  • Page 1 user manual...
  • Page 2 Elation Professional B.V. | Junostraat 2 | 6468 EW Kerkrade, The Netherlands +31 45 546 85 66 | +31 45 546 85 96 fax | www.elationlighting.eu | info@elationlighting.eu Elation Professional Mexico | AV Santa Ana 30 | Parque Industrial Lerma, Lerma, Mexico 52000 +52 (728) 282-7070...

  • Page 3: Table Of Contents

    C O N T E N T S General Information IP65 Rated Limited Warranty (USA Only) Safety Guidelines Overview Colors and Gobos Custom Gobos Gobo Installation Custom Logo Plate Installation Torque Settings for Screws IP Test Parameters Installation Guidelines Frequency & Wireless Location Guidelines System Menu Sun Protection Mode | Hibernation Mode Fan Modes and Low Noise Operation...

  • Page 4: Box Contents

    (x1) IP65 Rated Power Cable (x2) Omega Brackets (x1) Safety Cables CUSTOMER SUPPORT Contact ELATION Service for any product related service and support needs. Also visit forums.elationlighting.com with questions, comments or suggestions. ELATION SERVICE USA - Monday - Friday 8:00am to 4:30pm PST 323-582-3322 | Fax 323-832-9142 | support@elationlighting.com...

  • Page 5: Ip65 Rated

    I P 6 5 R AT E D The International Protection (IP) rating system is commonly expressed as “IP” (Ingress Protection) followed by two numbers (i.e. IP65), where the numbers define the degree of protection. The first digit (Foreign Bodies Protection) indicates the extent of protection against particles entering the fixture, and the second digit (Water Protection) indicates the extent of protection against water entering the fixture.

  • Page 6: Limited Warranty (Usa Only)

    B. For warranty service, send the product only to the Elation Professional factory. All shipping charges must be pre-paid. If the requested repairs or service (including parts replacement) are within the terms of this warranty, Elation Professional will pay return shipping charges only to a designated point within the United States.

  • Page 7: Safety Guidelines

    This fixture is a sophisticated piece of electronic equipment. To guarantee a smooth operation, it is important to follow all instructions and guidelines in this manual. Elation Professional is not responsible for injury and/or damages resulting from the misuse of this fixture due to the disregard of the information printed in this manual.
  • Page 8 S A F E T Y G U I D E L I N E S 66 lbs. (30 kg) DO NOT TOUCH the fixture housing during operation. Turn OFF the power and allow approximately 15 minutes for the fixture to cool down before serving. DO NOT shake fixture, avoid brute force when installing and/or operating fixture.

  • Page 9: Overview

    O V E R V I E W NFC Access Point LCD Display Battery Indicator Up Button Enter Button Down Button Tilt Lock Tilt Lock Carrying Handle FUSE : T12A / 250V POWE R IN AC100 -240V POWE R OUT 50/60H z MAX:1 00-240 V 1A...

  • Page 10: Colors And Gobos

    C O L O R S A N D G O B O S ROTATING GOBO WHEEL POS 1 POS 2 POS 3 POS 4 POS 5 POS 6 POS 7 FIXED GOBO WHEEL POS 8 POS 1 POS 2 POS 3 POS 4 POS 5...

  • Page 11: Custom Gobos

    Extended testing of custom gobo designs is highly recommended prior to use. Contact ELATION SERVICE for further information. ELATION SERVICE USA -Monday -Friday 8:00am to 4:30pm PST 323-582-3322 | support@elationlighting.com...

  • Page 12: Gobo Installation

    G O B O I N S TA L L AT I O N Place the fixture on a firm flat surface. Locate the (12x) hex screws securing the panel on the Pan Lock side of the moving head and remove them. Pan Lock Locate the Rotating Gobo Wheel Assembly Module, remove the screws that secure it to the internal housing frame,...
  • Page 13 G O B O I N S TA L L AT I O N Locate the specific Rotating Gobo to replace. Carefully grip the Gobo using your thumb and index finger, gently lift it slightly, and then pull it out and away until it fully clears the Gobo Wheel. CAUTION: TAKE CARE NOT TO SCRATCH GOBO OR GOBO HOLDER Locate the tab of the Retention Spring, and with a precision pick (or similar tool), carefully press...

