Qualitrol 505ITM Series Instructions Manual

Intelligent transformer monitor
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
QUALITROL
505ITM Series
QUALITROL
505ITM-100
Intelligent Transformer Monitor
Hardware and Software Instructions
Document ID: IST-104-1 ECN-31022
www.qualitrolcorp.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 505ITM Series and is the answer not in the manual?

Questions and answers

Related Manuals for Qualitrol 505ITM Series

Summary of Contents for Qualitrol 505ITM Series

  • Page 1 QUALITROL 505ITM Series  QUALITROL 505ITM-100  Intelligent Transformer Monitor Hardware and Software Instructions Document ID: IST-104-1 ECN-31022 www.qualitrolcorp.com...
  • Page 2 Legal Information in this document is subject to change without notice. This document is provided to purchasers of Qualitrol products for use in the installation, operation and servicing of such products. No other use, nor any reproduction, distribution or the making of any derivatives of this document is authorized, without the express prior written permission of Qualitrol.

  • Page 3: Table Of Contents

      Overview ........................1   QUALITROL 505 Series Intelligent Transformer Monitor ..........1   About Qualitrol ........................2  About These Hardware Instructions .................. 2  Controls, Indicators, and Modules ................3   Front Panel ........................3  Modules ..........................4  RTD Input Module ....................... 4 ...
  • Page 4 Communications ......................21  Operation ........................ 22   Automatic Operation ......................22  Viewing Channels or Viewing Mode Scrolling ............22  MENU Mode ......................22  Program Mode ......................24  Testing the System ......................24  Functional Specifications ..................25   Software Instructions ................... 27  ...
  • Page 5 Cancel and Load Buttons ..................50  Input Modules ........................51  Module ........................52  Custom Scaling ......................53  CT Current Parameters ..................... 54  Winding Temperature Setup (Calculated) ..............55  Simple Calculation Setup Method ............... 55  Advanced Calculation Setup Method ..............59  Output Relays ........................
  • Page 6 Calibration Procedure ....................93  Installing the USB driver (for use during model setup) ........99   Frequently Asked Questions About the 505ITM ..........100   Appendix INPUT MODULE 1 Input Modules INPUT MODULE 2 INPUT MODULE 3 Optional Heater INPUT MODULE 4 TB1-1,17 EARTH GROUND TB1 TB1...

  • Page 7: Hardware Instructions

    Hardware Instructions Overview QUALITROL 505 Series Intelligent Transformer Monitor  The QUALITROL 505 Series Intelligent Transformer Monitor (505ITM) for Liquid-Filled  Transformers offers microprocessor technology and advanced digital signal processing to accurately assess the health and performance of oil-filled transformers.

  • Page 8: About Qualitrol

    About Qualitrol Qualitrol has been a leader in supplying pressure, liquid level, and temperature controls since 1945. As an ISO 9001 System-certified company, we are committed to providing quality and reliability, both in our products and in our service.

  • Page 9: Controls, Indicators, And Modules

    SET POINT INDICATORS - A red LED illuminates to indicate that the set point for the relay, indicated on the overlay, has been exceeded. RS-232 PORT or USB PORT - When used with the Qualitrol software, this port allows for the setup of all of the parameters of the monitor. See the...

  • Page 10: Modules

    LTCs, or fan currents. The input to the module is a clamp on the CT, provided by Qualitrol, which has an input range of 0 - 5 A, 0 - 10 A, or 0 - 20 A, other ranges are available, and an output of 0 - 0.333 VAC, can be used as the input to the CT Input Module.

  • Page 11: Dc Voltage Input Module

    more information, see the section Using the Factory Calibrator Tool (Advanced users, only) in the Software Instructions. The scaling of the 505ITM for this module is 0 - 100%. DC Voltage Input Module The DC Voltage Input Module is used for monitoring transducer outputs with an output signal in either the 0 - 100 mVDC or 0 - 10 VDC range.

