Version 1.00 | 06/13/2024
User Manual
5G Multi-Connect Modem
DWM-314-G

Advertisement

loading
Need help?

Need help?

Do you have a question about the DWM-314-G and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for D-Link DWM-314-G

Summary of Contents for D-Link DWM-314-G

  • Page 1 Version 1.00 | 06/13/2024 User Manual 5G Multi-Connect Modem DWM-314-G...
  • Page 2 5G Multi-Connect Modem Chapter 1 Introduction ............................4 1.1 Introduction ............................4 1.2 Contents List ............................5 1.2.1 Package Contents ........................5 1.3 Hardware Configuration ........................6 1.4 LED Indication ............................8 1.5 Installation& MaintenanceNotice ....................... 8 1.5.1 SYSTEM REQUIREMENTS ....................... 8 1.5.2 WARNING ..........................
  • Page 3 5G Multi-Connect Modem 3.2.2 Routing Information ........................ 33 3.3 System ..............................34 3.3.1 System Time ..........................34 3.3.2 System Information ......................... 35 3.3.3 Scheduling ..........................35 3.3.4 Data Cap ............................ 36 Chapter 4 Security .............................. 37 4.1 VPN ................................ 37 4.1.1 OpenVPN ...........................
  • Page 4 Chapter 1 Introduction 1.1 Introduction Congratulations on your purchase of D-Link’s 5G Multi-Connect Modem. With this 5G Modem you have made a great first step in the world of connected Internet of things (IoT) by simply inserting a SIM card from the local mobile carrier into this device to get things connected.
  • Page 5 5G Multi-Connect Modem 1.2 Contents List 1.2.1 Package Contents #Standard Package Items Description Contents Quantity DWM-314-G 1pcs 5G Multi-Connect Modem Cellular Antenna 4pcs RJ45 Cable 1pcs 2 Pin Terminal Block 1pcs Power Adapter 1pcs (12V/1A) 1 set DIN-Rail Bracket (DIN rail: screw x3)
  • Page 6 5G Multi-Connect Modem 1.3 Hardware Configuration  Front View System Ethernet Reset Port Button Indicators ※Reset Button RESET button provides user a quick and easy way to restore the default setting. Press the RESET button continuously for more than 8 seconds, and then release it. The device will restore to factory default settings...
  • Page 7 5G Multi-Connect Modem Right View  Antenna Slot Antenna  Left View Power Antenna Antenna (2pin TB)
  • Page 8 5G Multi-Connect Modem 1.4 LED Indication LED Color Indication Description Steady On: Device power is on Blue Off: Device power is off Power Blue and Steady On: Cellular is registering to network. Blue Blue and Flash: Cellular is not registered to network. Cellular Bule and steady on: The device registers to 5G network Blue...
  • Page 9 5G Multi-Connect Modem Internet Explorer 8.0 or higher • Chrome 2.0 or higher • Firefox 3.0 or higher • Safari 3.0 or higher • 1.5.2 WARNING Only use the power adapter that comes with the  package. Using a different voltage rating power adaptor is dangerous and may damage the product.
  • Page 10 5G Multi-Connect Modem Federal Communication Commission Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 11 5G Multi-Connect Modem 1.5.3 HOT SURFACE CAUTION CAUTION: The surface temperature for the metallic enclosure can be very high! Especially after operating for a long time, installed at a closed cabinet without air conditioning support, or in a high ambient temperature space.
  • Page 12 5G Multi-Connect Modem 1.5.4 Product Information for CE RED Requirements The following product information is required to be presented in product User Manual for latest CE RED requirements. (1) Frequency Band & Maximum Power Band Number Frequency Band Max. Output Power WCDMA Band 1 1920 ~ 1980 MHz 24 dBm...
  • Page 13 5G Multi-Connect Modem 1.6 Hardware Installation This chapter describes how to install and configure the hardware 1.6.1 Mount the Unit The device can be placed on a desktop, or use extender to place on DIN-Rail bracket or mount on the wall. 1.6.2 Insert the SIM Card WARNING: BEFORE INSERTING OR CHANGING THE SIM CARD, PLEASE MAKE SURE THAT POWER OF THE DEVICE IS SWITCHED OFF.
  • Page 14 5G Multi-Connect Modem 1.6.3 Connecting to the Network or a Host The DWM-314-G provides four RJ45 ports to connect to 10/100/1000 Mbps Ethernet. It can auto detect the transmission speed on the network and configure itself automatically. Connect one Ethernet cable to the RJ45 port (LAN) of the device and plug another end of the Ethernet cable into your computer’s network...
