Operation and Service Instructions
DirectFlo™ DF1400
Issue Date: January 2009
This manual covers all variations of the DF1400 series
(DF1400-1, DF1400-2, ETC)
Comco Inc.
2151 N. Lincoln Street
Burbank, California 91504
USA
Phone: 818-841-5500
FAX: 818-955-8365
www.comcoinc.com
Book P/N PF1430
File: DF1400.doc

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DirectFlo DF1400 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Comco DirectFlo DF1400 Series

Summary of Contents for Comco DirectFlo DF1400 Series

  • Page 1 Operation and Service Instructions DirectFlo™ DF1400 Issue Date: January 2009 This manual covers all variations of the DF1400 series (DF1400-1, DF1400-2, ETC) Comco Inc. 2151 N. Lincoln Street Burbank, California 91504 Phone: 818-841-5500 FAX: 818-955-8365 www.comcoinc.com Book P/N PF1430 File: DF1400.doc...

  • Page 2: Table Of Contents

    Table of Contents The Comco Warranty .................... iv Safety Precautions ....................v Chapter 1: The DirectFlo DF1400 .............1-1 This chapter introduces you to the basic unit, including its description, principles of operation, and detail specifications. Overview ....................1-2 Figure 1-1, DirectFlo DF1400 ............1-2 How The DirectFlo Works ................
  • Page 3 This appendix presents parts lists, drawings and schematics for the DirectFlo DF1400. Appendix A: Parts Lists ..................A-1 Major Assemblies and Principal Parts ............A-2 Standard Accessory Parts ................A-5 Recommended Spares ................A-6 Appendix B: Drawings and Schematics ..............B-1 Comco Inc. Issue Date: January 2009...

  • Page 4: The Comco Warranty

    The warranty period begins when the equipment ships from the Comco facility and applies to the original owner only. Comco is not liable for damages from any cause or use of such equipment beyond the cost of repairing any defective parts.

  • Page 5: Safety Precautions

    General issues involved in operating machinery. Working with a Device that is Pressurized The DirectFlo uses pressurized air to perform its basic function. While Comco's blasting machines incorporate relief valves and check valves to minimize the risk of an accident related to air pressure, Comco also recommends the following: √...
  • Page 6 The DirectFlo uses several types of abrasive media that should not be inhaled or ingested in large quantities or maintained in prolonged contact with the skin. When working with the abrasive media, Comco recommends the following: √ Do not direct the abrasive blast on bare skin or face/eyes.
  • Page 7 Some powders, if allowed to collect inside the machine, may cause electrical shorts. Material safety data sheets (MSDS’s) for all abrasives distributed by Comco are available from the Comco factory. Every powder shipment includes an MSDS. Contact the Comco Customer Service department to obtain extra copies of any MSDS.
  • Page 8 Avoiding Hazards Associated with Operating Machinery The following warning labels/pictograms are utilized in the DirectFlo CE (European) versions: Symbol Meaning ELECTRICAL HAZARD HAND PROTECTION RECOMMENDED WHERE APPROPRIATE EYE PROTECTION RECOMMENDED WHERE APPROPRIATE RESPIRATORY PROTECTION RECOMMENDED WHERE APPROPRIATE Comco Inc. viii Issue Date: January 2009...

  • Page 9: Chapter 1: The Directflo Df1400

    DirectFlo DF1400 Chapter 1: The DirectFlo 1400 Chapter 1: The DirectFlo DF1400 In This Chapter  A general description of the DirectFlo  How the DirectFlo works  Detail specifications Comco Inc. Issue Date: January 2009...

  • Page 10: Overview

    Chapter 1: The DirectFlo 1400 Overview The Comco DirectFlo Model DF1400 is a bench-top machine that delivers a precisely controlled stream of micro-abrasive particles at high velocity. With the appropriate abrasive powder and the necessary adjustments, it will clean, deburr, cut or drill any material, particularly hard or brittle ones.