  • Page 12: Installation

    Installation Location and Mounting Installing the Hardware 1. Unpack the 505ITM. 2. Check that all of the materials on the packing slip are included. 3. Make four holes on the transformer panel for installation of the monitor. Important: Note the mounting differences between the enclosure style and the panel-only style. ...
  • Page 13 Installing power outside of the recommended input range will damage CAUTION: the unit. 10. Energize the 505ITM. The monitor briefly displays “Qualitrol” and the version of the board firmware. Important: The following operation can cause the alarm output state to change. 11. On the front panel, press TEST.
  • Page 14 Manager software which is found on the documentation CD-ROM, to view, change, or modify the settings of the 505ITM to meet your requirements. www.qualitrolcorp.com...

  • Page 15: Mounting Styles

    Mounting Styles Enclosure Style The 505ITM is a 3R enclosure style, designed to be back-mounted on any smooth surface. Four 0.31 × 0.50 in. oval slots are provided for use with fasteners. The monitor requires an approximate area that is 11.5 inches in width, 13.0 inches in height, and 6.5 inches in depth. An additional area below the monitor should be allowed for the wiring harness.
  • Page 16 Captive Thumb Screw (2) Places 3.00 [76.3] Suggested Panel Cutout = 7.8 WD x 9.3 HI 12.00 [305] 10.50 [267] (4X) Ø.41 [Ø10] MOUNTING HOLES 17.56 16.00 19.06 [446] [406] [484] 11.08 [281] Mounting the 505ITM www.qualitrolcorp.com...

  • Page 17: Power Supply

    Power Supply Supply power is applied to Terminal Block TB2 terminals 3 and 5. For DC input, positive voltage is applied to terminal 3, and ground or negative voltage is applied to terminal 5. Chassis ground is applied to terminal 1, as shown in the Power Supply Connection figure. This non-metallic enclosure does not automatically provide a common grounding lug.

  • Page 18: Heater Option

    RTD Input Wiring Connections If you are upgrading an existing Qualitrol device, or if the RTD you have installed is a four- wire RTD, DO NOT connect the fourth wire in parallel with the third wire, this will adversely affect the compensation scheme.

  • Page 19: Ct Input Module

    Input the current range as specified. Pull the supplied Qualitrol clamp on CT Sensor apart and place the wire which carries the current to be sensed, into the CT opening. Push the CT sensor back together and check that it is fully engaged.

  • Page 20: Ac Voltage Input Module

    For each Potentiometer Input Module, one standard potentiometer in the range of 1500 - 15000 ohm, as supplied by various Qualitrol case assemblies, is required to measure liquid level, flow, or gas accumulation. The module must be calibrated on site. See the...

  • Page 21: Dc Voltage Input Module

    DC Voltage Input Module For each Voltage Input Module, one voltage transducer, 0 - 100 mVDC or 0 - 10 VDC, as specified, is required. Connect the output wires of the transducer to the terminal block as shown in the DC Voltage Input Wiring figure.
  • Page 22 Current Input Wiring www.qualitrolcorp.com...

  • Page 23: Dry Contact Closure Input Module

    Dry Contact Closure Input Module The Dry Contact (Switch) Closure Input Module is designed to detect the actuation or de- actuation of one dry, non-powered switch contact. The system internally treats closed and open contacts as either a 0 or 100 numeric value. Therefore, if the module is used to control a relay, the relay set point should be set at midrange, e.g., 50.

  • Page 24: Output Contacts

    Output Contacts Five isolated sets of normally open/normally closed output contacts, for Output Relays 1 - 4 and the System State Output Relay, are provided for controlling cooling equipment, sounding an alarm, or operating remote breaker coils. Each set is capable of switching 115/230 VAC, 30 VDC @ 10 A, and the sets are accessed on Terminal Block TB1, see the Relay Wiring figure for the Enclosure and Panel Mount monitors.
  • Page 25 Relay Wiring www.qualitrolcorp.com...

  • Page 26: Remote Output Signals

    Remote Output Signals The monitor is configured to supply two milliamp (mA) current outputs for remote indication or use with SCADA devices. This output is proportional to the full scale of the parameter selected in the configuration. Refer to section, for maximum load. Functional Specifications The output signals are accessed on Terminal Block TB1 terminals 29 through 32, See the Remote Output Signal Terminals figure for the Enclosure and Panel Mount monitors.

  • Page 27: Communications

    If the operator is using a two-wire, RS-485 connection with the 505ITM, short TXD+(B) with RXD+(B), and TXD-(A) with RXD-(A), then connect the two-wire, RS-485 as an A/B system. The RS-485 connection may be used with the Qualitrol Remote Software Package and other available protocols. Refer to the...