  • Page 15 5G Multi-Connect Modem Chapter 2 Status 2.1Cellular 2.1.1.Network Network Page Item Description Mode Network type NAT Link Status Display cellular network status connected or disconnected. IP address Base station distribution network IP Netmask Display cellular network netmask Gateway Display cellular network gateway...
  • Page 16 5G Multi-Connect Modem 2.1.2Modem Modem information Page Item Description IMEI Display modem IMEI information Advanced Information Click advanced button to show Advanced Information...
  • Page 17 5G Multi-Connect Modem Advanced Information Page Item Description IMEI Display modem IMEI information Temperature Module temperature 4G Band capability 4G support band 5G Band capability 5G support band Service Information Page Item Description Display card slot Sim status Display read sim status Register status Display base station registration status registered or not register Operator...
  • Page 18 5G Multi-Connect Modem Advanced Information Page Item Description Display modem IMEI information Module temperature Roaming Roaming status no or roaming Cell id Cell id Band Connected frequency band Location Area Code Tracking Area Number...
  • Page 19 5G Multi-Connect Modem 2.1.3 Signal Cellular Signal Page Item Description Service type Cellular service type LTE /5G Operator Operator name RSSI Display Received Signal Advanced Information Click advanced button to show Advanced Information Advanced Information Page Item Description RSSI Display Received Signal RSRP Display Signal Received Power RSRQ...
  • Page 20 5G Multi-Connect Modem 2.1.4 Data Usage (Refer to 3.3.4) 2.2 Network Network Page Item Description Client List Display connected client list 2.3 Security 2.3.1 VPN OpenVPN client name Page Item Description Openvpn client #1 Click advanced button to display the VPN connection status...
  • Page 21 Display connected or disconnected Chapter 3 Setup The DWM-314-G connects to a machine via the Ethernet interface for 3G/4G/5G network connection. The DWM-314-G also provides another function with NAT router. It can help the network application to be more flexible. 3.1 Network...
  • Page 22 5G Multi-Connect Modem Set the IP of Ethernet and DHCP service Ethernet Enable specified port or protocol for service on connected device. Port Forwarding Register a dynamic host name for the unit. DDNS 3.1.1 Device Mode Device Mode Item Value setting Description 1.
  • Page 23 5G Multi-Connect Modem database. 2. By default Auto is Manual selected User must set APN manually. 1. A Must-fill setting Enter the APN you want to use to establish the connection. This is a must-fill setting if you selected Manual APN as APN scheme. Manual APN 2.
  • Page 24 5G Multi-Connect Modem Policy Setting Item Value setting Description Number of failed connections, After the number of times is reached, 1. 0 By default switch the SIM Failed connection 2. Unchecked by default When the signal is less than the set value, the SIM will be switched 1.0 By default RSSI Monitor 2.
  • Page 25 5G Multi-Connect Modem Static IP Configuration Item Value setting Description 1. IPv4 format. The Static IP Address setting of this unit. 2. A Must-fill setting 255.255.255.0 (/24) is Subnet Mask The Subnet Mask of this configured static IP. set by default 1.
  • Page 26 5G Multi-Connect Modem DHCP Setting Item Value setting Description 1. Numberic string The IP Pool of this DHCP Server. It is Starting Address entered in this IP Pool Start format. field. 2. A Must-fill setting 1. Numberic string The IP Pool of this DHCP Server. It is Ending Address entered in this IP Pool End format.
  • Page 27 5G Multi-Connect Modem DHCP IP Fixed Mapping Item Value setting Description The name of current rule. 1. String format can be Name any text 2. A must-fill setting 1. IPv4 format. Fixed IP The IP Address of this mapping rule. 2.
  • Page 28 5G Multi-Connect Modem Virtual Server Item Value setting Description The box is unchecked Check the Enable box to activate this port forwarding function Virtual Server by default Click Add will pop-up Virtual Server Rule Configuration page. Virtual Server Rule Configuration Item Value setting Description...
  • Page 29 5G Multi-Connect Modem When “UDP(17)” is selected It means the option “Protocol” of packet filter rule is UDP. Public Port selected a predefined port from Well-known Service, and Private Port is the same with Public Port number. Public Port is selected Single Port and specify a port number, and Private Port can be set a Single Port number.
  • Page 30 5G Multi-Connect Modem 3.1.5 DDNS To host your server on a changing IP address, you have to use dynamic domain name service (DDNS). Therefore, anyone wishing to reach your host only needs to know the domain name. Dynamic DNS will map the name of your host to your current IP address, which changes each time you connect your Internet service provider.
