Intended Use : The tool is designed for tapping or cleaning threads in holes in metal
or other materials, i.e., wood, concrete, plastic etc.
-The tool is intended for professional use only.
-Avoid misuse and abuse of the tool.
(e.g. Do not throw the tool on the floor, strike the housing in any way or use the tool as a hammer to knock material into place.)
Double-Trigger Type Tapper
UT series
Instruction Handbook
-Read and understand the safety instructions before installing,
operating, repairing, maintaining, changing accessories on or
working near the tapper. Failure to follow the warnings and
instructions in this handbook can result in serious bodily
injury.
-Do not discard the safety and operating instructions. Give them
to the operator. Retain these instructions for future reference.
1-2-11, Fukae-Minami, Higashinari, Osaka, 537-0002, Japan.
Tel : +81 (0)6 6973 9415
Email: uryuair@uryu.co.jp
Tappers
Grip Handle Type Tapper
Straight Tapper
Fax : +81 (0)6 6972 0346
www.uryu.co.jp/english
1
Advertisement
Related Manuals for URYU UT Series
Summary of Contents for URYU UT Series
- Page 1 UT series Tappers Instruction Handbook -Read and understand the safety instructions before installing, operating, repairing, maintaining, changing accessories on or working near the tapper. Failure to follow the warnings and instructions in this handbook can result in serious bodily injury.
- Page 2 For further information, contact your nearest URYU distributor or URYU Japan. Find URYU distributor in your country at www.uryu.co.jp/english/network.html. International Dept. +81 6 6973 9415 +81 6 6972 0346 uryuair@uryu.co.jp UT-2018-01-01...
- Page 3 NOTE...
-
Page 4: Description Of Functions
Description of Functions Double-Trigger Type Tapper Gear Casing Chuck Forwarding Reversing Double Button Handle Air Inlet Lubricate from here. Grip Handle Type Tapper Gear Casing Chuck Built-in Air Regulator Turn clockwise to lower and Throttle Trigger counter-clockwise to increase power. Air Inlet Lubricate from here. - Page 5 -Use the auxiliary handle when the reaction torque absorbed by the operator exceeds 4Nm for UT-60S series straight type tappers, 10Nm for UT-60/66B series pistol grip type tappers. (Part No. for auxiliary handle : 612-896-0 for all UT series) -Always wear impact-resistant eye protection during the operation of the tool. The grade of protection required should be assessed for each use.
-
Page 6: Technical Specifications
We, URYU SEISAKU, LTD., cannot be held liable for the consequences of using the declared values, instead of values reflecting the actual exposure, in an individual risk assessment in a work place situation over which we have no control. - Page 7 Service Manual -Refer to the parts list supplied along with the tool and use the correct jigs for proper service. Contact your local URYU distributor. Removal of Gear Casing from Casing: (for UT-60/66B Series) Fixing the casing in a vice, loosen the gear casing by the spanner (4.8x22x153) (Part No.:937-065-0) to remove the casing from the gear casing assembly.
- Page 8 -Continuous satisfactory operation depends upon proper tool care and regular maintenance. -Have the tool serviced by a qualified repair person. -Use URYU genuine parts for replacement. This will ensure that the safety and the optimum performance of the tool are maintained. Lubrication -It is important to lubricate regularly to get maximum performance and trouble-free operation.
