Majestic CRD36 Installation Instructions

Contemporary rectangular design decorative fronts

Advertisement

Quick Links

Contemporary Rectangular Design Decorative Fronts
Leave this manual with party responsible for use
and operation.
CAUTION! Risk of Cuts, Abrasions or Flying Debris.
Wear protective gloves and safety glasses during instal-
lation. Sheet metal edges are sharp.
DANGER
DO NOT TOUCH GLASS
NEVER ALLOW CHILDREN
A barrier designed to reduce the risk of
burns from the hot viewing glass is provided
with this appliance and must be installed for
the protection of children and other at-risk
individuals.
WARNING! Risk of Fire! Combustible materials MUST
NOT overlap or be placed behind a decorative front.
CAUTION! Do not install damaged components.
Note: To avoid potential damage to hearth pad or flooring,
protect area in front of fireplace by laying cardboard or
blanket down.
CRD36, CRD42
Installation Instructions for all available color choices
HOT GLASS WILL
CAUSE BURNS.
UNTIL COOLED.
TO TOUCH GLASS.
Majestic • CRD3, CRD42 Decorative Front Instructions • 2454-930 Rev. D • 7/22
INTRODUCTION
This instruction is to be used for both Inside Fit and Over-
lap Fit for both sizes of the Contemporary Rectangular
Design (CRD) decorative fronts. Multiple color options
are available.
A. Finishing Material
Refer to Table 1 for Decorative Front dimension
information.
These decorative fronts are designed to be installed as
"Overlap" or "Inside Fit".
Overlap Method: The factory-installed finishing strips
are to be removed for this method of finishing. Non-com-
bustible finish material that is 1" or less (such as marble
or tile) is installed up to the fireplace opening on the sides
and top. The mounting brackets are adjusted "out" so
that the edges of the mounting brackets are flush with the
face of the finishing material. When installed, the back of
the decorative front contacts the face of the finish materi-
al, thus the decorative front "overlaps" the finish material.
Refer to the appliance installation instructions for more
detailed information.
Inside Fit Method: The factory-installed finishing strips
are to remain in place during installation of the finishing
material. Typically, the inside fit method is only used
when non-combustible finish material greater than 1" is
preferred (such as cultured stone). This finish material
is installed adjacent to the decorative front sides and top.
The mounting brackets are to be installed "flush" with the
black edges of the inside surround opening. See Figure
3. When installed, the back of the decorative front con-
tacts the black surround on the fireplace, thus the deco-
rative front is "inside" the adjacent finish material. Refer
to the appliance installation instructions for more detailed
information.
DECORATIVE
FRONT
CRD36
CRD42
Table 1. Decorative Front Dimensions
HEIGHT
WIDTH
32-3/8 IN.
37-1/16 IN.
34-1/4 IN.
44-1/16 IN.
1
