- Page 1 EZEE-ON MODEL 2060 HEAVY DUTY LOADER OWNERS’ MANUAL PARTS LIST Manufactured Vegreville, Alberta EZEE-ON MANUFACTURING Canada Printed in Canada 712F...
- Page 2 Except as set forth above, Ezee-On Manufacturing shall have no obligation or liability of any kind on account of any of its equipment and shall not be liable for special or consequential damages.
- Page 3 3. If the equipment has been altered or repaired in a manner which, in the sole judgment of Ezee-On, affects its performance, stability or reliability. 4. The purchaser shall be responsible for dealer travel time to the machine or to deliver the machine to the dealer’s service shop for repair. Ezee-On Manufacturing does not cover delivery charges or travel time.
- Page 4 THANK YOU for choosing to purchase this Ezee-On implement, we are confident you will be impressed with its performance. In addition to the traditional values of simplicity, reliability and durability, your new EZEE-ON implement incorporates a number of operational and safety features.
- Page 5 LOADER SAFETY RECOMMENDATIONS Watch for this symbol. It identifies important safety messages. When you see this symbol, read the safety message carefully. GENERAL SAFETY 1. Never allow anyone to ride on any portion of the loader or tractor. The person may fall and be seriously or fatally injured. 2.
-
Page 6: Maintenance Safety
MAINTENANCE SAFETY 1. Do not disassemble or loosen hydraulic components when there is pressure within those components. Parts and fluid could fly out at a high velocity, resulting in serious injury. Always relieve the pressure in the hydraulic system. 2. Always use wood or cardboard as a backstop, and wear gloves and eye protection when searching the hydraulic system for leaks. Hydraulic fluid escaping under pressure can cause personal injury by penetrating the skin. -
Page 7: Operation Safety
TRANSPORT SAFETY CONTINUED: 3. Never transport the loader with the bucket (or any other attachment) in the "DUMP" position. If the hydraulic system failed, or if the hydraulic lever was accidentally operated, the loader will drop, causing the bucket (or attachment) to dig into the ground. This may result in serious injury or death to the operator and serious damage to the tractor and loader, especially if the tractor is moving at a high rate of speed. -
Page 8: Safety Decals
OPERATION SAFETY CONTINUED: 8. When raising a load, level attachment at higher lifting ranges to prevent material from falling on to tractor and/or operator. Falling material may cause serious injury or death to operator and serious damage to tractor and loader. 9. - Page 9 NOTE: Bucket teeth supplied include two (2) shorter teeth for the outside set of holes at each end of bucket blade. Face Port DOWN LOADER ASSEMBLY INSTRUCTIONS 1. Attach mount brackets to tractor, see instructions in the mount bolt package. Read the mount instructions carefully. Special adjustments or modifications may be required to adapt this loader to your tractor.
- Page 10 ASSEMBLY INSTRUCTIONS CONTINUED: 9. See ILL.1. Bolt the bucket teeth, arrow 9, to the top of the bucket blade with two (2) 7/16" x 2-1/4" carriage bolts c/w nuts and lockwashers for each tooth. Install the bolts from the bottom of the bucket. Install the teeth with the point facing DOWN. Six (6) teeth are required for the 54"...
-
Page 11: Lift Cylinder
ILL. 2 ILL. 2 LIFT CYLINDER LIFT CYLINDER 11(57") 9(64") 9(64") 7(27") 7(27") 11(57") 9(64") 9(64") 5(39") 5(39") 7(27") 7(27") BUCKET CYLINDER BUCKET CYLINDER ITEM DESCRIPTION 3/8" x 90 Degree Swivel Street Elbow 3/8" Male-Female Swivel Adapter 3/8" x 90 Degree Swivel Adapter 3/8"... - Page 12 ASSEMBLY CONTINUED: ILL. 3 CAUTION: BE SURE ALL HYDRAULIC CYLINDERS ARE COMPLETELY FILLED WITH HYDRAULIC FLUID TO AVOID LOADER FREE FALL OR SUDDEN MOVEMENT. IF THE CYLINDERS ARE NOT COMPLETELY FILLED, THE LOADER WILL DROP. Lift Cylinder Extend the lift cylinders. This will raise the loader into the mounting position, as shown in ILL.3.
-
Page 13: Operation
ILL. 4 lLL. 5 ILL. 6 Yoke Assembly Lift Cylinder OPERATION 1. LOADER MOUNTING INSTRUCTIONS: TO MOUNT, THE LOADER MUST BE SITTING ON THE GROUND, IN THE POSITION SHOWN ABOVE IN ILL.4. If the loader is sitting flat on the ground, as shown in ILL.1, raise it into the position shown in ILL.4 by attaching the hydraulic lines to the tractors’... - Page 14 OPERATION CONTINUED: CAUTION: KEEP THE LOADER ARMS IN A LOW POSITION DURING TRANSPORT AT ALL TIMES, ESPECIALLY WHEN CARRYING A LOAD. CARRYING THE LOADER IN A RAISED POSITION WILL DECREASE TRACTOR STABILITY, RESULTING IN POSSIBLE TRACTOR UPSET CAUSING SERIOUS DAMAGE TO THE LOADER AND TRACTOR, AND SERIOUS INJURY OR DEATH TO YOU OR THOSE NEARBY.