  • Page 28: Operation

    60 seconds, the monitor automatically reverts to Auto Scroll, or press MENU again to revert the system back to Viewing Mode Scrolling. Note: To avoid any erroneous readings caused by the installation, Qualitrol recommends resetting the maximum values immediately after setting up the monitor. www.qualitrolcorp.com...
  • Page 29 60 seconds, the monitor automatically reverts to Auto Scroll, or press MENU again to revert the system back to Viewing Mode Scrolling. Note: To avoid any erroneous readings caused by the installation, Qualitrol recommends resetting the minimum values immediately after setting up the monitor. Viewing TransLife...

  • Page 30: Program Mode

    Program Mode MENU, View Mode Scrolling, Right Arrows From Viewing Mode, keep pressing the Right Arrow until you reach the Change Settings column. Press ENTER to go to Change Settings Mode. This is the location where you can change some of the settings of the monitor. This mode is protected. Before you are allowed to change any parameters, you must first enter the program user ID #.

  • Page 31: Functional Specifications

    Functional Specifications Power Supply Universal; 90 - 264 VAC, 47 - 63 Hz and 40 - 290 VDC; (< 30 watts, AC in; < 15 watts, DC in) Front Panel Display: One easy-to-read 2-line, 16-character alphanumeric and Interface Liquid Crystal Display (LCD). Character size: 0.38" (9.66 mm) high x 0.19"...
  • Page 32 Outputs Control/Alarm Contacts: Four Form C relay contacts for cooling control, alarms, trip, etc. Diagnostics Alarm: One Form C relay for power, sensors and internal circuitry diagnostics Heater Control: One relay Relay Contact Ratings: 10A @ 115/230 VAC, 10A @ 30 VDC Remote (SCADA) Two loops;...

  • Page 33: Software Instructions

    Installing/Running the Software The software runs on Microsoft Windows NT, 98, 2000, XP, and Vista operating systems. You can run the software directly from the CD provided by Qualitrol or from files installed on your PC. To install the software from the CD: 1.

  • Page 34: Desktop Communications Window

    Desktop Communications Window The Desktop Communications window provides the communications interface with the 505ITM and your PC. The software automatically loads a default communications data file named default505ITM.qco on your desktop when it opens the Desktop Communications window. File Menu The File pull-down menu provides several options for selecting a communications file.

  • Page 35: Establishing Communications With The 505Itm

    Establishing Communications with the 505ITM From the Desktop Communications window, select, set, or observe the following items as required: Address Each 505ITM has an assigned address that allows multiple 505ITMs to be used with a common communication link. The factory default configuration has an address of 00.
  • Page 36 Close All Closes all open 505ITM applications, terminates communications, and Button closes the Desktop Communications window. The Save Communication Setup window displays if any communications parameters have been changed and not saved before clicking [Close All]. A successful communications link is indicated when: No error message displays.

  • Page 37: Troubleshooting The Communications Link

    Troubleshooting the Communications Link If a problem occurs in establishing a communications link between the PC and the 509 ITM, check the following: Is the cable a straight-through cable (not a null) and is it securely connected to the PC ...
  • Page 38 If required, call Qualitrol Application Calibrator Engineering at 585-586-1515 x 410. Customer Setup 111111 The Factory Setup tool can only be entered by Qualitrol factory personnel. This section is reserved for the factory except in the Demo mode (offline). Remember Me...

  • Page 39: Opening A Tool

    Opening a Tool To open any of the 505ITM software tools, do the following: 1. Establish communications with the 505ITM. 2. From the Desktop Menu window, enter the correct password for the tool you wish to start. Note: If the Remember Me feature is enabled, you do not have to enter a password.
  • Page 40 There are eight control buttons on your PC screen: Test, Reset, Menu, Enter, Up, Down, Left, and Right. These buttons are activated by clicking on them with the left mouse button. Activating a button in this way has the same effect as pressing the same button on the 505ITM monitor itself.

  • Page 41: Using The Simulator Tool

    Using the Simulator Tool The Simulator tool allows you to simulate values regardless of the actual inputs that the sensors register. The 505ITM responds to the input signal changes from the Simulator window as if the signals originated in the field. This mode is useful for testing items such as relay connections and wiring.

