Summary of Contents for Bosch PI 75N14E Series

  • Page 1 All manuals and user guides at all-guides.com EN Instruction manual...
  • Page 2 All manuals and user guides at all-guides.com PI..75N14E 400x210/ 400x210/ 400x210/ Ø 14,5 382x200 382x200 382x200 Ø 21 400x210/ Ø 28 382x200 Ø 14,5 Ø = cm...

  • Page 3: Table Of Contents

    All manuals and user guides at all-guides.com Table of contents Safety information ......Safety instructions .
  • Page 4 All manuals and user guides at all-guides.com Table of contents Timer function ......Automatic hotplate switch off .

  • Page 5: Safety Information

    All manuals and user guides at all-guides.com Safety information Read these instructions carefully. Only after doing this will you be able to operate your appliance properly. Keep the operating and assembly instructions in a safe place. If the appliance is given to another person, ensure the appliance documentation is also included.
  • Page 6 All manuals and user guides at all-guides.com Cooking using a water bath involves cooking food Cooking using a water bath inside a pot which is in turn placed in another larger pan which contains water. In this way, the food is heated gently and constantly and it is the hot water, not the direct heat of the hotplate, which cooks the food.
  • Page 7 All manuals and user guides at all-guides.com Risk of burns! Do not leave cutlery, lids or other metal Do not place metal objects on the induction hob objects on the hob as they can heat up very quickly. This hob is fitted with a fan in the lower section. Taking care of the cooling Risk of malfunction! If a drawer is fitted beneath the hob you must not keep small objects or paper in it as,...

  • Page 8: Causes Of Damage

    All manuals and user guides at all-guides.com Causes of damage Rough pot and pan bases scratch the ceramic. Bases of pots and pans Avoid boiling pots dry. This may cause damage. Never place hot pots or pans on the control panel, Hot pots and pans the display area or the surround.

  • Page 9: Environmental Protection

    All manuals and user guides at all-guides.com Environmental protection Environmentally Unpack the appliance and dispose of the packaging friendly disposal in an environmentally responsible manner. This appliance is labelled in accordance with European Directive 2002/96/EU on Waste Electrical and Electronic Equipment WEEE. The directive provides a framework for the collection and recycling of old appliances, which is valid across the EU.

  • Page 10: Induction Cooking

    All manuals and user guides at all-guides.com Induction cooking Advantages of Induction cooking involves a radical change to the induction cooking traditional method of heating, as the heat is generated directly in the pan. For this reason, it offers a number of advantages: Greater speed in cooking and frying;...
  • Page 11 All manuals and user guides at all-guides.com To find out whether the pans are suitable, check that Checking pans using a magnet they are attracted to a magnet. The manufacturer will usually indicate if their pans are suitable for induction cooking. Never use pans made from: Unsuitable pans standard, high quality steel...

  • Page 12: Getting To Know Your Appliance

    All manuals and user guides at all-guides.com These areas can detect pans of different sizes. The Double or triple hotplate area will automatically adapt, depending on the pan material and its properties, activating only a single area or an entire area and supplying the right level of power for best cooking results.

  • Page 13: The Hotplates

    All manuals and user guides at all-guides.com The hotplates Hotplate Turning on and off Single hotplate Always use cookware of a suitable size. û Flexible zone See the section on the flexible zone m Cooking zone This zone is switched on automatically when using cookware whose base is the same size as the outer zone.

  • Page 14: Programming The Hob

    All manuals and user guides at all-guides.com Programming the hob This section shows how to adjust a hotplate. The table gives the settings and cooking times for various dishes. Switching the hob Switch the hob on and off using the main switch. on and off To switch on: touch the # symbol.

  • Page 15: Cooking Table

    All manuals and user guides at all-guides.com To change the heat setting: Select the hotplate and Switching off the hotplate then press the symbol for the required heat setting. Warning: The selected heat setting will flash if no pan is placed on the induction hotplate.
  • Page 16 All manuals and user guides at all-guides.com Slow cooking Duration of level slow cooking in minutes Simmering, bringing to the boil over a low heat Potato dumplings 4. 5.* 20 30 min Fish 4 5* 10 15 min White sauces, e.g. béchamel 3 6 min Emulsions, e.g.
  • Page 17 All manuals and user guides at all-guides.com Slow cooking Duration of level slow cooking in minutes Frying** (150 g 200 g per portion in 1 2 l of oil) Frozen food, e.g. chips, chicken nuggets fry in batches Frozen croquettes Dumplings Meat, e.g.