- Page 15 OPERATION CONTINUED: CAUTION: ADD NECESSARY WHEEL BALLAST OR REAR WEIGHTS TO INCREASE TRACTOR STABILITY. CAUTION: MOVE THE TRACTOR WHEELS TO THEIR WIDEST POSSIBLE SETTING TO INCREASE TRACTOR STABILITY. CAUTION: NEVER ALLOW ANYONE TO RIDE ON ANY PORTION OF THE LOADER OR TRACTOR. THE PERSON RIDING COULD FALL AND BE SERIOUSLY INJURED.
- Page 16 MAINTENANCE & STORAGE CONTINUED: 2. When the loader is dismounted from the tractor and is sitting on the ground, contract all the hydraulic cylinders to protect the cylinder shafts from the weather and possible accidental damage. 3. Keep the mounting bracket and bucket teeth bolts tights and be sure all loader pins are secured with cotter pins. CAUTION: DO NOT SERVICE OR ADJUST THE LOADER WHILE THE TRACTOR AND LOADER ARE IN OPERATION.
- Page 17 Cylinder Repair Seal Kit Code Cylinder Seal Kit PAINT & DECALS PART QTY. DESCRIPTION REQ’D L415 Ezee-On Decal (8-1/2" x 1-1/2") L732 “2060” Model Number Decal L014/L017 Loader Caution Decal – (5-3/4” x 7-7/8”) A75764 “Read Manual Decal” – (2-5/16” x 4-1/2”) L3216 “Falling Load Decal”...
- Page 18 2060-1 Narrow Yoke Assembly c/w Pins LB723 2060-2 Wide Yoke Assembly c/w Pins LB724 2060-3 Extra Wide Yoke Assembly c/w Pins LB725 2060-4 Super Wide Yoke Assembly c/w 4 Pins LB721 2060 Main Frame Assembly c/w Pins LB695 54" Bucket Less Teeth LB696 60"...
-
Page 19: Hydraulic System
HYDRAULIC SYSTEM (S/N - 45493 and Prior) REF. PART QTY. DESCRIPTION REQ’D 2-1/4" x 24" Lift Cylinders - See Cylinder Parts List (Instructions on Page 18) 2" x 12" Bucket Cylinders - See Cylinder Parts List (Instructions on Page 18) L728 Bottom 1 Hydraulic Oil Line L729... - Page 20 HYDRAULIC SYSTEM (S/N - 45494 and After) REF. NO. PART NO. DESCRIPTION QTY. REQ’D 2-1/4" x 24" Lift Cylinders - See Cylinder Parts List (Instructions on Page 18) 2" x 12" Bucket Cylinders - See Cylinder Parts List (Instructions on Page 18) L728 Bottom 1 Hyrdaulic Oil Line L729...
- Page 21 Part Number Part Description - Wiper Seal, etc. 10 Means Fits Any Size of Cylinder 20 Means Used Most Commonly on 2" Cylinders 22 Means Used Most Commonly on 2-1/4" Cylinders MODEL 2060 CYLINDER SPECIFICATIONS CODE C.C. SHAFT DIAMETER STROKE...
- Page 22 BUCKET CYLINDER - 2" x 12" (N5) A – Cup TYPE – (#155) QTY. REQ’D REF. NO. PART NO. DESCRIPTION 20TU28 Tube Assembly - 2" x 12" - (Oil Line Type) 10SH15 Shaft - 1" x 12" 10OR9 O-Ring - 1/16" x 7/8" O.D. 20FP2 Filler Plate - With Machined Seat For O-Ring 20CU1...
- Page 23 LIFT CYLINDER - 2-1/4" x 24" (N6) – U-Cup TYPE – (#284) BUCKET CYLINDER - 2" x 12" (N5) – U-Cup TYPE – (#314) QTY. REQ’D REF. NO. PART NO. DESCRIPTION 20TU37 Tube Assembly – 2” x 12” 22TU2 Tube Assembly – 2-1/4” x 24” 10SH15 Shaft –...
- Page 24 EZEE - ON CYLINDER REPAIR SEAL KIT CODES CODE 20 = 2" bore 22 = 2-1/4" bore PART NO. 2015N5 N5 = threaded head type N6 = threaded head type 10 = 1" shaft 15 = 1-1/2" shaft CYLINDER SEAL KIT KIT NO.