  • Page 42: Using The Factory Calibrator Tool (Advanced Users Only)

    Using the Factory Calibrator Tool (Advanced users only) The Factory Calibrator tool allows you to calibrate most inputs. When you first enter the Calibrator - Signal Selection window, the Input 1 channel is selected by default. Important: All channels, except for the Potentiometer Input module, are calibrated at the factory.
  • Page 43 Calibrating the Input Channels 1. Open the Factory Calibrator tool. 2. Select the input channel to calibrate. 3. Click [Calibrate]. The Input Channel Calibration window displays. 4. In the terminal block that corresponds to the input module being calibrated, enter the signal value displayed in the Set input signal to field.
  • Page 44 Calibrating the Output Channels The analog outputs can be adjusted in a four-point calibration; see the Output Calibration section of the manual for more details. However, this calibration should not be necessary because it is done at the factory. Saving Calibrations in Files You can save calibration values in files using the File pull-down menu.

  • Page 45: Using The Setup Tools

    Using the Setup Tools The User Setup tool allows you to set all the adjustable parameters of the 505ITM. The Factory Setup tool is used to set the hardware configurations of the monitor. The Customer Setup limits access to some of the 505ITM parameters, such as serial number, manufacturing date, and configuration date.
  • Page 46 The Setup windows have three main sections: Model Displays the fields for Serial number, Manufacturing date, and the last Information Configuration date of the 505ITM. The Configuration date field displays when the 505ITM was last updated. Model Type Displays that the monitor is a Transformer Monitor. System Index Displays the system buttons required to set up and view the parameters of the 505ITM.

  • Page 47: System Settings

    System Settings The System Settings window opens when you click [System Settings] from the Setup window. This window allows you to set the configuration for the items displayed in the different sections of the window. More Information Password Setup  Installed Features ...

  • Page 48: Password Setup

    Password Setup This section of the System Settings window allows you to configure the passwords that provide access for the different software tools. The passwords are stored in the 505ITM and have the following characteristics and requirements: Passwords consist of one to six alphanumeric characters, and they are case-sensitive. ...

  • Page 49: Installed Features

    Installed Features This section of the System Settings window displays the installed features available in the 505ITM. If a feature is installed, there will be a check mark in the check box next to the legend. Time and Date Setup This section of the System Settings window allows you to configure the time and date values...

  • Page 50: Display Setup

    Time Zone Allows you to adjust for a difference in time zones between the location of Difference setup and the location of the installed 505ITM. If the two locations are the same, set the value to 0. Otherwise, select the appropriate number of hours, positively or negatively, to provide for a correct time at the installation location.

  • Page 51: Heater Setup

    Heater Setup This section of the System Settings window allows you to configure the 505ITM Heater option. The Heater is not a standard feature and has to be ordered. It is used in extremely cold or moist environments. The Heater is controlled by a 505ITM internal temperature measurement.

  • Page 52: Communications

    Communications The Communications Setup window opens when you click [Communications] from the Setup window. This window allows you to configure the 505ITM communications ports displayed in the different tabs of the window. More Information Front USB - Service Port  Front Serial –...

  • Page 53: Front Usb - Service Port

    Front USB - Service Port This section of the Communications Setup window includes the fields described below. Type Indicates the type of signaling hardware used for the Service Port. This field is for informational purposes only. Configures the baud rate that is used to communicate over the USB Baud Rate Service Port at the front panel.

  • Page 54: Front Serial - Service Port

    Front Serial - Service Port This section of the Communications Setup window includes the fields described below. Type Indicates the type of signaling hardware used for the Service Port. This field is for informational purposes only. Configures the baud rate that is used to communicate over the RS232 Baud Rate Service Port at the front panel.

  • Page 55: Main 485 - Main Port

    Selects the duplex type used for communications. If using a 2-wire duplex remember to add jumpers to terminal block TB1 as explained in the Hardware section under Communications. Installed The Qualitrol ITM Manager software comes standard with every 505ITM Protocol unit. Optional Note: All of these options are upgradeable by the factory.

  • Page 56: Aux 485 - Auxiliary Port

    Protocol Selects between the available communications protocols to be used by the Main Port communications. Address Indicates the communication address of the 505ITM used by the specified protocol. Baud Rate Selects the desired baud rate for the Main Port communications protocol. The default value is 9,600.