  • Page 11: How The Directflo Works

    To operate the DirectFlo from this point would simply require picking up the nozzle, pointing it at the item to be blasted, and depressing the footswitch to begin blasting. What happens when the machine is actually in operation is explained on the following pages. Comco Inc. Issue Date: January 2009...
  • Page 12 Since the air flowing from the regulator into the mixing chamber is at basically the same pressure as that in the tank, the upward force of the air keeps the abrasive in the tank. At this point, little or no abrasive is being injected into the air stream. Comco Inc. Issue Date: January 2009...
  • Page 13 Additional information regarding the tank orifice, nozzle sizes, abrasives, and other variables in the abrasive blast process is presented in Chapter 3 of this manual. Comco Inc. Issue Date: January 2009...

  • Page 14: Detail Specifications

    250 standard cubic feet per hour (SCFH) at 80 psig; and nozzle life will be 8 to 35 hours depending on the amount of wear that can be tolerated. Units supplying abrasive to multiple nozzles may require up to 12 SCFM. Operating voltage specified by order and is shown on nameplate. Comco Inc. Issue Date: January 2009...

  • Page 15: Chapter 2: Getting Started

    Chapter 2: Getting Started In This Chapter  The work area required to properly use the DirectFlo  What you received with the DirectFlo  Basic components of the DirectFlo  Setting up and testing the DirectFlo Comco Inc. Issue Date: January 2009...
  • Page 16 These dust collectors have both high airflow and large filter areas to keep work areas clean and dust free. The Comco DC2100 is a suitable dust collector for most micro- abrasive blasting applications. In heavy usage, multiple blaster, and automated applications, the continuous duty DC3000 dust collector is recommended.
  • Page 17 DF1400. If the WS2200 or WS6000 WorkStation is used, it requires 40 watts. The DC2100 Dust Collector, if used, requires about 16 amps (115 VAC) for its 1-HP motor. Actual voltage required for each machine will be found on the nameplate. Comco Inc. Issue Date: January 2009...
  • Page 18 You may use this tip sheet to quickly get your DirectFlo set up and ready to operate, and as a ready reference for common questions regarding the operation of the DirectFlo. Keep it nearby and refer to it often. For complete details on the DirectFlo, Comco strongly urg es you to read the manual completely.
  • Page 19 Parts Kit. Note that two additional items, a .025" tank orifice, MB1409-25, and a .060" nozzle, PF2110-1 (red), should already be installed on the DirectFlo DF1400. Open all small packages within the large carton carefully, since many small parts are included with the shipment. Comco Inc. Issue Date: January 2009...
  • Page 20 “OFF” and the unit has been vented. PowderGate The PowderGate Valve is used to control the air/abrasive flow from the DirectFlo. The valve protrudes from the rear of the unit. It is designed for high reliability in a production environment. Comco Inc. Issue Date: January 2009...
  • Page 21 DirectFlo DF1400 Chapter 2: Getting Started Figure 2-3: External Component Locations PRESSURE GAGE POWER SWITCH ABRASIVE BLEND CONTROL AIR PRESSURE CONTROL KNOB AIR IN COUPLING FOOTSWITCH CONNECTION ELECTRICAL POWER CONNECTION POWDERGATE VENT HOSE OUTPUT Comco Inc. Issue Date: January 2009...

  • Page 22: Setup And Test

    140 PSIG. CAUTION: Inlet pressures above 140 psig may damage the DirectFlo DF1400. The DirectFlo DF1400 has an internal pressure relief valve, however, Comco recommends that the system inlet line have a relief valve also. Comco Inc. Issue Date: January 2009...
  • Page 23 DirectFlo DF1400 Chapter 2: Getting Started TANK COVER POWDER BASKET SWING BOLTS & NUTS (4) Figure 2-4: Tank Inspection Comco Inc. Issue Date: January 2009...
  • Page 24 The PowderGate will close and the pressure gage on the front of the unit should indicate pressure in the unit. Listen for obvious leaks. CAUTION: Do not lean over the abrasive tank while the system is pressurizing. Comco Inc. 2-10 Issue Date: January 2009...
  • Page 25 You are now ready to select the proper abrasive, nozzle and other operational parameters to begin using your DirectFlo. These issues, as well as detailed operational instructions, are discussed in the next chapter. Comco Inc. 2-11 Issue Date: January 2009...
  • Page 26 DirectFlo DF1400 Chapter 2: Getting Started THIS PAGE LEFT INTENTIONALLY BLANK Comco Inc. 2-12 Issue Date: January 2009...

