URYU UL Series Instruction Handbook Manual

Non shut-off hydraulic impulse tools

Advertisement

Hydraulic Impulse Tools
Intended Use : The tool is designed to tighten or loosen threaded fasteners.
-The tool is intended for professional use only.
-Avoid misuse and abuse of the tool.
(e.g. Do not throw the tool on the floor, strike the housing in any way or use the tool as a hammer to knock material into place.)
'D' Type
UL Series
UL series
Non Shut-off
Instruction Handbook
-Read and understand the safety instructions before installing,
operating, repairing, maintaining, changing accessories on or
working near the hydraulic impulse tool.
Failure to follow the warnings and instructions in this
handbook can result in serious bodily injury.
-Do not discard the safety and operating instructions.
Give them to the operator.
Save these instructions for future reference.
1-2-11, Fukae-Minami, Higashinari, Osaka, 537-0002, Japan
Tel : +81 (0)6 6973 9415
Email: uryuair@uryu.co.jp
UL-S Series
Fax : +81 (0)6 6972 0346
www.uryu.co.jp/english

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UL Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for URYU UL Series

  • Page 1 UL series Non Shut-off Hydraulic Impulse Tools Instruction Handbook -Read and understand the safety instructions before installing, operating, repairing, maintaining, changing accessories on or working near the hydraulic impulse tool. Failure to follow the warnings and instructions in this handbook can result in serious bodily injury.
  • Page 2: Description Of Functions

    Description of Functions Pistol Type Casing Protector Suspension Ring Handle Throttle Trigger Torque Adjuster Hole Forward / Reverse Leve Set the lever to ‘R’ for clockwise operation and ‘L’ for anticlockwise operation. Silencer Air Inlet Lubricate from here. Straight Type Throttle Lever Suspension Ring Air Inlet...
  • Page 3: Safety Instructions

    Safety Instructions General Safety -Only qualified and trained operators should install, adjust or use the tool. Operators and maintenance personnel must be physically able to handle the bulk, weight and power of the tool. -Do not modify the tool. Modifications can reduce the effectiveness of safety measures and increase the risks to the operator. -Stop using the tool if discomfort, tingling feeling or pain occurs.
  • Page 4: Maintenance Instructions

    -After every 100,000 fasteners or 3 months, whichever comes earlier, it is recommended to drain and refill the pulse unit and grease the bearings in the air motor (see table 2). Do not substitute any other fluid. Failure to use the oil specified by URYU.
  • Page 5 Put the pulse unit into the UOF-2 vacuum fill tank and pour the oil specified by URYU into the tank so that the oil level is at least 10mm above from the top of the liner casing (see figure 4).
  • Page 6: Troubleshooting

    Loss of power in the air motor Overhaul the air motor. Should the above steps fail to remedy a problem with the tool, immediately stop using the tool and contact your local URYU distributor or URYU Japan. Find URYU distributor in your country at www.uryu.co.jp/english/network.html.
  • Page 7: Technical Specifications

    We, URYU SEISAKU, LTD., cannot be held liable for the consequences of using the declared values, instead of values reflecting the actual exposure, in an individual risk assessment in a work place situation over which we have no control.
  • Page 8 For further information, contact your nearest URYU distributor or URYU Japan. Find URYU distributor in your country at www.uryu.co.jp/english/network.html. International Dept. +81 6 6973 9415 +81 6 6972 0346 uryuair@uryu.co.jp UL-10-23-2024...

This manual is also suitable for:

Ul30Ul30tmUl30dUl30dtmUl40Ul40tm ... Show all