  • Page 57: Input Modules

    Input Modules The Input Module Setup window opens when you click [Input Modules] from the Setup window. The 505ITM has up to four input modules. The types of available modules are described in the section of the Hardware Instructions. Modules To begin, click the tab of the input module that you want to configure.

  • Page 58: Module

    Module This section of the Input Module Setup window includes the fields described below. Input Module Indicates the input module number that is being configured. This field is Number for informational purposes only. Input Module Indicates what module type was installed in this corresponding site of the Type 505ITM.

  • Page 59: Custom Scaling

    Custom Scaling The configuration parameters in this section of the Input Module Setup window allow you to change the scaling of the process input signal. Custom Scaling is not available if the Input Module Type field is set to a "Logic Switch" or "AC/DC Input". For “Temperature” input modules, for example, “RTDs”, “Ambient”, and “CT, Temperature”...

  • Page 60: Ct Current Parameters

    CT Current Parameters If the Input Module Type field is set to "CT, Current" or ”CT, Temperature,” this section of Input Module Setup window provides linear scaling between the 505ITM output and the actual current sensed by the Power Transformer CT. The fields in this section are described below.

  • Page 61: Winding Temperature Setup (Calculated)

    Winding Temperature Setup (Calculated) This section of the Input Module Setup window allows you to configure the "CT, Temperature" input module type. The checked box indicates which winding calculation method is active. Click either method to open the corresponding setup window. Simple Calculation Setup Method ...
  • Page 62 More Information Input Module Number and Input Signal Name Fields  Winding Rise Parameters  Oil Rise Parameters  www.qualitrolcorp.com...
  • Page 63 Input Module Number and Input Signal Name Fields This section of the Simple CT Temperature Scaling Setup window includes the fields described below. Input module Displays the input module number for which the simple “CT, number Temperature” scaling parameters are being configured. Input signal Displays the user-assigned name of the signal for which the simple “CT, Temperature”...
  • Page 64 If the time constant is unknown, the IEEE Std C57.91-1995 Annex G recommends a value between 3 and 7 minutes. Qualitrol uses a default value of 6 minutes. Oil Rise Parameters...

  • Page 65: Advanced Calculation Setup Method

    Advanced Calculation Setup Method This method allows you to configure the advanced scaling parameters for input module types that are set to “CT, Temperature.” The advanced calculation method is capable of adapting the winding temperature model for all the different stages of cooling, thereby giving a more accurate response than the Simple Calculation Method.
  • Page 66 The Importance of Winding Temperature and Cooling Paper insulation used in transformers contains organic materials that deteriorate over time at elevated temperatures. Cooling that is activated too slowly allows elevated temperatures to degrade this insulation. Cooling systems that are activated too early or too often will lead to reduced fan and/or oil pump life.
  • Page 67 Advanced Winding Rise Parameters This section of the Advanced CT Temperature Scaling Setup window includes the fields described below. Cooling Relay Allows you to input the relay number that controls the cooling system for (3 fields) each cooling stage. Example: Relay 2 controls fan bank 1, Relay 3 controls fan bank 2, and Relay 4 energizes the oil pump.
  • Page 68 Cooling Modes. The exponent describes the “rise” curve of the winding temperature above the oil temperature. When installing a 505ITM on older transformers, this information might be difficult to obtain. In those cases, Qualitrol recommends:  For ONAN (natural convection): 1.6 ...
  • Page 69 Oil Time Allows you to set the time constant for the temperature rise of this Constant winding. The time constant is defined as the time it takes the winding (4 fields) temperature to reach 63.2% of its final value for a given current input. Note: It takes approximately five time constants to elapse for the temperature to reach full value for a given load.

  • Page 70: Output Relays

    Output Relays The Output Relay Setup window opens when you click [Output Relays] from the Setup window. This window displays the tab array of the four relays with the Relay 1 tab being selected. By selecting the different tabs, you can index through the relay array. To begin, click the tab of the output relay that you want to configure.