  • Page 27: Chapter 3: Using The Directflo

    DirectFlo DF1400 Chapter 3: Using the DirectFlo Chapter 3: Using the DirectFlo In This Chapter  Abrasive selection  Orifice and Nozzle selection  General operation of the DirectFlo Comco Inc. Issue Date: January 2009...

  • Page 28: Essence Of Micro-Abrasive Blasting

    Air Pressure  Powder Flow Adjustment Setting Table 3-1 gives a brief overview of all of these essential factors. Each of them is discussed in detail on the following pages, beginning with abrasive selection. Comco Inc. Issue Date: January 2009...
  • Page 29 Less powder heading within this and more air tend to cut faster at close nozzle chapter. distances. * Additional Information can be found in these chapters. Comco Inc. Issue Date: January 2009...

  • Page 30: Abrasive Selection

    “clump up”, preventing a free flow from the tank. Problems associated with moisture in the abrasive powder are discussed in detail in Chapter 4. Comco Inc. Issue Date: January 2009...
  • Page 31 Always start the work shift with fresh abrasive powder. Powder left sitting in an unpressurized machine overnight can absorb moisture. This contaminated powder can cause flow problems. Keep powder containers sealed and stored in a cool, dry place. Comco Inc. Issue Date: January 2009...
  • Page 32 1/4" nut driver (see Figure 3-1). The replacement orifice should be installed securely, but not too tight. Insert the powder basket back in the tank and replace the tank cover. For improved performance and longer life, all Comco orifices are carbide lined. Rev 5/2014 Comco Inc.
  • Page 33 30 - 80 0.025 0.006 65 - 200 0.030 0.008 80 - 300 0.040 0.010 150 - 300 0.060 TANK COVER POWDER BASKET TANK COVER NUTS ORIFICE Figure 3-1: Changing the Tank Orifice Rev 5/2014 Comco Inc. Issue Date: January 2009...
  • Page 34 With larger nozzle openings, more abrasive can flow, and thus cutting speed is increased and efficiency will improve. Comco offers many different sizes and configurations (see Figure 3-2), from a 0.030" diameter round nozzle, to 0.016" x 0.190" rectangular. For most applications a round nozzle would be preferred due to the precise spray pattern.
  • Page 35 0.195 0.018 - 0.030 0.150 PF2110-6 Blue 0.016 0.250 0.018 - 0.046 0.190 Straight Round, and Rectangular Nozzles Requires Comco Nozzle Adapter PF2044 (see Figure 3-2) MB1500-11 Green 0.030 0.074 0.018 - 0.040 MB1500-29 Yellow 0.046 0.125 0.018 - 0.046...
  • Page 36 In this manner, a saw cut may be made with relatively straight sides through relatively thick materials. In any case, nozzle angle can be adjusted in two planes to result in at least one side being cut perpendicular to the surface. Comco Inc. 3-10 Issue Date: January 2009...
  • Page 37 Chapter 6, Options. Note: Splitters will not supply appropriate abrasive flow to all types of nozzles. Contact Comco Technical Support for additional information about splitter capabilities. Air Pressure The simplest method of changing cutting speed is to vary the air pressure to the tank with the “Air Pressure”...

