Ezee-On 2080S Owner's Manual

Front-end loader
Hide thumbs

Advertisement

Quick Links

Download this manual
EZEE-ON
MODEL
2080S-2080
2085S-2085
FRONT-END LOADER
OWNERS' MANUAL
and
PARTS LIST
Manufactured
Vegreville, Alberta
Ezee-On Mfg. Ltd.
by
Canada
Printed in Canada
645C

Advertisement

loading
Need help?

Need help?

Do you have a question about the 2080S and is the answer not in the manual?

Questions and answers

Related Manuals for Ezee-On 2080S

Summary of Contents for Ezee-On 2080S

  • Page 1 EZEE-ON MODEL 2080S-2080 2085S-2085 FRONT-END LOADER OWNERS’ MANUAL PARTS LIST Manufactured Vegreville, Alberta Ezee-On Mfg. Ltd. Canada Printed in Canada 645C...
  • Page 2 This warranty is void if equipment is used for other than agricultural purposes. The sole obligation of EZEE- ON under this warranty is limited to the repair or replacement of those part(s) (F.O.B. EZEE-ON Factory) of the equipment which EZEE-ON in its sole discretion, determines to have failed as a result of defects in material or workmanship occurring prior to the expiration of one year ("Warranty Period") from delivery by EZEE-ON or its selling dealer ("Dealer") to the original purchaser ("Purchaser").
  • Page 3 PARTS EZEE-ON MFG. LTD. RESERVES THE RIGHT to make improvements in design and changes in specifications at any time without notice and without incurring any obligation to install them on units previously sold. Specifications, descriptions, and illustrative material herein are as accurate as known at time of publication, but are subject to change without notice.

  • Page 4: General Safety

    LOADER SAFETY RECOMMENDATIONS Watch for this symbol. It identifies important safety messages. When you see this symbol, read the safety message carefully. GENERAL SAFETY 1. Never allow anyone to ride on any portion of the loader or tractor. The person may fall and be seriously or fatally injured. 2.

  • Page 5: Maintenance Safety

    MAINTENANCE SAFETY 1. Do not disassemble or loosen hydraulic components when there is pressure within those components. Parts and fluid could fly out at a high velocity, resulting in serious injury. Always relieve the pressure in the hydraulic system. 2. Always use wood or cardboard as a backstop, and wear gloves and eye protection when searching the hydraulic system for leaks. Hydraulic fluid escaping under pressure can cause personal injury by penetrating the skin.

  • Page 6: Operation Safety

    TRANSPORT SAFETY CONTINUED: 3. Never transport the loader with the bucket (or any other attachment) in the "DUMP" position. If the hydraulic system failed, or if the hydraulic lever was accidentally operated, the loader will drop, causing the bucket (or attachment) to dig into the ground. This may result in serious injury or death to the operator and serious damage to the tractor and loader, especially if the tractor is moving at a high rate of speed.