  • Page 14: Custom Logo Plate Installation

    C U S T O M LO G O P L AT E I N S TA L L AT I O N To install a Logo Plate, ensure the fixture is powered off and disconnected. Locate and remove the existing Elation Logo Plate using a hex driver by unscrewing the two holding screws. Using the existing mounting screws, align the screw holes of the new badge with the mounting holes of the fixture.

  • Page 15: Torque Settings For Screws

    ISSUES! TO CONFIRM THE IP65 INTEGRITY AFTER A PROCEDURE REQUIRING DISASSEMBLY/REASSEMBLY, TEST THE FIXTURE USING THE IP TESTER. CONTACT ELATION SERVICE FOR MORE DETAILS. CAUTION! THE USE OF PROTECTIVE GLOVES AND SAFETY GOGGLES IS STRONGLY RECOMMENDED WHILE PERFORMING THE IP PRESSURE TEST! AVOID PLACING YOUR FACE, EYES, HANDS, ETC IN CLOSE PROXIMITY TO THE FIXTURE’S LENS...

  • Page 16: Ip Test Parameters

    Following any repair or maintenance procedure that requires disassembly of the fixture, use Elation’s IP Tester to confirm the IP integrity of the fixture. Please contact Elation Service for information regarding the Elation IP Tester, or visit the product information page online at: https://www.

  • Page 17: Installation Guidelines

    I N S TA L L AT I O N G U I D E L I N E S FLAMMABLE MATERIAL WARNING Keep fixture minimum 5.0 feet (1.5m) away from flammable materials and/or pyrotechnics. ELECTRICAL CONNECTIONS A qualified electrician should be used for all electrical connections and/or installations. USE CAUTION WHEN POWER LINKING OTHER MODEL FIXTURES AS THE POWER CONSUMPTION OF OTHER MODEL FIXTURES MAY EXCEED THE MAX POWER OUTPUT ON THIS FIXTURE.
  • Page 18 I N S TA L L AT I O N G U I D E L I N E S OMEGA BRACKETS WITH CLAMP INSTALLATION When mounting the fixture to a truss, be sure to secure an appropriately rated professional grade rigging clamp to the included Omega Brackets using an M10 screw fitted through the center hole of the Omega Brackets.

  • Page 19: Fixture Installation

    I N S TA L L AT I O N G U I D E L I N E S FIXTURE INSTALLATION The Elation Rebel Profile is fully operational in three different mounting positions, hanging upside-down, mounted sideways on trussing, or set on a flat level surface. Be sure this fixture is kept at least (1.6' (0.5m) away from any flammable materials (decoration etc.).
  • Page 20 I N S TA L L AT I O N G U I D E L I N E S ART-NET | sACN CONNECTION When connecting fixture to a network switch to control multiple devices, a Gigabit Ethernet Switch that supports IGMP (Internet Group Management Protocol) is required. Using a Gigabit Ethernet Switch that does not support IGMP can cause erratic behavior of all connected devices to the switch.
  • Page 21 LEDs. This issue is not specific only to ELATION lighting fixtures, it is a common issue with lighting fixtures from all manufacturers. Although there is no true way to fully prevent this issue from happening, the guidelines below can prevent any potential damage from occurring if followed.

  • Page 22: Frequency & Wireless Location Guidelines

    F R EQUE NCY & W I R E L ESS LO CATI ON G UI DELI N ES 2GHZ Versus Sub-Gig (GHz) Frequencies: Sub-GHz frequencies provide superior reliability and range compared to higher frequencies, making them perfect for consistent communication across vast distances or in difficult conditions.