  • Page 31 5G Multi-Connect Modem 3.2 Routing Routing Item Value setting Description The box is unchecked Static Routing Check the Enable box to activate this function. by default The routing information allows user to view the routing table and Routing Information policy routing information. 3.2.1 Static Routing "Static Routing"...
  • Page 32 5G Multi-Connect Modem Static Routing Rule Configuration Item Value setting Description The box is unchecked Check the Enable box to activate this function. Name by default Click Add will pop-up Static Routing Rule Configuration page. 1. IPv4 Format Destination IP Specify the Destination IP of this static routing rule.
  • Page 33 5G Multi-Connect Modem 3.2.2 Routing Information Routing Information Item Value setting Description 192.168.123.0 by 192.168.123.0 Show default routing and static routing rule list default...
  • Page 34 5G Multi-Connect Modem 3.3 System This section provides the configuration of system features. 3.3.1 System Time System Time Item Value setting Description Show the current time of the unit. Current Time When select Auto, unit will sync the time via cellular cell, and then try 1.
  • Page 35 5G Multi-Connect Modem 3.3.2 System Information System Information Item Value setting Description Show the model name of the device Model Name DWM-314-G 3.3.3 Scheduling Scheduling Item Value setting Description Press Add to create a schedule rule for system. Time Schedule...
  • Page 36 5G Multi-Connect Modem Time Schedule Configuration Item Value Setting Description Rule Name String: any text Set rule name Rule Policy Default Inactivate Inactivate/activate the function been applied to in the time period below Time Period Definition Item Value Setting Description Week Day Select from menu Select everyday or one of weekday...
  • Page 37 5G Multi-Connect Modem Chapter 4 Security 4.1 VPN VPN Page Item Value setting Description The OpenVPN setting allows user to create and configure OpenVPN Openvpn tunnels. The WireGuard setting allows user to create and configure WireGuard WireGuard tunnels. 4.1.1 OpenVPN If you want to offer remote access to a VPN server from client(s) and inhibit the access to remote LAN resources under VPN server, OpenVPN TUN mode is the simplest solution.
  • Page 38 5G Multi-Connect Modem be assigned a virtual IP (10.8.0.2) which is belong to a virtual subnet that is different to the local subnet in Control Center. OpenVPN Tap Scenario If you want to offer remote access to the entire remote LAN for VPN client(s), you have to setup OpenVPN in “TAP”...
  • Page 39 5G Multi-Connect Modem...
  • Page 40 5G Multi-Connect Modem OpenVPN Client Rule Configuration Page Item Value setting Description 1. String format can be Name any text The name of current rule 2. A Must-fill setting Define the selected Protocol for connecting to the OpenVPN Server. • Select TCP , or UDP 1.
  • Page 41 5G Multi-Connect Modem 4.1.2 WireGuard WireGuard Page Item Value setting Description The box is unchecked Enable Check the Enable box to activate this WireGuard function by default The box is unchecked Check the Enable box to activate this client function Client enable by default Click Add will pop-up Interface page...
  • Page 42 5G Multi-Connect Modem Rule Page Item Value setting Description Check the Edit box to activate this WireGuard function Name Check the Delete box to delete Rule Interface Page Item Value setting Description The box is unchecked Rule Check the Enable box to activate this WireGuard function by default Name A Must-fill setting.
  • Page 43 5G Multi-Connect Modem peer Page Item Value setting Description Remote IP :Port A Must-fill setting. Specify the remote IP and port Remote Public key A Must-fill setting. Specify the server public key The box is unchecked Enable Preshared key Check the Enable box to activate this Preshared key function by default...
  • Page 44 5G Multi-Connect Modem 4.2 Firewall The firewall functions include Packet Filter, URL Blocking, MAC Control, IPS and some firewall options. 4.2.1 Packet Filters "Packet Filter" function can let you define some filtering rules for incoming and outgoing packets. So the gateway can control what packets are all blocked to pass through it. A packet filter rule should indicate from and to which interface the packet enters and leaves the gateway, the source and destination IP addresses, and destination service port type and port number.
  • Page 45 5G Multi-Connect Modem Packet Filter Scenario As shown in the diagram, specify "Packet Filter Rule List" (block those match the following rules) and define the rules. Rule-1 is to block HTTP packets to pass, and Packets other than Rule1 let it pass through.
  • Page 46 5G Multi-Connect Modem Packet Filter Rule Configuration Page Item Value setting Description 1. String format can be Enter a packet filter rule name. Enter a name that is easy for you to Name any text remember. 2. A Must-fill setting This field is to specify the Source IP address.