  • Page 71: Relay Tabs

    Relay Tabs This section of the Output Relay Setup window includes the fields described below. The tabs at the top of the window allow you to select which relay to Relay 1 - Relay 4 display for setup. System Status The system relay is actuated by: Relay ...
  • Page 72 If the setpoints are exceeded or if the monitor loses power, the normally closed and common contacts are shorted together. Important: Qualitrol recommends setting any trip contacts for a transformer to Non-failsafe. See the following table for further clarification of Failsafe/Non-failsafe operation.
  • Page 73  Manual / Manual: The relay actuates regardless of the setpoint values. Automatic  Automatic: The relay actuates according to the Control Signal Matrix table and other function settings. This feature can be toggled through the communication channels, which allows you to actuate a relay remotely.

  • Page 74: Seasonal Setpoint

    Seasonal Setpoint This section of the Output Relay Setup window includes the fields described below. Seasonal A check mark indicates that the Seasonal Setpoint feature is installed. This feature only affects the setpoint for the Control Signal 1 column in setpoint installed the Controlled by Matrix section.

  • Page 75: Ambient Temperature Forecast

    To set the Seasonal Setpoint: 1. Enter the appropriate information in the following fields:  Start Date: Select the Month and Day when the Seasonal Setpoint becomes active.  End Date: Select the Month and Day when the Seasonal Setpoint is discontinued. Normal setpoint operation resumes the day after this date.

  • Page 76: Configure Button

    Configure Opens the window that allows you to configure the Ambient Temperature Button Forecast feature. This window provides a common path for setting the values of the Ambient Temperature Forecast feature for all eight relays. This function measures the ambient temperature for a specified amount of time and allows you to adjust the setpoint for relay operation during forecasted periods of high temperatures.
  • Page 77 To set the Ambient Temperature Forecast: 1. Enter the appropriate information in the following fields:  Controlled By: Select a temperature signal source to use in forecasting the temperature. This should be an ambient temperature probe. Note: If the 505ITM does not have an ambient temperature probe installed as one of its input modules, this feature cannot be used.

  • Page 78: Cooling Equipment Exerciser

    specified number of hours. 2. Click [Load]. Example: If the ambient temperature exceeds 30C for at least 12 hours over the previous 120 hours, the effective setpoint for the first column is 50C. Cooling Equipment Exerciser The Cooling Equipment Exerciser actuates the relay for a set period of time at a specified interval of days.

  • Page 79: Matrix Controlled

    Matrix Controlled This section of the Output Relay Setup window provides a variety of input signal configurations and logic to control the relay actuation. For example, using the math function “or”, you can actuate the relay with a maximum of four different input signals. Conversely, by using the “or”...
  • Page 80 Math Allows you to enter a math function in each of the three available fields. Expression The first and third fields allow the math functions “or”, “and”, and “minus”. (3 fields) The second field allows only “or” and “and”. The “minus” function(s) are first evaluated in the matrix math expression.

  • Page 81: Cancel And Load Buttons

    hour window no longer has an absolute increase of 100 PPM. This same feature can be used for a falling control signal if the actuation direction is set to ‘down’. Rate of The Rate of change time period is the rolling time period used to measure change the absolute change in the control signal one.

  • Page 82: Output Loops

    Output Loops The Output Loops Setup window opens when you click [Output Loops] from the Setup window. This window allows you to configure the two current loop output channels. The 505ITM is equipped with two software selectable 0 - 1 mA or 4 - 20 mA (0 - 10 mA on request) outputs to provide information to Supervisory Control &...

  • Page 83: Loop Parameters

    Loop Parameters This section of the Output Loops Setup window includes the fields described below. Output Loop Displays the number of the analog current loop that is to be configured. Loop function Allows you to enable or disable the output loop operation. Loop type Allows you to select between current loop ranges of 0 - 1 mA and 4 - 20 Note:...

  • Page 84: Loop Controlled

    Loop Controlled This section of the Output Loops Setup window allows up to three different input measurements and two math functions to correspond to the analog output loop. You can set up the current output loops to be controlled by one of these three options: a single input measurement ...
  • Page 85 You can bank switch more than two relays in a loop, but this can only be accomplished if the bank switching loop is closed or completed after the setup. This means that the last relay of the bank switching loop must select the first relay of the loop. Example: If Relay 2 selects “Relay 3”, and Relay 3 selects “Relay 4”, you must set up Relay 4 to select “Relay 2”...

