OR9 O-Ring - 3/4" I.D. x 7/8" O.D. 30CU2 U-Cup - 2-1/2" I.D. x 3" O.D. x 3/8" 30PB2 Plunger Block - 3"...
- Page 30 HYDRAULIC LIFT CYLINDER- N6 TYPE (FOR MODELS WITH SERIAL NO. 40695 & UP) REF. PART CYLINDER CODE DESCRIPTION 30TU35 Tube Assembly - 3" x 27" - N6 Type 10SH9 Shaft - 1-1/2" x 27" - w/3/4" stub 100R9 O-Ring - 1"I.D. x 1-1/8" O.D.. 30CU2 U-Cups - 2-1/2"...
- Page 31 EZEE-ON CYLINDER REPAIR SEAL KIT CODES CODE 30 = 3" BORE PART NO. 3015HR - N4 N4 - Thread Type Head HR = Wear Ring in Head and Piston 15 = 1-1/2" Shaft CYLINDER SEAL KITS KIT NO. CONTENTS FITS CYLINDER CODE NO.