  • Page 18: Flexible Zone

    All manuals and user guides at all-guides.com Flexible zone This may be used as a single zone or as several individual zones, depending on the cooking needs at any given time. It consists of several independently controlled It works as follows inductors.

  • Page 19: As Two Hotplates

    All manuals and user guides at all-guides.com Select the hotplate and press the Ô symbol. How to deactivate As two hotplates The flexible zone can be used as two independent hotplates. The hob must be switched on. How to activate 1.

  • Page 20: Switching The Permanent Childproof Lock On And Off

    All manuals and user guides at all-guides.com Switching the permanent childproof lock on and off Using this function, the childproof lock is activated automatically whenever the hob is disconnected. See the section on Basic settings". Switching the permanent childproof lock on and off Press the D until the beep sounds and the D Switching the hob on...

  • Page 21: How To Activate It

    All manuals and user guides at all-guides.com How to activate it Follow the steps below: 1. Select a hotplate. 2. Press the boost± symbol. You have now activated the function. How to deactivate it Follow the steps below: 1. Select a hotplate. 2.
  • Page 22 All manuals and user guides at all-guides.com The hotplate must be selected and set. Setting a cooking time 1. Touch the 0 symbol twice. The ‹ indicator for the desired hotplate lights up. The r symbol appears and ‹‹ lights up in the timer display.

  • Page 23: Kitchen Timer

    All manuals and user guides at all-guides.com Kitchen timer You can use the kitchen timer to set a time of up to 99 minutes. It runs independently of all the other settings. 1. Touch the 0 symbol, the U indicator for the Setting procedure kitchen timer lights up.

  • Page 24: Automatic Time Limit

    All manuals and user guides at all-guides.com Automatic time limit If a hotplate is in use for a long time without the setting being changed, the automatic time limit is activated. The hotplate stops heating. F and 8 flash alternately on the hotplate display.

  • Page 25: Changing The Basic Settings

    All manuals and user guides at all-guides.com b = 1000 W minimum power Power Management Function b. - i. = from 1500 to 8500w This limits the total power j = 9000W maximum power of the hob. There are 17 setting levels. Increasing the setting level increases the power of the hob by 500 W.

  • Page 26: Care And Cleaning

    All manuals and user guides at all-guides.com 4. Set the desired value on the control panel. 5. Touch the j symbol for 4 seconds. The setting is activated. To exit the basic setting, switch off the hob with the Switching off main switch and make new settings.

  • Page 27: Hob Surround

    All manuals and user guides at all-guides.com Never use: Abrasive products Aggressive cleaning products, such as stain removers and oven sprays Sponges which may scratch High-pressure cleaners or steam cleaners Remove stubborn dirt with a glass scraper. Glass scrapers 1. Remove the guard from the scraper 2.

  • Page 28: Fixing Malfunctions

    All manuals and user guides at all-guides.com Fixing malfunctions Malfunctions are generally caused by minor faults. Before contacting Technical assistance, ensure you have read the following recommendations and warnings. Display Malfunction Measure none The electric power supply Use other electrical appliances to check if there has been has been interrupted.

  • Page 29: Normal Noises Heard During Appliance Operation

    All manuals and user guides at all-guides.com Display Malfunction Measure Incorrect supply voltage, Please contact the local electricity board. outside normal operating limits {c/{d The hotplate has Wait until the electronic system has cooled down overheated and has sufficiently before switching the hob back on. switched off in order to protect the hob Do not rest hot pans on the control panel.

  • Page 30: After Sales Service

    All manuals and user guides at all-guides.com To run the electronic system properly, the cooking Noise from the fan hob must operate at a controlled temperature. To do this, the cooking hob is fitted with a fan which comes on after each temperature detected using different power levels.
  • Page 31 All manuals and user guides at all-guides.com DE http://www.bosch hausgeraete.de GB http://www.boschappliances.co.uk FR http://www.bosch electromenager.com NL http://www.bosch huishoudelijke apparaten.ni http://www.bosch kodinkoneet.com DK http://www.bosch hvidevarer.com ES http://www.bosch ed.com PT http://www.bosch.pt BE http://www.electro.bosch.be AU http://www.bosch.com.au AT http://www.bosch hausgeraete.at BR http://www.boschelectrodomesticos.com.br GR http://www.bosch home.gr US http://www.bosch appliances.com...
