Features
1.Neon with 5050 SMD
2.Colors in W/R/G/B/Y/O available
3.Adopt high quality components and special circuit design for reliable performance
4.Unique extrusion process and electronic design can be bended in vertical way
5.5m max run in single feed and 10m max run in double feed without brightness drop
6.Flexible and cuttable every 62.5mm for various application
7.Extrusion modeling, IP68 with excellent weather resistance
Application
Landscape lighting, facade lighting, steps, bridges, yards, roads, etc.
Installation
by clips
5050
1
LED NEON FLEX
ND5-20
156°
3Years
24V
IP68
Advertisement
Table of Contents
Related Manuals for Blueview LED NEON FLEX
Summary of Contents for Blueview LED NEON FLEX
- Page 1 LED NEON FLEX ND5-20 156° 5050 3Years IP68 Features 1.Neon with 5050 SMD 2.Colors in W/R/G/B/Y/O available 3.Adopt high quality components and special circuit design for reliable performance 4.Unique extrusion process and electronic design can be bended in vertical way 5.5m max run in single feed and 10m max run in double feed without brightness drop...
-
Page 2: Specification
LED NEON FLEX ND5-20 Sectional view and size Bending Diameter: mm[inch] Light Surface Light Surface Specification Light Color Temperature/ Efficacy Beam Luminous Flux Voltage Power Model No. Wavelength(K/nm) (lm/W) Color (lm/m) (W/m) Angle (V DC) 2000-25000 1305 620-625 520-525 ND5-20 156°... - Page 3 LED NEON FLEX ND5-20 Profile Drawings Unit:mm Single Feed Double Feed NOTE: Please ask the sales for detail drawing. Working Length vs. Recommended Power Supply Recommended Rated Voltage Power Supply Working Length Rated Current Rated Power Model No. Power Supply(W)
- Page 4 LED NEON FLEX ND5-20 Luminous Intensity Distribution Diagram Unit：cd C0 /180,199.8° AVERAGE BEAM ANGLE(50%)：156.1° C90/270,112.4° Average Illumination Flux Out: 588.1lm Diameter Height Eavg，Emax Beam Angle：112.01° NOTE: the above two figures are tested with white LED and surface of ND5-20 at 6500k, please ask the sales for other data.
-
Page 5: Product Accessories
LED NEON FLEX ND5-20 Product accessories End exit(FREE) End cap (FREE) Plastic clip(FREE) Screw(FREE) Quantity(5/10m):2/4pcs Quantity(5/10m):2/4pcs Quantity(5/10m):10/20pcs Quantity(5/10m):10/20pcs Silicone glue (OPTIONAL) Quantity(5/10m):1pcs Note: all accessories can be provided according to customer requirements. Packaging Information Roll the product on the reel Label the reel. -
Page 6: Installation
LED NEON FLEX ND5-20 Packaging information Product Size Carton Size Model No. Meter/Reel Reel/Carton Net Weight(kg) Gross Weight(kg) (mm) (mm) 5000X18X15 390X390X325 15.75(1±10%) 20.05(1±10%) ND5-20 10000X18X15 390X390X325 12.60(1±10%) 18.50(1±10%) Note: 1. Each 1 piece(5m or 10m) for a reel and every 10 reels or 4reels packed in a carton box. - Page 7 LED NEON FLEX ND5-20 Details of installation operation at the end part First put some glue inside of Wipe off the excess glue and the plug, then push into the wait for the glue to solidify. tape light 3. Operation details of plastic clip installation.
- Page 8 LED NEON FLEX ND5-20 Attentions Light Surface Cuttable mark Neat and smooth cut Insert a stick on the reel use in convex direction and place it on the packing box,and rotate the reel to get the product Light Surface Do not twist the product...
-
Page 9: Attentions Before Installation
LED NEON FLEX ND5-20 Attentions before installation Before installation, check that the product parameters are consistent with the requirements (Seeing product specificationsor product labels) Load voltage, current, power and power supply should be matched with the product. Follow the instructions of wiring diagram (first connect the load and then the power supply) to avoid short circuit.
