Log Set Assembly: LOGS-KMOD
Models: 6KMOD, 8KMOD, MER36MN, MER42MN
Leave this manual with party responsible for use
and operation.
CAUTION: Logs are fragile, handle with care.
NOTICE: To simplify the installation process, positively
identify each individual log before beginning installation.
See Figure 1.

Installation

1. Fill round holes with included log pins as indicated in
Figure 2. Discard remaining log pins. Figure 3 shows
the log pins in the round holes.
6KMOD / MER36MN (12 PINS)
8KMOD / MER42MN (13 PINS)
Figure 2 Locations for Log Pins
Log #1: Place Log #1 using the #4 and #6 log pins as guides as shown in Figure 4. The left end of the log will align with
the burner screw as shown in the top view illustrated in Figure 5.
LOG PINS
LOG PINS
Figure 4 Place Log #1
Heat & Glo • LOGS-6KMOD, LOGS-8KMOD Log Instructions • 2584-935 Rev. B • 12/22
1 1
LOG PLACEMENT INSTRUCTIONS
1 1
2 2
3 3
Figure 2
Figure 1 Log Identification
1 1
8 8
2 2
3 3
10
10
11
11
Figure 3 Log Pins Installed (6KMOD / MER36MN Base Pan Shown)
Figure 5 Top View of Log #1 in Position
4 4
5 5
6 6
7 7
4 4
6 6
5 5
9 9
7 7
12
12
1 1
BURNER SCREW
BURNER SCREW
8 8
1
