Majestic LOGSMER36 Placement Instructions

Log Set Assembly: LOGSMER36
Models: MER36PN, MER36PL, MER36N, MER36L
Leave this manual with party responsible for use
and operation.
CAUTION: Logs are fragile, handle with care.
NOTICE: To simplify the installation process, positively
identify each individual log before beginning installation.
See Figure 1.
Installation
1. Reference the four log pins and the location of the log
stop shown in Figure 2.
LOG STOP LOG STOP
1 1
Figure 2 Locations for Log Pins
Log #1: Place Log #1 as shown in Figure 3. The right end touches Log Pin 4. Push the log back until it rests against the
log stop shown in Figure 2.
1 1
2 2
1 1
LOG PINS LOG PINS
Figure 4 Position Log #2
Log #2: Place Log #2 using the three log pins as shown in Figure 4.
4 4
2 2
3 3
2 2
3 3
Majestic • LOGSMER36 Log Instructions • 2596-935 Rev. B • 5/23
LOG PLACEMENT INSTRUCTIONS
1 1 3 3
2 2
Figure 2
Figure 1 Log Identification
NOTCH FOR LOG #5 NOTCH FOR LOG #5
NOTCH FOR LOG #3 NOTCH FOR LOG #3
Figure 3 Position Log #1
4 4 5 5 6 6
NOTCH FOR LOG #4 NOTCH FOR LOG #4
1 1
LOG LOG
PIN #4 PIN #4
7 7
