Arkon TABPBRM023 Manual

TABPBRM023 | Push-Button Tablet Holder with Cup Holder Mount
TAB003
APRM2T
Install the Dual T-Tab adapter into the tablet holder
Insert the Dual T-Tab adapter into the slot located behind
the holder. Then, slide the adapter upwards to ensure it is
securely in place.
WARNING
CHOKING HAZARD - Keep out of reach from children under 8 yrs. as they can choke or suffocate on parts included with this system
WARNING
Arkon® is not responsible for any damages caused to your device or yourself due to the installation or use of this mount. Do not install Arkon® products near areas that intefere with operation
of vehicles. Arkon® assumes no responsibility or liability for injury or death as a result of failure to install in a safe location. Arkon® is not responsible for any damages caused to vehicles,
product, or people due to the installation or use of this product.
SPRM023
SP-RM250
Includes:
1 – Universal Push-Button Tablet Holder (TAB003)
1 – 25mm Ball to Dual T-Tab Mounting Pattern Adapter (APRM2T)
1 – Robust™ Series 3.75 inch Mount Shaft Arm (SP-RM250)
1 – Cup Holder Mounting Pedestal (SPRM023)
Please take note of the pads included in SPRM023 packaging:
1 - Set of 4 Self-Adhesive Pads (SP023PAD) - Optional
Compatibility: This holder is suitable for tablets with cases measuring up
to 6.5" tall.
Important: Clean the application surface and make sure it is free of dirt,
dust, and grease before installation.
Assemble the components
Turn the shaft knob counterclockwise to loosen it. Next,
attach the 25mm ball adapters to both ends. Finally, tighten
the shaft to secure everything in place.
USA (800) 841-0884
INT'L (626) 254-9005
Monday - Friday 9 am - 5 pm PST
Need assistance?
arkon.com
Scan to email our
Designed in USA
Arkon® customer
©Arkon Resources, Inc.
Continued on page 2