  • Page 38: General Operation Of The Directflo

    √ Properly set up your DirectFlo according to the procedures in Chapter 2. √ Selected the proper abrasive for your application. √ Installed the proper tank orifice for the abrasive powder you are using. √ Selected the proper nozzle for your application. Comco Inc. 3-12 Issue Date: January 2009...
  • Page 39 Do not overfill. Tap the flapper as it closes so that any powder on it will be dislodged into the tank and not interfere with sealing of the O-ring. Figure 3-3: Filling the Abrasive Tank Comco Inc. 3-13 Issue Date: January 2009...
  • Page 40 Chapter 3: Using the DirectFlo Figure 3-4: Controls and Indicators PRESSURE GAGE POWER SWITCH ABRASIVE BLEND CONTROL AIR PRESSURE CONTROL KNOB AIR IN COUPLING FOOTSWITCH CONNECTION ELECTRICAL POWER POWDERGATE CONNECTION VENT HOSE OUTPUT Comco Inc. 3-14 Issue Date: January 2009...
  • Page 41 Move the handpiece or the work piece as required by the job. If more or less abrasion is desired, turn the "Air Pressure" knob to raise or lower the blasting pressure. Comco Inc. 3-15 Issue Date: January 2009...
  • Page 42 Do not overfill the tank. Tap the Flapper as it closes so that any powder on it will be dislodged into the tank and not interfere with sealing of the O-ring. Comco Inc. 3-16 Issue Date: January 2009...
  • Page 43 Turn the Power “ON” to pressurize the unit. Hold the handpiece and depress the footswitch for approximately 30 seconds to purge any remaining abrasive out of system. Follow the directions in “Refilling the Tank”, above. Comco Inc. 3-17 Issue Date: January 2009...
  • Page 44 DirectFlo DF1400 Chapter 3: Using the DirectFlo THIS PAGE LEFT INTENTIONALLY BLANK Comco Inc. 3-18 Issue Date: January 2009...

  • Page 45: Chapter 4: Maintenance

    DirectFlo DF1400 Chapter 4: Maintenance Chapter 4: Maintenance In This Chapter  Maintenance intervals  Extending the life of wear items  Replacing worn out components Comco Inc. Issue Date: January 2009...

  • Page 46: Normal Maintenance

    DirectFlo: √ A small stiff brush for cleaning threads and components. √ The 1/4" nut driver supplied by Comco in the accessory kit. √ The 9/16" wrench supplied by Comco in the accessory kit. Comco Inc. Issue Date: January 2009...
  • Page 47 PowderGate Remove and disassemble. Inspect internal components for wear. (see directions in Chapter 5) Vent Pinch Assembly Inspect pinch assembly for worn or inoperable parts. Tank Cover & Basket O-rings Replace (See directions following) Comco Inc. Issue Date: January 2009...

  • Page 48: Parts Subject To Normal Wear

    NOTE With an abrasive machine, wear to critical parts is inevitable. You can minimize downtime by replacing normal wear items at regular intervals. Comco recommends that the following parts be replaced annually, or every 2000 hours of operation, whichever comes first. See Appendix A for part numbers. See Chapter 5 for replacement instructions.
  • Page 49 In addition the valve seat assembly will need to be inspected for grooves or channels that may inhibit proper sealing of the nosepiece. These two items are designed as standard replacement items for the PowderGate valve. Comco Inc. Issue Date: January 2009...
  • Page 50 It is recommended to replace the modulator housing assembly every 2000 hours of operation, which is approximately one year of normal operation. See Chapter 5 for inspection and repair procedures. Comco Inc. Issue Date: January 2009...

  • Page 51: General Maintenance

    Leaks usually begin to occur first in the tank cover O-rings. Inspect the O-rings often and make sure the cover is firmly sealed. See the previous discussion on “Tank Cover”, in this chapter. See Chapter 5 for further information on leaks. Comco Inc. Issue Date: January 2009...
  • Page 52 PF2110-x 3/8" ABRASIVE HOSE TUBING ASSEMBLY NOZZLE FERRULE SET PF2066 ST5508 HANDPIECE NOZZLE TUBE O-RING RIRi Figure 4-2: Regular Maintenance Items NOTE: See Appendix Parts List and Drawings for Part Numbers not listed here Comco Inc. Issue Date: January 2009...

  • Page 53: Auxiliary Equipment

    Other types of air dryers should be checked according to the manufacturer’s recommendations. Check the system air dryer on a regular basis. Typically, this should be done monthly. However, in high use facilities, it should be done weekly. Comco Inc. Issue Date: January 2009...

  • Page 54: Moisture

    Comco maintains an extensive library of technical bulletins that address issues including the effects of moisture on the micro-abrasive blasting process and methods for reducing moisture contamination.

  • Page 55: Chapter 5: Trouble-Shooting And Repair

     How to correct most problems which may develop with the DirectFlo  How to contact Comco’s Customer Service Department  How to order replacement parts for the DirectFlo Comco Inc.