  • Page 86: Translife

    TransLife™ The TransLife Setup window opens when you click [TransLife ] from the window. Setup The TransLife feature provides detailed information for a winding temperature of the transformer. More Information TransLife Control  Consumed Life  Critical Forecast  Temperature Profiler ...

  • Page 87: Translife Tm Control

    TransLife Control This section of the Setup window allows you to configure the TransLife TransLife settings for the individual winding temperatures. It includes the fields described below. Enable / Allows you to enable or disable the TransLife feature. Disable Winding Allows you to select the number of the input module, or if suitably Temperature equipped, the fiber optic probe that will measure the winding...

  • Page 88: Consumed Life

    Consumed Life The 505ITM calculates relative “life consumption” according to IEEE standards. These standards are based on the Arrhenius formulas for deterioration of organic insulation material with time and temperature. Each 6 - 8 degree increase in temperature approximately doubles the rate of life decay. Based on the cumulative exponential affects of temperature over time, life consumption metering helps to prioritize maintenance activities between transformers.

  • Page 89: Critical Forecast

    Present Loss Displays the consumed life rate of the winding at this instant in time. of Life Rate Example: If the Unity Hot Spot Temperature is 110° C and the winding is reading exactly 110° C, the present loss of life rate is 1.00. Loss of Life in Displays the consumed life lost in the past hour.
  • Page 90 The Critical Forecast section includes the fields described below. Critical Allows you to enter three temperature values for monitoring the time it Temperature takes for the winding temperature to reach the present load conditions. (3 Range fields) Time to Displays the time calculated for the winding temperature to reach the Critical critical setpoint values, given the present loading, oil/winding Temperature...

  • Page 91: Temperature Profiler

    Temperature Profiler This section of the Setup window allows you to configure the Temperature TransLife Profiler. The Temperature Profiler has 12 ranges of temperature values - six ranges each above and below the value in the Unity Temperature field. The Temperature Profiler monitors how many hours the measured winding temperature remains in each temperature range.
  • Page 92 www.qualitrolcorp.com...

  • Page 93: Importing And Exporting Configuration Files

    Importing and Exporting Configuration Files Configurations can be saved as files. This is convenient if: you want to restore the 505ITM to its original settings  you want to configure a 505ITM offline and import this configuration at the site ...

  • Page 94: Calibrating The 505Itm

    2. Click [Connect] and enter the password for the Calibrator tool. Note: If you do not know this password, call Qualitrol at 585-586-1515, Ext. 410. 3. Click [Start]. The Calibrator - Signal Selection window displays with the radio button for Input 1 selected.
  • Page 95 Be extremely careful in the Calibrator tool. Changing calibration values CAUTION: incorrectly might cause the 505ITM to malfunction. 4. Connect the ammeter (or multi-meter set to measure DC milliamps) to TB1 pins 29 and 30 with the positive probe on 29. 5.
  • Page 96 6. Click [Next] until you reach the Output Channel Calibration window. The Adjust output signal to field displays 4.80 mA, which is the value used to calibrate for a 4 - 20 mA current loop output. Output Channel Calibration 7. Adjust the slide bar control until the ammeter displays the correct lower calibration value for the new current loop output range.
  • Page 97 8. Click [Next]. The Output Channel Calibration window displays again. Output Channel Calibration 9. Adjust the slide bar control until the ammeter displays the correct upper calibration value for the new current loop output range. Current Loop Upper Output Range Calibration Value 4 - 20 mA 20.00 mA...

