aci TR-A-CP Series Installation And Operation Instruction

Advertisement

Quick Links

◼ Operating Specifications
The TR-A-CP-xxx Series room temperature sensors come with an output signal of 10K Ohms Type II (CP) at 77F (25C).
The temperature sensors have an overall accuracy of  0.36F
TR-A-CP-xxx Series room temperature sensors can be used in environments where the operating temperature is between
o
o
40 to 122
F
(4.4 to 50
C).
Some part numbers include an adjustable resistive set point (1K to 11K ohms) and / or a
momentary N/O override "After Hours" pushbutton.
All part numbers with the "After Hours" Override pushbuttons
**Note:
with the sensor. If a Separate Input (Dry Contact Closure) is needed, see "After Hours" Override Jumper
Options (J3) table below in the wiring diagrams.
Part Number
TR-A-CP-RSO
Space Temperature Sensor with Knob (Setpoint) and Override pushbutton
TR-A-CP-RS
Space Temperature Sensor with Knob (Setpoint)
TR-A-CP-RO
Space Temperature Sensor with Override pushbutton
TR-A-CP-R
Space Temperature Sensor
◼ Wiring Specification
ACI recommends 18 to 22 AWG shielded cable for all sensor installations. See the wiring diagrams for the total number of
wires needed for each unit to work properly. All wire connections are in BOLD print on the wiring diagrams.
◼ Wiring Diagrams
Thermistor (Sensor) Output to Controller
Thermistor, Setpoint & Override Common
Figure # 1
AUTOMATION COMPONENTS, INC
2305 Pleasant View Road
Middleton, Wisconsin 53562 (888) 967-5224
www.workaci.com
Please Read Instruction Carefully Before Installation!
TR-A-CP-RSO
Wire Access Hole
© CSI REV. 7
-
Installation and Operation Instructions
TR-A-CP-xxx Series
( 0.2C)
over the range of 32 to 158F
are shipped with the override in parallel
Description
J3
Short Sensor
Separate Input
TB1
TB2
SW1
-
SEN
O/R SET
P1
S1
+
Page 1 of 4
(0 to 70C).
Wiring Diagram
Figure # 1
Figure # 2
Figure # 3
Figure # 4
Override "After Hours" Output to Controller
(Use for Separate Input / Dry Contact Output Only)
Adjustable Setpoint Output to Controller
Normally Open Override Pushbutton
Override "After Hours" Jumper Options
Parallel with Sensor
J3
Short Sensor
Separate Input
Separate Input
J3
Short Sensor
Separate Input
Thermistor (Sensor)
Adjustable Setpoint Slidepot
The
Version : 4.0
I0000260