  • Page 23: System Menu

    THE SYSTEMS MENU TO TAKE ADVANTAGE OF ITS WIRELESS FEATURE SET FOR WIRELESS CONNECTIVITY AND OVER THE AIR SOFTWARE UPDATES. AN ELATION E-LOADER III CAN BE USED TO UPDATE THE FIXTURE TO THE LATEST SOFTWARE. SEE PAGE 41 FOR INSTRUCTIONS. TO ORDER THIS DEVICE, PLEASE CONTACT ELATION SUPPORT FOR FURTHER DETAILS.
  • Page 24 S YS T E M M E N U MAIN MENU OPTIONS / VALUES (Default Settings in BOLD) DMX Address 001 - 512 DMX Mode Standard, Extended Hold Last, Fade to Black, Sun Protection No DMX Status Hibernation Off, 1-99M (Default = 15 Min) DMX, Art-Net, sACN, Aria In-DMX Out, Select Signal DMX In - Aria Out...

  • Page 25: Sun Protection Mode | Hibernation Mode

    S U N P R O T E C T I O N M O D E The fixture incorporates an automatic protection from harmful sunlight, which can damage a fixture’s internal components from extended exposure. Fixtures use an internal sensor to determine their physical orientation, then reorient the fixture towards the ground to prevent sunlight from entering the lens.

  • Page 26: Fan Modes And Low Noise Operation

    LED engine cannot be cooled down to its safe operating range due to high ambient temperature. Auto is the recommend mode for daily operation of the Rebel Profile. Low – In this mode the fixture reduces fan speeds throughout for a lower noise profile of the fixture.

  • Page 27: Dimmer Modes And Dimmer Curves

    D I M M E R M O D E DIMMER 100% Time (ms) 0 Sec Rise Time Down Time 0 sec Fade Time 1 sec Fade Time Dimming Curve Ramp Effect Rise Time (ms) Down Time (ms) Rise Time (ms) Down Time (ms) Standard (default) Stage 1100...

  • Page 28: Dmx Traits

    D M X T R A I T S MODE/CHANNEL VALUE FUNCTION SNAP DEFAULT STANDARD EXTENDED 0-255 Left → Right Pan Fine 0-255 Fine Position Tilt 0-255 Forward → Backward Tilt Fine 0-255 Fine Position Pan Rotation 0-128 no function 128-189 Clockwise Fast →...
  • Page 29 D M X T R A I T S MODE/CHANNEL VALUE FUNCTION SNAP DEFAULT STANDARD EXTENDED 0-255 Open → 2700K CTO Fine 0-255 Fine Saturation CMY Mix Mode 0-127 Full 128-255 SFX Color Open 6-15 Color 1 16-31 Color 2 32-47 Color 3 48-63...
  • Page 30 D M X T R A I T S Features subject to change without notice MODE/CHANNEL VALUE FUNCTION SNAP DEFAULT STANDARD EXTENDED Rotating Gobo Index/Rotation 0-127 Index Position Rotate 128-190 Clockwise Fast → Slow 191-192 Stop 193-255 Counter-clockwise Slow → Fast Rotating Gobo Index/Rotation Fine 0-255 Fine Adjustment...
  • Page 31 D M X T R A I T S MODE/CHANNEL VALUE FUNCTION SNAP DEFAULT STANDARD EXTENDED Prism1 Open 6-255 Prism 1 Prism 1 Index/Rotation 0-127 Index Position Rotate 128-189 Clockwise Fast → Slow 190-193 Stop 194-255 Counter-clockwise Slow → Fast Prism 1 Index/Rotation Fine 0-255 Fine Adjustment...
  • Page 32 D M X T R A I T S MODE/CHANNEL VALUE FUNCTION SNAP DEFAULT STANDARD EXTENDED Dimmer 0-255 0 → 100% Dimmer Fine 0-255 Fine Adjustment Dimmer Modes 0-20 Standard 21-40 Stage 41-60 61-80 Architectural 81-100 Theatre 101-120 Stage 2 Dimmer Time 0.1s 0.2s...
  • Page 33 D M X T R A I T S MODE/CHANNEL VALUE FUNCTION SNAP DEFAULT STANDARD EXTENDED Blade 1 A 0-255 Open → Closed Blade 1 A Fine 0-255 Fine Adjustment Blade 1 B 0-255 Open → Closed Blade 1 B Fine 0-255 Fine Adjustment Blade 2 A...
  • Page 34 D M X T R A I T S MODE/CHANNEL VALUE FUNCTION SNAP DEFAULT STANDARD EXTENDED Control 0-19 Wheel Snap 20-29 Color Wheel Fade 30-39 Color/Gobo Wheel Fade Fan Mode 40-44 Mute 45-49 Studio 50-59 60-69 High 70-79 Auto Reset 80-84 85-87 Pan / Tilt...
  • Page 35 D M X T R A I T S : C H A N N E L F U N C T I O N S & VA L U E S MODE/CHANNEL VALUE FUNCTION SNAP DEFAULT STANDARD EXTENDED Refresh Rate (Hz) 1160 1170 1180...
  • Page 36 D M X T R A I T S : C H A N N E L F U N C T I O N S & VA L U E S MODE/CHANNEL VALUE FUNCTION SNAP DEFAULT STANDARD EXTENDED 169-172 Idle 173-174 Hibernation Off 175-176 Hibernation 177-178 Sun Protection On...

