- Page 1 Operation and Service Instructions ProCenter CTR100-1 Issue Date: November 2007 Comco Inc. 2151 N. Lincoln Street Burbank, California 91504 Phone: 818-841-5500 FAX: 818-955-8365 Web Site: www.COMCOinc.com Book P/N CTR130 File: CTR100-1.doc Comco Inc. Issue Date: November 2007...
-
Page 2: Table Of Contents
Comco ProCenter Table of Contents The Comco Warranty ....................iii Safety Precautions ....................iv Section 1: The ProCenter CTR100-1 ............1-1 Installation, operation, and service instructions Positioning the ProCenter ................1-1 Installing the ProCenter ................1-2 Installing and Connecting the Blaster ............1-3 Operation..................... -
Page 3: The Comco Warranty
The warranty period begins when the equipment ships from the Comco facility and applies to the original owner only. Comco is not liable for damages from any cause or use of such equipment beyond the cost of repairing any defective parts. -
Page 4: Safety Precautions
DO NOT point the abrasive hose nozzle toward the window glass. The glass will quickly become frosted and will require replacement. √ DO NOT modify or alter the ProCenter in any way without first consulting Comco Inc. √ ENSURE that all operators are familiar with the safety operating procedures in this manual. -
Page 5: Section 1: The Procenter
Comco ProCenter CTR100-1 Section 1: The ProCenter CTR100-1 The ProCenter model CTR100-1 is a combined blasting chamber and dust collection system. It should only be used with micro-abrasive blasting equipment and abrasive powders recommended for use with such blasting equipment. -
Page 6: Installing The Procenter
CTR100-1 Comco ProCenter Installing the ProCenter Installing the Blower Motor Assembly – The Motor Assembly is removed prior to shipping to prevent damage. Before operating the ProCenter, the blower motor assembly must be installed on the unit. Remove the Blower Motor Assembly from its box. Position the assembly on the right hand side of the unit by inserting the fan through the large hole in the unit and aligning the mounting plate holes with the holes in the side of the unit. -
Page 7: Installing And Connecting The Blaster
Comco ProCenter CTR100-1 Installing and Connecting the Blaster Prior to installing and connecting the blaster, read the “Getting Started” section of the Operations and Service Instructions manual that was provided with the blaster. Installing the Blaster: The ProCenter is designed so that an MB... -
Page 8: Operation
CTR100-1 Comco ProCenter Operation ON/OFF Switch – This switch activates the lights and motor. It is to remain in the ON position whenever the blaster is being operated. The ProCenter can remain ON even when the blaster is not being used. -
Page 9: Section 2: Maintenance
Comco ProCenter CTR100-1 Section 2: Maintenance Vibrate/Clean Filter – The ProCenter is equipped with a pneumatic vibrator that is used to vibrate or “shake” the air filter element. The vibrating action dislodges the powder particles from the filter element pleats and allows them to fall into the hopper. Normally this vibrating or cleaning of the filter only needs to be run periodically for approximately 2 minutes. - Page 10 CTR100-1 Comco ProCenter Filter Replacement (cont’d) Remove the two filter clamping knobs. The amount of airborne dust can be reduced by rotating the filter 360° before removing it from the unit. Hold the filter element up and slide its clamping bar off the threaded bars.
- Page 11 Comco ProCenter CTR100-1 Emptying the Hopper – The hopper collects the abrasive powder and will require emptying periodically. To empty the hopper: Place a suitable container under the hopper gate, or secure a plastic bag around the hopper outlet with a strap or drawstring.
- Page 12 CTR100-1 Comco ProCenter THIS PAGE LEFT INTENTIONALLY BLANK Comco Inc. Issue Date: November 2007...
-
Page 13: Appendix A: Replacement Parts And Schematics
Comco ProCenter CTR100-1 Appendix A: Replacement Parts and Schematics Appendix A Replacement Parts and Schematics for the ProCenter 115V/60 Hz CTR100-1 Comco Inc. Issue Date: November 2007... - Page 14 Appendix A: Replacement Parts and Schematics Comco ProCenter CTR100-1 CTR100-1 PROCENTER 115V Comco Inc. Issue Date: November 2007...
- Page 15 Comco ProCenter CTR100-1 Appendix A: Replacement Parts and Schematics ELECTRICAL COMPONENTS 115V Comco Inc. Issue Date: November 2007...
- Page 16 Appendix A: Replacement Parts and Schematics Comco ProCenter CTR100-1 LIGHT PANEL 115V Comco Inc. Issue Date: November 2007...
-
Page 17: Pneumatic Diagram
Comco ProCenter CTR100-1 Appendix A: Replacement Parts and Schematics PNEUMATIC DIAGRAM ELECTRICAL SCHEMATIC 115V Comco Inc. Issue Date: November 2007... -
Page 18: Wiring Diagram 115V
Appendix A: Replacement Parts and Schematics Comco ProCenter CTR100-1 WIRING DIAGRAM 115V Comco Inc. Issue Date: November 2007... - Page 19 Comco ProCenter CTR100-1 Appendix A: Replacement Parts and Schematics Motor Replacement Instructions If motor replacement is required, it can be accomplished in two ways: The complete motor, impeller, and motor mounting plate assembly can be replaced as one unit, or the motor assembly can be disassembled and just the motor replaced.
- Page 20 ProCenter and possible injury to the operator. Contact Comco Technical Support for a replacement Impeller P/N CTR150. With the motor and plate still on their side, loosen the (4) 9/16” hex bolts.
- Page 21 Connect the ProCenter’s electrical plug into power outlet and turn on unit. The motor should run smoothly. If not, determine cause of problem and repair before operating unit. For assistance, contact Comco Technical Support. Note: Do not use the ProCenter if there is a noticeable vibration from the motor and impeller.
- Page 22 Appendix A: Replacement Parts and Schematics Comco ProCenter CTR100-1 THIS PAGE LEFT INTENTIONALLY BLANK A-10 Comco Inc. Issue Date: November 2007...
-
Page 23: Appendix B: Options
Comco ProCenter CTR100-1 Appendix B: Options Appendix B Options for the ProCenter 115V/60 Hz CTR100-1 Comco Inc. Issue Date: November 2007... - Page 24 Appendix B: Options Comco ProCenter CTR100-1 Optional CTR141 ProCenter Shelf Installation Instructions Install the two Vertical Shelf Supports onto the right hand side of the ProCenter with the four 3/8-16 X 1/2 in. long Hex Head Bolts. DO NOT tighten at this time.