  • Page 7: Safety Decals

    OPERATION SAFETY CONTINUED: 8. When raising a load, level attachment at higher lifting ranges to prevent material from falling on to tractor and/or operator. Falling material may cause serious injury or death to operator and serious damage to tractor and loader. 9.
  • Page 8 Arrow "G" indicates location of grease fitting. IMPORTANT: The Ezee-A-Tach carrier frame for 2085 or 2085S loaders will not work if pinned on 2080 or 2080S loaders. Severe damage will occur to bucket cylinder if wrong carrier is installed. Page 6...
  • Page 9 17), all pin to the main frame using the bottom holes. Secure each pin with (1) one 1/4" x 1-1/2" cotter pin. EZEE-A-TACH CARRIER (Optional) - See ILL. 3 and 4. When attaching Ezee-A-Tach carrier frame on Model 2080 and 2080S loaders, secure the main frame to bottom pin "B"...
  • Page 10 See ILL. 2. Model 2080-2080S - Attach two (2) lift cylinders, arrow 6, with the tube end attached to centre pin, arrow 7, on each side of main frame. Attach the shaft end of each lift cylinder to bottom pin, arrow 8, on the yoke assembly. The shaft end ports on the cylinders must be facing up.
  • Page 11 ASSEMBLY INSTRUCTIONS CONTINUED: ILL. 5 (MODEL 2085S-2085) 10. CONNECTING HYDRAULIC SYSTEM - MODEL 2085-2085S - See ILL. 5 IMPORTANT: CLEANLINESS IS ABSOLUTELY NECESSARY TO PREVENT CONTAMINATION WHEN HOOKING UP HYDRAULIC COMPONENTS. HANDLE THE FITTINGS CAREFULLY. DO NOT REMOVE THE CAPS FROM THE PIPE AND HOSE ENDS UNTIL ALL FITTINGS ARE INSTALLED.
  • Page 12 ASSEMBLY INSTRUCTIONS CONTINUED: Model 2085 - See ILL 5. Connect one (1) 3/8" x 60" hydraulic hose, arrow 5, to the 3/8" tee, arrow 6, on the #2 oil line at the centre of the main frame. Then fasten the opposite end to the 3/8" x 90 degree swivel street elbow, arrow 1, on the lift cylinders.
  • Page 13 Model 2080S - See ILL. 6. Connect one (1) 3/8" x 63" hydraulic hose, arrow 3, to each side of 3/8" tee, arrow 4, on the #1 oil line. Then fasten the opposite end of each hose to the 3/8" male-female swivel, arrow 2, on each lift cylinder. Thread hose as shown.
  • Page 14 Thread hose as shown. Model 2080S - See ILL. 6. Connect one (1) 3/8" x 32" hydraulic hose, arrow 5, to each side of 3/8" tee, arrow 6, on the #2 oil line. Then fasten the opposite end of each hose to the 3/8" x 90 degree swivel street elbow, arrow 1, on each lift cylinder.
  • Page 15 ASSEMBLY INSTRUCTIONS CONTINUED: CAUTION: BE SURE ALL HYDRAULIC CYLINDERS ARE COMPLETELY FILLED WITH HYDRAULIC FLUID TO AVOID LOADER FREE- FALL OR SUDDEN MOVEMENT. IF THE CYLINDERS ARE NOT COMPLETELY FILLED, THE LOADER WILL DROP. 12) Extend the lift cylinders. This will raise the loader into the mounting position, as shown in ILL.