  • Page 56: Trouble-Shooting

    NOTE: Improper repairs may void your warranty. If you have any questions, consult with Comco before you do any work on the inside of the DirectFlo DF1400. Most problems that can occur with your DirectFlo will fall into either one of two categories: No air flow - Nothing happens when you depress the footswitch.

  • Page 57: How To Order Replacement Parts

    DirectFlo DF1400 Chapter 5: Trouble-Shooting and Repair How To Order Replacement Parts Replacement parts for the DirectFlo may be ordered directly from Comco Customer Service. Please provide the following when ordering parts:  Your name  Your company’s name and location (city and state) ...

  • Page 58: Common Problems, Causes, And Solutions

    When cycling the unit ON and OFF operating? with the footswitch an audible clicking sound from the cylinder that opens and closes the PowderGate should be heard. If it is not, see maintenance of the PowderGate below. Comco Inc. Issue Date: January 2009...
  • Page 59 (see Chapter 3, Table 3-3). powder? √ Is the Modulator Does it hum audibly when the footswitch is functioning? actuated? If not, or if it rattles noisily, the modulator should be checked. See procedures below. Comco Inc. Issue Date: January 2009...

  • Page 60: Clogging

    Check it by holding the tip to a light. A point of light should be visible through the tip. Discard the nozzle if it remains plugged. If plugging recurs, either the tank is releasing too much powder or the nozzle is too small for the powder. Refer to Chapter 3 for direction. Comco Inc. Issue Date: January 2009...

  • Page 61: Tank Cover

    Tank Cover Flapper Valve The flapper valve allows for quick filling of the abrasive tank. If the valve becomes worn or damaged, replace it with Comco part number MB1145. Refer to Appendix B, Figure Tank Cover Flapper Valve Replacement Procedure (MB1145) Turn Power OFF and depressurize unit.
  • Page 62 CAUTION: Always use the proper hose when replacing a worn or damaged abrasive hose. The use of a different hose or a hose with a different pressure rating may present a hazard. Comco Inc. Issue Date: January 2009...
  • Page 63 The complete handpiece and hose assembly (PF2406) includes the handpiece, handpiece nose, a 7 ft length of polyurethane tubing with the ESD grounding spring wrapped around it, and a connector nut with ferrules. Replace complete assembly by disconnecting at PowderGate output. Comco Inc. Issue Date: January 2009...
  • Page 64 It is very hard to detect a slight leak in the tank cover. If you cannot locate a leak anywhere else, it is probably the tank cover O-rings. See the previous discussion, “Tank Cover”. Comco Inc. 5-10 Issue Date: January 2009...
  • Page 65 Inspect the pinch and plunger on a regular basis (see Table 4-1, “Maintenance Intervals”) for pitting and sharp edges. Abnormal hose breakage, always at the pinch, is an indication of pinch or plunger damage. Comco Inc. 5-11 Issue Date: January 2009...
  • Page 66 Remove the hose and pull it through the pinch tube. Remove the pinch tube. Inspect it for sharp edges or pitting due to abrasive leakage. Replace if necessary with Comco part number MB1282. Inspect the pinch plunger for sharp edges or pitting due to abrasive leakage.

  • Page 67: Inspecting And Repairing The Powdergate

    Nose and is replaced with the nose as a complete assembly. Replace the Nose & Valve Seat Assembly. Secure in place with the 4 socket head cap screws. Figure 5-2: PowderGate Nosepiece and Nose & Valve Seat Replacement Comco Inc. 5-13 Issue Date: January 2009...
  • Page 68 Turn knob back out counterclockwise 1/4 to 1/2 turn. Tighten the locking ring in place. If the delay cannot be properly set, it will be necessary to replace the flow control valve. Comco Inc. 5-14 Issue Date: January 2009...

