Summary of Contents for dedalo 068
- Page 2 After a decade and half of developing effects, we set ourselves the challenge of designing a line of beautiful pedals simplified to their essence, purifying the functions and sound, and aiming at complexity based on the combinations between them. This is how Dedalo System was born.
- Page 3 068 / Oscillator This is an instrument-controlled oscillator. It generates variable-width rectan- gular waveforms on three octaves, and deforms them with a custom analog waveshaper for thick and creamy synthesizer and fuzzed-out sounds. Features: • Monophonic (Detects single notes) • Digital propietary-algorithm PWM oscillator •...
- Page 4 Controls Mode of oscillation. 01 - OCTAVE Gated Fuzz (In this mode, Shape controls the gate of the detector) Octave Down Unison Octave Down + Unison Octave Down + Octave Up Unison + Octave Up Octave Down + Unison + Octave Up Pulse width of the waveform.
-
Page 5: Technical Specifications
Suggested effects chain Use and care of the pedal • Use only regulated 9v dc adapter, with negative center polarity. In no way should be connected to 220V or adapters of other kinds. • Avoid dropping, hitting or exposing the pedal to extremes of humidity or temperature. •... -
Page 6: Problems And Solutions
• Failures due to accident or misuse are not covered in the warranty. Check that the DC plug doesn’t have metalic parts that may touch the case of the • DEDALO is not responsible for any loss or damage the user may suffer as a result of pedal. -
Page 7: Sound Settings
Sound Settings... - Page 8 Sound Settings...
- Page 9 Sound Settings www.dedalofx.com.ar...
