Majestic CK36MS Installation Instructions Manual

Leave this manual with party responsible for use
and operation.
DANGER
DO NOT TOUCH GLASS
NEVER ALLOW CHILDREN
A barrier designed to reduce the risk of
burns from the hot viewing glass is provided
with this appliance and shall be installed for
the protection of children and other at-risk
individuals.
CAUTION! Do not install damaged components.
CAUTION! Risk of Cuts, Abrasions or Flying Debris.
Wear protective gloves and safety glasses during instal-
lation. Sheet metal edges are sharp.
WARNING! Choking Hazard! Keep media and stones
out of reach of children.
WARNING! Risk of Injury! This kit must be installed by
a qualified service technician.
TOOLS
Screw gun equipped with 1/4 in. socket or
1/4 in. wrench
3/8 in. wrench (Propane Appliances Only)
Instructions for optional glass kit, if applicable.
Models: PEARL36STIN, PEARL36PRIN
Installation Instructions
HOT GLASS WILL
CAUSE BURNS.
UNTIL COOLED.
TO TOUCH GLASS.
Majestic • CK36MS Contemporary Kit Instructions • 2488-970 Rev. D • 7/18
CK36MS
Note: The control module MUST be set to 30%
turndown when the CK36MS kit is installed.
Note: If an optional LINER-36ST or LINER-36PIER kit
will be used with the CK36MS, the LINER-36ST/LINER-
36PIER instructions will be needed during installation of
the CK36MS kit.
Note: The CK36MS is not compatible with fiber refractory.
BTU Specifications
Models
(U.S. or Canada)
CK36MS (NG)
CK36MS (Propane)
Preparation
CAUTION! Risk of Burns! The fireplace should be
turned off and cooled before contemporary kit is installed.
• Remove the CK36MS burner assembly from the base
pan assembly by removing four screws.
• Shut off gas supply and disconnect electrical power.
• Remove decorative fronts, glass assemblies, lava
rock, embers and logs, if previously installed.
Maximum
Minimum
Input
Input BTU/h
BTU/h
38,000 26,000
(0-2000 FT)
29,000 19,000
(0-2000 FT)
Orifice
Size
(DMS)
32
52
1
