- Page 1 NEON COB PLUS DC 24V TOP BENDING Version: A1.0 www.blueviewled.com...
- Page 2 Outdoor 120° DC 24V IP67 5Years 3Years OPTICAL & ELECTRICAL PARAMETERS Model No. Voltage Color Lm/m Lm/W 2700K 3000K NDR0604-COB Plus-Single color DC 24V >90 4000K 1022 5000K 1022 6000K 1015 2700K 1360 3000K 1390 NDR1004-COB Plus-Single color DC 24V >90...
- Page 3 AVERAGE BEAM ANGLE(50%): 124.5° Height Eavg, Emax Beam Angle: 110.65° Diameter Note: the above two figures are tested with the sample NDR0604-COB Plus at CCT 3000K, for other data, please consult sales rep. Flux Out: 787.0lm NDR1004-COB Plus 0.5m 455.9,1523lx 145.46cm...
-
Page 4: Packaging Information
Bending Diameter Dimension NDR0604-COB Plus NDR1004-COB Plus 6.0[0.24] 10.0[0.39] 60.0[2.36] Note: within 5m, customizable lengths are multiples of the min cuttable length. PACKAGING INFORMATION Put reel, accessory bag and Roll the product to a reel Label the reel; Label the foil bag;... -
Page 5: Accessories Information
ACCESSORIES INFORMATION NDR0604-COB Plus Part No. Picture Item Model No. Dimensions L*W*H Quantity Free/Optional Front cap ASY-NDR0604-COB PLUS-N00NH-EC 01.06.10602000892 20.0*8.0*12.0mm 5m: 2pcs Free Closing End-cap ASY-ND0604-COB-PLUS-N00NX-EC 01.06.10602000893 11.5*8.0*12.0mm 5m: 2pcs Free Aluminum Channel ASY-NDR0604-PLUS-A1NN1000-MT 01.08.0420082401 1000*9.5*3.7mm Optional Silicone Glue WR-7516 01.10.0220000418... -
Page 6: Installation
INSTALLATION Front cap installation Weld the wire to the PCB board. Apply waterproof glue to the front cap, Wipe off any excess glue and wait then install it. for it to dry. Closing-end cap installation Apply waterproof glue to the end Wipe off any excess glue and cap, then install it. - Page 7 WARNING MARK Wrong Correct Insert stick through reel Keep products neatly Cutting line marks Top bending Neat and smooth cut. on box for easy product No side bending stacked. access. Prevent sharp objects Do not pile randomly Ensure smooth and Do not violently unpack.
-
Page 8: Attentions Before Installation
- LED lighting products belongs to electronic products, please do recycling treatment according to the relevant WEEE directives. Version Content Date A1.0 First release 2024-7-15 BLUEVIEW ELEC-OPTIC TECH CO.,LTD Tel: +86-28-8148 0011 Web.: www.blueviewled.com Fax: +86-28-8148 1258 Email: sales@blueviewled.com Add.: No. 1000, Section 2, Konggang 2nd Road, Shuangliu, Chengdu 610207, Sichuan, CHINA www.blueviewled.com...