  • Page 16: Operation

    OPERATION 1. LOADER MOUNTING INSTRUCTIONS: TO MOUNT, THE LOADER MUST BE SITTING ON THE GROUND IN THE POSITION SHOWN ABOVE IN ILL. 8. If the loader is sitting flat on ground, as shown in ILL. 1 and 2, it can be raised into the position shown in ILL. 8, by attaching the hydraulic hoses to the tractor hydraulic system and extending the lift cylinders.
  • Page 17 OPERATION CONTINUED: 3. EZEE-A-TACH SYSTEM (OPTIONAL) The EZEE-A-TACH system allows the operator to quickly install (or remove) attachment onto (or from) loader. To install attachment proceed as follows: STEP 1: See ILL. 11. With the spring-loaded locking pins in the "UP" position and carrier tipped forward, drive the carrier between the brackets of the attachment.
  • Page 18 OPERATION CONTINUED: CAUTION: MOVE AND TURN THE TRACTOR AT LOW SPEEDS. OPERATING THE TRACTOR AT HIGH SPEEDS REDUCES TRACTOR STABILITY, CAUSING POSSIBLE TRACTOR UPSET WHICH COULD RESULT IN SERIOUS INJURY OR DEATH TO THE OPERATOR AND SERIOUS DAMAGE TO THE LOADER AND TRACTOR. CAUTION: NEVER STAND UNDER ANY PART OF THE LOADER OR ATTACHMENT WHEN THE LOADER ARMS ARE IN A RAISED POSITION.
  • Page 19 Adjust level indicator, arrow 3, so top end is flush with top side of rod support, arrow 4. NOTE: Model 2080 and 2080S loader is shown in ILL. 14. The level indicator for Model 2085 and 2085S loaders are adjusted using the same procedure.
  • Page 20 MAINTENANCE and STORAGE 1. Check the hoses and oil lines periodically for signs of ruptures and leaks. CAUTION: ALWAYS USE A PIECE OF WOOD OR CARDBOARD AS A BACKSTOP AGAINST SPURTING FLUID. ALWAYS WEAR GLOVES AND EYE PROTECTION WHEN SEARCHING THE HYDRAULIC SYSTEM FOR LEAKS. HYDRAULIC FLUID ESCAPING UNDER PRESSURE CAN CAUSE PERSONAL INJURY BY PENETRATING SKIN.
  • Page 21 PARTS INDEX PAGE 2085 - 2085S H-FRAME, YOKE, BUCKET 2080 - 2080S H-FRAME, YOKE, BUCKET EZEE-A-TACH SYSTEM HYDRAULIC SYSTEM CYLINDER PARTS LIST CYLINDER SEAL KITS PAINT & DECALS PART QTY. DESCRIPTION REQ'D DF13002 EZEE-ON DECAL - 2-1/2" x 15-1/2" A75764 READ MANUAL DECAL - 2-5/16"...
  • Page 22 MODEL 2085-2085s Page 20...
  • Page 23 MODEL 2085-2085S LOADER PARTS LIST REF. PART QTY. DESCRIPTION REQ'D LB3411 2085S-1 Yoke Assembly - Narrow Yoke c/w pins LB3410 2085S-2 Yoke Assembly - Wide Yoke c/w pins LB3409 2085S-3 Yoke Assembly - Extra Wide Yoke c/w pins LB3408 2085S-4 Yoke Assembly - Super Wide Yoke c/w pins LB3315 2085-1 Yoke Assembly -Narrow Yoke c/w pins LB3316...
  • Page 24 MODEL 2080-2080s Page 22...
  • Page 25 REF. PART QTY. DESCRIPTION REQ'D LB3448 2080S-1 Yoke Assembly - Narrow Wide Yoke c/w pins LB3447 2080S-2 Yoke Assembly - Wide Yoke c/w pins LB3446 2080S-3 Yoke Assembly - Extra Wide Yoke c/w pins LB3445 2080S-4 Yoke Assembly - Super Wide Yoke c/w pins...
  • Page 26 REQ'D LB2514 Model 2085-2085S Loader Ezee-A-Tach Carrier c/w attaching pins and locking pins LB2513 Model 2080-2080S Loader Ezee-A-Tach Carrier c/w attaching pins and locking pins LA2508 Ezee-A-Tach Bracket - R.H. Side - Weld-On LA2509 Ezee-A-Tach Bracket - L.H. Side - Weld-On...
