MAINTENANCE
WARNING
1. Disconnect power supply before making wiring connections
or working on this equipment. Follow all applicable safety
procedures to prevent accidental power up. Failure to do
so can result in injury or death from electrical shock or
moving parts and may cause equipment damage.
2. When servicing or repairing this equipment, use only
factory-approved service replacement parts. A complete
replacement parts list may be obtained by contacting
the factory. Refer to the rating plate on the appliance for
complete appliance model number, serial number, and
company address. Any substitution of parts or controls not
approved by the factory will be at the owner's risk.
AVERTISSEMENT
1. Débranchez l'alimentation électrique avant d'effectuer
des connexions ou de travailler sur l'appareil. Respectez
toutes les procédures de sécurité qui s'appliquent pour
éviter toute mise en marche accidentelle. Le non-respect
de cette directive peut entraîner des blessures ou la mort
causées par un choc électrique ou des pièces mobiles, en
plus d'endommager l'appareil.
2. Pour l'entretien et les réparations de cet appareil, utilisez
uniquement des pièces d'origine certifiées. Pour la liste
complete des pièces de rechange, consultez Modine
Manufacturing Company. Le numéro de modèle complet,
le numéro de série et l'adresse du fabricant figurent sur la
plaque signalétique fixée à l'appareil. Toute substitution de
pièce ou decommande non approuvée par le fabricant sera
aux risques du propriétaire.
CAUTION
1. Do not attempt to reuse any mechanical or electrical
component which has been wet. Such component must be
replaced.
2. When servicing the unit, some components may be hot
enough to cause pain or injury. Allow time for cooling of hot
components before servicing.
ATTENTION
1. Ne tentez pas de réutiliser un composant mécanique ou
électrique qui a été mouillé. Ces composants doivent être
remplacés.
2. Durant l'entretien de l'unité, certains composants peuvent
être assez chauds pour causer de la douleur ou une
blessure. Laissez les composants chauds se refroidir avant
de procéder à tout entretien.
30
IMPORTANT
1. Start up and adjustment procedures, installation, and
service of these appliances must be performed by a
qualified installation and service agency.
2. No water-flow can cause a freeze condition resulting in
damage to the coil.
3. To check most of the Possible Remedies in the
troubleshooting guide listed in Table 30.1, refer to the
applicable sections of the manual.
IMPORTANT
1. Les procédures de démarrage et de réglage, l'installation
et le service de ces appareils doivent être confiés à un
centre d'installation et de service qualifié.
2. L'absence d'écoulement d'eau risque de causer une
condition de gel et d'endommager le serpentin.
3. Pour essayer la plupart des solutions possibles suggérées
dans le guide de dépannage du
aux sections correspondantes du manuel.
The routine care and maintenance of this unit will increase
longevity, provide for the proper operational performance, and
reduce the probability of failure.
Once the unit is operational, it will be necessary to perform
certain routine maintenance/service checks. Following is a
Maintenance Schedule with the recommended checks. If your
unit is equipped with special features, there may be additional
checks that are required. Consult Modine for assistance.
The use of torque screwdrivers on panel, cover or component
mounting screws is not recommended. Hand-start all screws.
If electric drills are used – set at the lowest possible torque.
Any time the refrigerant system is opened, the Filter Drier and
Sight Glass should be replaced.
Precautions for Work with Flammable
Refrigerant
Prior to beginning work on systems containing FLAMMABLE
REFRIGERANTS, safety checks are necessary to ensure that
the risk of ignition is minimized.
1. Work shall be undertaken under a controlled procedure so
as to minimize the risk of a flammable gas or vapor being
present while the work is being performed.
2. All maintenance staff and others working in the local area
shall be instructed on the nature of work being carried out.
Work in confined spaces shall be avoided.
3. The area shall be checked with an appropriate refrigerant
detector prior to and during work, to ensure the technician
is aware of potentially toxic or flammable atmospheres.
Ensure that the leak detection equipment being used is
suitable for use with all applicable refrigerants.
4. If any hot work is to be conducted on the refrigerating
equipment or any associated parts, appropriate fire
extinguishing equipment shall be available to hand. Have
a dry powder or CO2 fire extinguisher adjacent to the
charging area.
5. No person carrying out work in relation to a refrigeration
system which involves exposing any pipe work shall use
any sources of ignition in such a manner that it may lead
to the risk of fire or explosion. All possible ignition sources,
including cigarette smoking, should be kept sufficiently far
AIR 2-504.0
Table 30.1, reportez-vous