  • Page 37: Remote Device Management (Rdm)

    R E M O T E D E V I C E M A N A G E M E N T ( R D M ) NOTE: In order for RDM to work properly, RDM enabled equipment must be used throughout the entire system, including DMX data splitters and wireless systems.

  • Page 38: Maintenance Guidelines

    Regular inspections are recommended to ensure proper function and extended life. There are no user serviceable parts inside this fixture. Please refer all other service issues to an authorized Elation service technician. Should you need any spare parts, please order genuine parts from your local Elation dealer.

  • Page 39: Error Codes

    E R R O R C O D E S Error Codes subject to change without notice ERROR CODES DESCRIPTION Movement is not located in the default position after the reset. These messages will appear after a fixture reset if the magnetic-indexing circuit malfunctions (sensor failed, or magnet is missing) or there is a motor failure (defective motor or a defective motor IC drive on the main PCB).

  • Page 40: Software Updates

    PLEASE CONTACT ELATION SERVICE FOR FURTHER INFORMATION. C-LOADER II An Elation C-Loader II can be used to update the fixture to the latest software. Please visit the C-Loader II product page at the Elation web site and download the product manual for step by step instructions.
  • Page 41 ELATION SERVICE EUROPE - Monday - Friday 08:30 to 17:00 CET +31 45 546 85 63 | support@elationlighting.eu The Elation Ethernet Updater is an EXE file, which only works on a PC System. Once you’ve received the Elation Ethernet Updater RAR file from Elation Service via email, download and extract the EXE file.
  • Page 42 S O F T WA R E U P D AT E S ETHERNET UPDATER Once you have installed the Elation Ethernet Updater, it will launch automatically (unless you unchecked “Launch Elation Ethernet Updater”), or you can open it any time by clicking on the icon.
  • Page 43 S O F T WA R E U P D AT E S ETHERNET UPDATER Once opened, your local IP will automatically be identified. Click “Scan fixture” and create a connection. The fixture identity will appear in the Update List on the left side of browser. A connection will fail to establish if the fixture IP and Local IP are not in the same network segment.
  • Page 44 S O F T WA R E U P D AT E S ETHERNET UPDATER Click Update, then wait for the download Progress to reach 100% before closing Updater. The Elation Ethernet Updater can update up to 31 fixtures via connection to a PC.

  • Page 45: Specifications

    S P E C I F I C AT I O N S SOURCE SIZE / WEIGHT 500W 6,500K Bright White Peak Field LED Length: 11.4 in (290mm) Engine Width: 15.2 in (385mm) 20,000 Hour Average LED Life* Height: 26.2 in (666mm) Center-to-Center Spacing: 23.2in.

  • Page 46: Dimensional Drawings

    D I M E N S I O N S *Drawings not to scale. Specifications and improvements in the design of this unit and this manual are subject to change without notice. 23.2in. [589mm] Ø21.2in. [Ø538mm] 2.0in. [51mm] 11.1in. [281mm] 11.4in.

  • Page 47: Optional Accessories | Fcc Statement

    O P T I O N A L A C C E S S O R I E S ORDER CODE ITEM TRIGGER CLAMP Heavy Duty Wrap Around Hook Style Clamp SIP126 5 ft. (1.5m) IP65 Twist Lock Power Link Cable TOU027 5 ft.
