Arkon Slim-Grip Ultra Pro Manual

TAB6RMAMPS-MET | Slim-Grip® Ultra Pro Tablet Holder with Drill-Base Mount
TAB006AMPSXL
Disassemble the AMPS adapter plate from the pedestal
To detach one of the AMPS adapters from the drill base
pedestal, simply turn the shaft knob counterclockwise.
Mount Installation
To secure the pedestal to the mounting surface, align the
screws (not included) with the AMPS adapter. If necessary,
detach the shaft from the adapter to streamline the
installation process.
WARNING
CHOKING HAZARD - Keep out of reach from children under 8 yrs. as they can choke or suffocate on parts included with this system
WARNING
Arkon® is not responsible for any damages caused to your device or yourself due to the installation or use of this mount. Do not install Arkon® products near areas that intefere with operation
of vehicles. Arkon® assumes no responsibility or liability for injury or death as a result of failure to install in a safe location. Arkon® is not responsible for any damages caused to vehicles,
product, or people due to the installation or use of this product.
RM2XAMPS-MET
USA (800) 841-0884
INT'L (626) 254-9005
Monday - Friday 9 am - 5 pm PST
Includes:
1 – Slim-Grip® Ultra Pro Tablet Holder with Support Legs (TAB006AMPSXL)
1 – Drill Base Mount with 3.75" Shaft Arm (RM2XAMPS-MET)
Please note the contents included:
4 - M4 x 12mm Screws
5 - Support legs (SPTAB6FT)
Important: Clean the application surface and make sure it is free of dirt, dust, and grease
before installation.
Leg Selection Guide
Choose the appropriate legs based on your tablet size, with or without a case:
Tablets (approximately 6.37" to 8.81") - Use 2 small legs.
Tablets (approximately 7.12" to 9.25") - Use 1 long leg and 1 small leg.
Tablets (approximately 7.62" to 10") - Use 2 long legs.
Tablets (approximately 8.75" to 11.12") - Use 1 long leg and 1 extra long leg.
Install the AMPS adapter plate to the holder
Align the AMPS 4-hole adapter on the back of the holder. Then,
insert the four mounting screws through the AMPS 4-hole ball
adapter plate and into the holder. Finally, secure the screws tightly.
Assemble the components
Locate the shaft arm and turn to the adjustment knob
counterclockwise to expand. Insert the 25mm ball ends into the
shaft. Turn clockwise to tighten.