  • Page 98: Calibrating A Level Gauge To The 505Itm

    Calibrating a Level Gauge to the 505ITM Overview All of the input modules on the 505ITM are calibrated at Qualitrol, except for the Potentiometer (Level Gauge) input modules. These modules and sensor inputs are specific to the transformer with which they are associated and must be calibrated on the transformer.
  • Page 99 Calibration Procedure Connect the computer to the 505ITM start the Remote Software. The Desktop Menu window displays. 2. Click [Connect] and enter the password (505) for the Calibrator tool. 3. Click [Start]. The Calibrator - Signal Selection window displays with the radio button for Input 1 selected.
  • Page 100 4. Click the radio button for the input module that displays “Potentiometer.” In the example above, this is Input 3. Check again that you have selected the correct input module before CAUTION: proceeding. Calibrating any other input module could erase the system’s calibration values and cause the 505ITM to malfunction.
  • Page 101 www.qualitrolcorp.com...
  • Page 102 The Input Channel Calibration window displays. The Set input signal to field prompts you to set the pointer to minimum (“MIN”). 6. Adjust the case face until the pointer is set at the minimum position. Case face adjusted with the pointer (and potentiometer) moved to minimum 7.
  • Page 103 The Input Channel Calibration window now prompts you to set the pointer to maximum (“MAX”). 8. Adjust the case face until the pointer is set at the maximum position. Case face adjusted with the pointer (and potentiometer) moved to maximum www.qualitrolcorp.com...
  • Page 104 9. Click [Finish]. The Level Gauge is now calibrated to the 505ITM. The Minimum value will read 0% on the LCD display and the Maximum value will read 100%. 10. Immediately exit the Calibrator tool. 11. To use the Level Gauge for alarm setpoints: (a) Adjust the case face until the pointer is set to an alarm value, either low or high.
  • Page 105 Installing the USB driver (for use during model setup) Install the latest CP210X Drivers applicable to your operating system. The Microsoft Windows version is available on the CD-ROM sent with the ITM or the very latest can be obtained from the Silicon Laboratories website: http://www.silabs.com/products/mcu/Pages/USBtoUARTBridgeVCPDrivers.aspx.
  • Page 106 Frequently Asked Questions About the 505ITM In the Simple CT Temperature Scaling Setup window, what is the “Oil Temperature Adder”? And where do I get the values for the other three variables? Simple Calculation Setup Method, which uses the Simple CT Temperature Scaling Setup window, calculates the winding temperature of the transformer by using the oil temperature of the transformer and the load or current running through the windings.
  • Page 107 What is the difference between failsafe and non-failsafe for a relay? In the 505ITM, Qualitrol uses Form C relays. These relays have three contacts: normally open, normally closed, and common. When the monitor has no power applied, the common and normally closed contacts are shorted together, while the common and normally open contacts are open.
  • Page 108 109.73 ohm 146.06 ohm Because of the small resistance values in an RTD sensor, Qualitrol recommends a maximum of 75 feet of cable length. A typical application to measure the resistance (temperature) changes in an RTD is for a monitor to send an excitation current through the RTD and then measure the voltage across the device.
  • Page 109  contact Qualitrol about updating the 505ITM unit in the field (purchasing a new module and getting an update software disk). 2. The calibration for the RTD Input Module has been altered or overwritten. If the 505ITM was incorrectly recalibrated in the field, reinstall the factory calibration settings.

  • Page 110: Wiring Diagram

    Appendix INPUT MODULE 1 Input Modules INPUT MODULE 2 INPUT MODULE 3 Optional Heater INPUT MODULE 4 TB1-1,17 EARTH GROUND TB1 TB1 VAC LINE INPUT (+) VAC LINE VACC NEUT HEATER HEATER RS-485 VACC NEUT INPUT (-) RELAY 1 Input Power TXD+(B) 10 A Interface...
  • Page 114 down/enter enter OPERATING HOURS RELAY 4 TOTAL 013992 HRS MAN/AUTO AUTO down/enter enter TEMP < 80 C TOP OIL CHAN 1 000171 HR down/enter enter TEMP 80 - 86 C WIND 1 CHAN 2 000200 H down/enter enter TEMP 86 - 92 C WIND 2 CHAN 3 000207 H down/enter...
  • Page 115 Index exporting configuration files, 86 about Qualitrol, 6 about the hardware instructions, 6 file menu, 29 AC voltage four wire RS-485 connection, 22 input connections, 16 framework window, 29 input module, 8 frequently asked questions, 98 advanced calculation setup, 59...
  • Page 116 potentiometer software instructions, 28 input connections, 16 system setup, 42 input module, 8 power supply, 13 power up, 23 powered contact temperature profiler, 84 closure module, 9 testing the system, 25 wiring, 19 time configuration, 44 program mode, 25 translife, 62, 79 translife control, 80 troubleshooting the communications link, 32 relay...
  • Page 117 It is the global leader in sales and installations of transformer asset protection equipment, fault recorders and fault locators. Established in 1945, Qualitrol produces thousands of different types of products on demand, each customized to customers' unique requirements.