  • Page 69: Inspecting And Repairing The Modulator

    Slide the 1" washer over the modulator housing and then slide the modulator coil over the modulator housing. Replace the retaining coupler. Install the air hose. Replace the DirectFlo cover and install the tank cover. Comco Inc. 5-15 Issue Date: January 2009...
  • Page 70 DirectFlo DF1400 Chapter 5: Trouble-Shooting and Repair Figure 5-3: Modulator Assembly and Modulator Housing Assembly See illustration below ------------------------------------------------------------------------------------------------------------------------------- PF2040 Modulator Housing Assembly, part of Modulator Assembly above Comco Inc. 5-16 Issue Date: January 2009...

  • Page 71: Air Pressure Regulator

    Pull the regulator assembly back into chassis and remove. Install the new regulator (PF2443). Attach the air hoses to the regulator assembly. Install the cover. Comco Inc. 5-17 Issue Date: January 2009...
  • Page 72 DirectFlo DF1400 Chapter 5: Trouble-Shooting and Repair THIS PAGE LEFT INTENTIONALLY BLANK Comco Inc. 5-18 Issue Date: January 2009...

  • Page 73: Chapter 6: Optional Equipment And Manual Supplements

    DirectFlo DF1400 Chapter 6: Optional Equipment Chapter 6: Optional Equipment and Manual Supplements In This Chapter  Optional equipment available on your DirectFlo  Operation and service of these options Comco Inc. Issue Date: January 2009...
  • Page 74 Chapter 6: Optional Equipment Splitters can be integrated with the DirectFlo to supply abrasive to multiple nozzles. Additional information on splitters and multiple nozzle arrays is available in Chapter 3, page 11. Rev 07/15 Comco Inc. Issue Date: January 2009...
  • Page 75 DirectFlo DF1400 Chapter 6: Optional Equipment Rev 07/15 Comco Inc. Issue Date: January 2009...
  • Page 76 Moisture in this area could cause the abrasive media to clump up and plug the nozzle tip. Blasters equipped with the optional Constant Air Bleed provide this continuous air flow. Rev 07/15 Comco Inc. Issue Date: January 2009...
  • Page 77 DirectFlo DF1400 Chapter 6: Optional Equipment Rev 07/15 Comco Inc. Issue Date: January 2009...
  • Page 78 Tee, Male Run, 5/32 T x 10-32 ST4028 Nipple, 1/4 NPT, Brass ST4238 Connector, 5/32 T x 1/8 NPT ST4087 Elbow, Street 1/8 NPT ST5010 Grommet ST4226 Tee, 1/4 NPT Stainless Steel ST6204 Needle Valve Rev 04/10 Comco Inc. Issue Date: January 2009...
  • Page 79 If the bleed air still does not flow, it is likely caused by an obstruction in the bleed air path such as a clogged filter, check valve, or regulator port. Locate clog by disconnecting or removing components one at a time and checking for air flow. Comco Inc. Issue Date: January 2009...
  • Page 80 DirectFlo DF1400 Chapter 6: Optional Equipment THIS PAGE LEFT INTENTIONALLY BLANK Comco Inc. Issue Date: January 2009...

  • Page 81: For The Directflo Df1400

    DirectFlo DF1400 Appendix A: Assemblies, Components, and Parts Appendix A Parts Lists for the DirectFlo DF1400 Comco Inc. Issue Date: January 2009...

  • Page 82: Major Assemblies And Principal Parts

    230 VAC PowderGate Valve Assembly is PF1407-2 230 VAC Valve, 4-Way is ST6265-2 230 VAC Inlet Valve Assembly is PF1404-2 230 VAC Valve, 2-Way is ST6208-4 230 VAC Valve, 3-Way is ST6245-4 Rev 08/09 Comco Inc. Issue Date: January 2009...
  • Page 83 Nose Assembly PF2083 Tube, Abrasive, .375 Polyhose 6 ft ST4266 Nut & Ferrule Set, 3/8 Tubing ST4209 Ferrule Set (only) 3/8 Tubing ST5552 Spring, Grounding 230V Modulator Assembly is PF2034-2 230V Coil, Modulator is MB1310-8 Comco Inc. Issue Date: January 2009...
  • Page 84 Part of Cabinet Assembly, PF1422 Power Cord for 230V machines is P/N ST7716-2 Fuses for 230V machines: ST2005-005 Fuse, 220V, 500mA, Time Delay ST2005-0315 Fuse, 220V, 3.15A, Time Delay 230 VAC Terminal Block is PF1490 Rev 11/09 Comco Inc. Issue Date: January 2009...