  • Page 47 5G Multi-Connect Modem Define the selected interface to be the packet-leaving interface of the 1. A Must-fill setting router. If the packets to be filtered are entering from LAN to WAN then Destination interface 2. By default Any is select WAN for this field. selected Select Any to filter packets leaving the router from any interfaces.
  • Page 48 5G Multi-Connect Modem 4.2.2 MAC Control When the administrator wants to reject the traffics from some client hosts with specific MAC addresses, he can use the "MAC Control" function to reject with the black list configuration. Mac control Scenario Mac Control Page Item Value setting Description...
  • Page 49 5G Multi-Connect Modem MAC Control Rule Configuration Page Item Value setting Description 1. String format can be Name any text Enter a mac rule name. Enter a name that is easy for you to remember. 2. A Must-fill setting Mac address Specify the Source MAC Address to filter rule.
  • Page 50 5G Multi-Connect Modem 4.2.3 IPS IPS Page Item Value setting Description The box is unchecked Check the Enable box to activate this IPS function by default The box is unchecked SYN Flood Defense Check the Enable box to activate this SYN Flood Defense function by default 1.
  • Page 51 5G Multi-Connect Modem The box is unchecked Block Smurf Attack Check the Enable box to activate this Block Smurf Attack function by default The box is unchecked Block Land Attack Check the Enable box to activate this Block Land Attack function by default The box is unchecked Block Fraggle Attack...
  • Page 52 5G Multi-Connect Modem URL Block Rule Configuration Page Item Value setting Description 1. String format can be Specify an URL Blocking rule name. Enter a name that is easy for you any text Name to understand. 2. A Must-fill setting Specify URL, Domain Name, or Keyword list for URL checking.
  • Page 53 5G Multi-Connect Modem Firmware Upgrade Item Value setting Description Select firmware file to be upgraded FW Path Upgrade Action Click Upgrade button to start upgrade process with selected FW Backup Configuration Settings Item Value setting Description You can backup or restore the device configuration settings by clicking Backup Download is selected the Via Web UI button.
  • Page 54 5G Multi-Connect Modem Password Item Value setting Description 1. String: any text 2. The default Old Password Enter the current password to enable you unlock to change password. password for web- based MMI is ‘admin’. New Password String: any text Enter new password New Password String: any text...
  • Page 55 5G Multi-Connect Modem 5.1.4 SSH Item Value setting Description 1. Default value is Check the Enable box to activate the SSH Telnet function for connecting from LAN or WAN interfaces. disable such You can set which number of Service Port you want to provide for the service corresponding service.
  • Page 56 5G Multi-Connect Modem Rule Configuration Item Value setting Description Name String: any text Set rule name Protocol Select HTTP or HTTPS method for router access. HTTP is set by default This field is to specify the remote host to assign access right for remote access.
  • Page 57 5G Multi-Connect Modem 5.2 Utility 5.2.1 SMS SMS service Item Value setting Description Check the Enable box to activate this SMS function The box is unchecked Click Add will pop-up Mac control Rule configuration page by default Select SIM or modem storage SMS storage SIM by default specify a number (1-10) for message count to reserve some available...
  • Page 58 5G Multi-Connect Modem Account configuration Item Value setting Description The box is unchecked Sender Phone Number for the received SMS Phone number#1 by default The box is unchecked Check the Enable box to activate this SMS function application by default Check the Enable box to activate this SMS function The box is unchecked Check the Enable box to activate this SMS function...
  • Page 59 5G Multi-Connect Modem Managing Event Item Value setting Description The box is unchecked Check the Enable box to activate this SMS notification function Cellular Status by default The box is unchecked Check the Enable box to activate this SMS notification function Cellular Reconnect by default The box is unchecked...
  • Page 60 5G Multi-Connect Modem New SMS Item Value setting Description Remote Administrator Write the receivers to send SMS. User need to add the semicolon and Host Definition compose multiple receivers that can group send SMS. Text Message Write the SMS context to send SMS. Click the Send button, above text message will be sent as a SMS.
  • Page 61 5G Multi-Connect Modem 5.1.8 Command Script Command Script Item Value setting Description Enter a short description for the applied Command script. 1.An Optional setting Command Script 2.Any string Check the Enable box to activate the Command Script function. The box is unchecked Enable by default 5.2.3 System log...
  • Page 62 5G Multi-Connect Modem System log Item Value setting Description Check the Enable box to activate the system log function The box is unchecked Enable by default Specify Collector IP System log server IP 0.0.0.0 by default Specify Collector Port System log server port 0 by default...
