Arkon Slim-Grip TABCPM38 Manual

TABCPM38 | Slim-Grip
TAB001-AMPS APMAMPS38MM
Install the AMPS adapter onto the tablet holder
Align the adapter holes with the ones on the tablet holder.
Then, securely attach the screws included in the tablet
holder kit.
WARNING
CHOKING HAZARD - Keep out of reach from children under 8 yrs. as they can choke or suffocate on parts included with this system
WARNING
Arkon ® is not responsible for any damages caused to your device or yourself due to the installation or use of this mount. Do not install Arkon
of vehicles. Arkon ® assumes no responsibility or liability for injury or death as a result of failure to install in a safe location. Arkon
product, or people due to the installation or use of this product.
® Universal Tablet Holder with Clamp Mount and 3.5" Arm
SPRM3835B CPM38B
Includes:
1 – Slim-Grip ® Universal Tablet Holder Kit
1 – Metal 4-Hole AMPS to 38mm Ball Adapter
1 – Robust™ Series 3.5inch Shaft Arm
1 – Robust™ Clamp Mount with 38mm Ball
IMPORTANT: Clean the application surface and make sure it is free of dirt, dust, and
grease before installing the mounting hardware.
Leg selection guide
Recommended legs to use based on tablet with or without a case
- For tablets size min 6" to 8.25" max we recommend using 4 small legs
- For tablets size min 6.75" to 9.12" max we recommend using 2 small legs and 2 medium legs
- For tablets size min 8.31" to 10.75" max we recommend using 2 medium legs and 2 large legs
- For tablets size min 9.12" to 11.50" max we recommend using 4 large legs
Assemble all components
Turn the shaft arm counterclockwise to loosen it. Next, attach
the 38mm ball adapters to both ends. Finally, tighten the shaft to
secure everything in place.
USA (800) 841-0884
INT'L (626) 254-9005
Monday - Friday 9 am - 5 pm PST
(TAB001-AMPS)
(APMAMPS38MM)
(SPRM3835B)
(CPM38B)
® products near areas that intefere with operation
® is not responsible for any damages caused to vehicles,
Need assistance?
arkon.com
Scan to email our
Designed in USA
Arkon® customer
©Arkon Resources, Inc.
rev.062824
Continued on page 2