  • Page 27 REQ'D 279, 313 Lift Cylinder - See Cylinder Parts List instructions on page 28 272, 285 Bucket Cylinder - 2080S-2080 - See Cylinder Parts List instructions on page 28 L3325 Bottom 1 Hydraulic Oil Line (2080) L3434 Bottom 1 Hydraulic Oil Line (2080S)
  • Page 28 QTY. DESCRIPTION REQ'D Lift Cylinder - See Cylinder Parts List instructions on page 28 Bucket Cylinder - (2080S-2080) See Cylinder Parts List instructions on page 28 L3325 Bottom 1 Hydraulic Oil Line (2080) L3434 Bottom 1 Hydraulic Oil Line (2080s)
  • Page 29 MODEL 2085-2085S HYDRAULIC PARTS LIST REF. PART. QTY. DESCRIPTION REQ'D 279, 313 Lift Cylinder - See Cylinder Parts List instructions on page 28 Bucket Cylinder - (2085S-2085) See Cylinder Parts List instructions on page 28 L3325 Bottom 1 Hydraulic Oil Line (2085) L3434 Bottom 1 Hydraulic Oil Line (2085S) L3326...
  • Page 30 EZEE-ON LOADER CYLINDER PARTS LIST 1. Identify cylinder code number by matching up diameter, stroke, application and type from list below. 2. Once the code number has been established then locate cylinder parts list further in book and use correct reference number and cylinder code column to locate part number.
  • Page 31 HYDRAULIC LIFT CYLINDER - N4 TYPE W/OIL LINE PORT MODEL 2080-2080S (FOR MODELS PRIOR TO SERIAL NO. 40100) CYLINDER CODE PART DESCRIPTION 30TU10 Tube Assembly - 3" x 18" 10SH14 Shaft - 1-1/2" x 18" w/ 1" Stub 100R21 O-Ring - 1" I.D. x 1-1/8" O.D.
  • Page 32 HYDRAULIC BUCKET CYLINDER - Model 2080-2080S N6 TYPE (W/OIL LINE PORT) (FOR MODELS WITH SERIAL NO# from 40100 to 43155) CYLINDER CODE REF. PART DESCRIPTION 30TU28 Tube Assembly - 3" x 18" - w/oil Line Port & 1-1/2" O.D. Cross Tube 10SH14 Shaft - 1-1/2"...
  • Page 33 HYDRAULIC BUCKET CYLINDER - Model 2080-2080S N6 TYPE (W/OIL LINE PORT) (FOR MODELS WITH SERIAL NO. From 43156 to 45146) CYLINDER CODE REF. PART DESCRIPTION 30TU35 Tube Assembly - 3" x 18" - w/oil line ports - 1-3/4" O.D. Cross tube 10SH14 Shaft - 1-1/2"...
  • Page 34 HYDRAULIC BUCKET CYLINDER - MODEL 2080-2080S N6 TYPE (W/90 DEGREE PORT) (FOR MODELS WITH SERIAL NO. 45146 & UP) CYLINDER CODE REF. PART DESCRIPTION 30TU36 Tube Assembly - 3" x 18" - w/ 90 deg. port and 1-3/4" O.D. Cross Tube 10SH14 Shaft - 1-1/2"...
  • Page 35 HYDRAULIC BUCKET CYLINDER - N4 TYPE MODEL 2085-2085S CYLINDER CODE REF. PART DESCRIPTION 30TU25 Tube Assembly - 3" x 19-1/2" (2085-2085S) 10SH43 Shaft - 1-1/2" x 19-1/2" w/ 1" Stub (2085-2085S) 100R21 O-Ring - 1" I.D. x 1-1/8" O.D. 30CU2 U-Cups - 2-1/2"...
  • Page 36 HYDRAULIC LIFT CYLINDER - N4 TYPE MODEL 2080-2080s-2085-2085s (FOR MODELS PRIOR TO SERIAL NO. 40695) CYLINDER CODE REF. PART DESCRIPTION 30TU35 Tube Assembly - 3" x 27" - N4 Type 10SH14 Shaft - 1-1/2" x 27" - w/3/4" Stub 100R9 O-Ring - 3/4"...
  • Page 37 HYDRAULIC LIFT CYLINDER - N6 TYPE MODEL 2080-2080s-2085-2085s (FOR MODELS WITH SERIAL NO. 40695 & UP) CYLINDER CODE REF. PART DESCRIPTION 30TU35 Tube Assembly - 3" x 27" - N6 Type 10SH9 Shaft - 1-1/2" x 27" - w/3/4" Stub 100R9 O-Ring - 1"...
  • Page 38 EZEE-ON CYLINDER REPAIR SEAL KIT CODES CODE 30 = 3" BORE PART NO. 3015HR - N4 N4 - Thread Type Head HR = Wear Ring in Head and Piston 15 = 1-1/2" Shaft CYLINDER SEAL KITS KIT NO. CONTENTS FITS CYLINDER CODE NO.