  • Page 85: Standard Accessory Parts

    Ferrule Set, 3/8 Tubing PF2090 Nose Assembly, Nozzle MB1653 Nosepiece, PowderGate The Accessory Parts kit for 230v machines is PF1408-2CE; Power cord is ST7716-9, and two fuses are added, ST2005-005 (500ma) and ST2005- 0315 (3.15a). Rev 01/12 Comco Inc. Issue Date: January 2009...
  • Page 86 PF2139 O-ring Replacement Kit ST5161 O-ring, .489 ID ST6209 Valve, Check ST6210 Regulator ST6267 Filter Element, Replacement Orifice and Nozzle sizes are determined by application requirements. Refer to Chapter 3 for details. Rev 07/12 Comco Inc. Issue Date: January 2009...

  • Page 87: Appendix B: Drawings And Schematics

    DirectFlo DF1400 Appendix B: Drawings and Schematics Appendix B Drawings and Schematics for the DirectFlo DF1400 Comco Inc. Issue Date: January 2009...
  • Page 88 Figure 12:P/N PF2142 Powder Adjustment Assembly ..........B-16 Figure 13: P/N PF1404 Air Valve Assembly .............. B-17 Figure 14: P/N PF1407 PowderGate Assembly ............B-18 Figure 15: P/N PF2227 Abrasive Basket Assembly ........... B-19 Rev 11/09 Comco Inc. Issue Date: January 2009...
  • Page 89 Part No. Item Description Part No. Power Switch ST2045 Tank Cover PF2480 Regulator Assy. PF2443 Abrasive Tank Pressure Gage MB1407-1 Handpiece Assy. PF2406 Powder Flow Ctl. PF2142 See individual Part Drawing for Part Numbers Comco Inc. Issue Date: January 2009...
  • Page 90 Union, Bulkhead, 1/4 T ST4014 Tank Orifice Size, determined by application See individual Part Drawing for Part Numbers 230V Modulator Assembly is PF2034-2 230 VAC Inlet Valve Assembly is PF1404-2 230V Terminal Block is PF1490 Comco Inc. Issue Date: January 2009...
  • Page 91 DirectFlo DF1400 Appendix B: Drawings and Schematics FIGURE 3: PNEUMATIC SCHEMATIC, MODEL DF1400 Comco Inc. Issue Date: January 2009...
  • Page 92 DirectFlo DF1400 Appendix B: Drawings and Schematics FIGURE 4A: ELECTRICAL SCHEMATIC, MODEL DF1400 Comco Inc. Issue Date: January 2009...
  • Page 93 DirectFlo DF1400 Appendix B: Drawings and Schematics FIGURE 4B: ELECTRICAL SCHEMATIC, MODEL DF1400-2 Comco Inc. Issue Date: January 2009...

  • Page 94: Figure 4C: Component Designations

    DirectFlo DF1400 Appendix B: Drawings and Schematics FIGURE 4C: COMPONENT DESIGNATIONS Comco Inc. Issue Date: January 2009...
  • Page 95 Part No. Scrw, 4-40x.25 ST1030 O-ring ø5.859 ID ST5495 Washer, #4 ST1027 O-ring ø.296 ID ST5496 Flapper Assy. MB1145 Bushing Feedthru PF2055 O-ring ø1.734 ID ST5023 These items are part of PF2139 (O-ring Replacement Kit) Comco Inc. Issue Date: January 2009...
  • Page 96 Bypass Tube Assy PF2498-4** Swing Bolt, Tank Cover PF2079 Tubing, 1/4 OD, Blue MB1233 * 12” Pipe (ST4236) is used on Extended Tanks ** PF2498-4 Bypass Tube Assembly is use on Extended Tanks. Rev 02/09 Comco Inc. B-10 Issue Date: January 2009...
  • Page 97 Conn. Male 3/8T x 1/4P ST4038 Coupling Modulator PF2042 Coil, Modulator MB1310-7 Modulator, Housing [1] PF2040 The Modulator Housing is a Sub-Assembly consisting of three parts typically replaced as one unit. 230V Coil is MB1310-8 Comco Inc. B-11 Issue Date: January 2009...

