Winward Umbrella Coffee Table
SKU 642706
Thank you for your purchase. If you have any questions pertaining to the assembly of this
furniture piece, please contact the nearest World Market store. If you are not near a store,
please call our customer service call center toll free at 877-967-5362 for assistance.
2024.09.17
PAGE 1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for World Market Winward 642706
Summary of Contents for World Market Winward 642706
- Page 1 Thank you for your purchase. If you have any questions pertaining to the assembly of this furniture piece, please contact the nearest World Market store. If you are not near a store, please call our customer service call center toll free at 877-967-5362 for assistance.
-
Page 2: Tool List
TABLE LIDS TABLE PANELS BOTTOM SHELF ALLEN BOLT 6x30mm INSERT NUT Ø6x18mm Tool List LABEL QTY. ALLEN KEY PAGE 2... -
Page 3: Assembly Preparation
Assemble on a clean non-marring surface (such as the product’s packing foam). Do not discard any packaging until the product has been fully assembled. In case of missing parts, please contact your nearest World Market store or call our customer service call center at 1-877-967-5362. -
Page 4: Assembly Steps
Assembly Steps Step 1 (H-1) SHORT ALLEN BOLT x4 (H-2) INSERT NUT x4 (T-1) ALLEN KEY x2 Place two Table Panels (B) together onto a padded, non-marring surface as shown. Align the holes and secure by first inserting the Short Allen Bolts (H-1) and Insert Nuts (H-2) into opposite sides of the connecting through holes and engaging together. - Page 5 Assembly Steps Step 3 One at a time, insert the Bottom Shelves (C) so that they rest on the pre-installed cleats inside the assembly. One at a time, place each Table Lid (A) onto the upper rim of the assembly, careful not to pinch your fingers. Step 4 ADJUSTABLE LEVELER Levelers are located on the bottom of each leg and...
- Page 6 Assembly Steps How to use this table with an umbrella stand and pole Remove the Table Lids (A) and Bottom Shelves (C). Using a second person to assist you, carefully lift the assembly directly over your umbrella stand (sold separately) and lower, centered with the stand.
- Page 7 Storage compartment is NOTweatherproof. Use the compartment for TEMPORARY protection from the elements only. DO NOT leave items in the compartment for extended periods of time unless also using a furniture cover during cold or inclement weather events PAGE 7...
- Page 8 Customer Service Call Center, Toll Free at 877-967-5362. For valid warranty claims, World Market will repair or replace the product, or offer a full or par�al credit, in the sole discre�on of World Market. This LIMITED ONE-YEAR WARRANTY gives you specific legal rights and you may also have other rights which vary from state to state.