  • Page 98: Figure 8: P/N Pf2406 Handpiece & Abrasive Hose Assembly

    FIGURE 8: P/N PF2406 HANDPIECE & ABRASIVE HOSE ASSEMBLY Item Description Part No. Tube, Handpiece PF2066 Nose, Assy., Nozzle PF2090 Tube, Abrasive PF2083 Spring, Compression ST5552 Nut & Ferrule Set ST4266 Ferrule Set (only) ST4209 Comco Inc. B-12 Issue Date: January 2009...

  • Page 99: Figure 9: P/N Pf2445 Vent Pinch Assembly

    Appendix B: Drawings and Schematics FIGURE 9: P/N PF2445 VENT PINCH ASSEMBLY Item Description Part No. Plunger, Pinch MB1050-2 Vent Breather, 1/8P ST4003 Elbow, Male, 1/8 Thd ST4224 Cylinder, DBL Spring ST6081 Tube, Pinch MB1282 Comco Inc. B-13 Issue Date: January 2009...

  • Page 100: Figure 10: P/N Pf2450 Powdergate Assembly

    PF2442 O-ring, 2-019 ST5546 O-ring, 2-018 ST5031 Nosepiece MB1653 Air Cylinder Assy [2] PF2471 Fitting, 5/32 OD ST4172 Body, Valve PF2434 Adapter, Cylinder PF2436 Includes a ST5161 O-ring Includes a MB1653 Nose Piece Comco Inc. B-14 Issue Date: January 2009...

  • Page 101: Figure 11: P/N Pf2443 Pressure Regulator Assembly

    ST4004 Replac. Filter Elem. ST6267 Regulator, 3/8 NPT PF2472 Elbow, 3/8Tx1/4 NPT ST4162 Elbow, Street, 1/4 P ST4143 Filter & Check Valve MB1560 Elbow, 1/4Tx1/8 NPT ST4144 Conn. 5/32T x 1/8 P ST4238 Comco Inc. B-15 Issue Date: January 2009...

  • Page 102: Figure 12:P/N Pf2142 Powder Adjustment Assembly

    Bushing, 1/2 x 1/4P ST4125 Filter In-Line, 1/2” 20M ST6232 Check Valve ST6209 Elbow Street, 1/4P ST4143 Elbow, 3/8T x 1/4P ST4142 Valve Needle, 1/4-P PF2148 Knob, Black [1] ST5520 Not Part of this Assembly Comco Inc. B-16 Issue Date: January 2009...
  • Page 103 Bushing, 1/4 FPT x 3/8 MPT ST6256 Valve, Flow Control, Meter In ST4143 Elbow, Street, 1/8 ¼ NPT ST6246-2 Regulator 1/4 NPT, w/Backflow Option 230 VAC Valve, 3-Way is ST6245-3 230 VAC Valve, 2-Way is ST6208-4 Rev 08/09 Comco Inc. B-17 Issue Date: January 2009...
  • Page 104 FIGURE 14: P/N PF1407 & PF1407-2 POWDERGATE VALVE Item Description Part No. Valve, 4-Way, 110VDC ST6265 Muffler, 10-32 Thd ST6263 Elbow, 10-32 Thd ST4198 Elbow, Male, 10-32 Thd ST4222 Conn. Valve, 40” Wires ST6268 230 VAC Valve, 4-Way is ST6265-2 Comco Inc. B-18 Issue Date: January 2009...
  • Page 105 Description Part No. O-ring ST5504 Tank Orifice [1] MB1409-25 Tank Orifice size may be changed. Refer to Chapter 3 of the Manual. This item is part of PF2139 (O-ring Replacement Kit). Rev 11/09 Comco Inc. B-19 Issue Date: January 2009...
  • Page 106 DirectFlo DF1400 Appendix B: Drawings and Schematics THIS PAGE LEFT INTENTIONALLY BLANK Comco Inc. B-20 Issue Date: January 2009...
