- Page 1 W A L L P E N S T O C K - M X S E R I E S INSTALLATION AND MAINTENANCE INSTRUCTION MANUAL manufacturing the valve you need...
-
Page 2: Purpose And Scope
This document describes the installation, operation and maintenance instructions for CMO Valves MX series unidirectional and bidirectional channel gates. MX Series gates are designed to work with a wide range of clean or solid-laden liquids, controlling their fl ow, isolation, and passage in pipelines for the defi ned range of pressures (water load) and service conditions, as is their designated use. -
Page 3: Transport And Handling
• To prevent damage, especially to the anticorrosive protection, it is recommended to use soft straps or belts when lifting CMO valves knife gate valves. These straps must be fi tted around the top of body. • If the equipment is packed in wooden boxes, these must be provided with clearly marked holding areas where the slings will be placed when securing them. -
Page 4: Installation
Completely isolate the gate from the whole process. • Drain all the fl uid from the line through the gate. For MX Series gates for use in potentially explosive atmospheres (ATEX), ‘Ex’ approved hand tools must be • used during installation and maintenance, according to current regulations. - Page 5 ASPECTS TO BE CONSIDERED DURING ASSEMBLY The most common installation for MX Series wall gates is placing them against the civil construction wall and fas- tening the gate with expansion or chemical anchors (fi g. 2), although there are other mounting options, as shown in fi...
- Page 6 WALL PENSTOCK - MX SERIES WALL PENSTOCK - MX SERIES In order to mount the gate with the base embedded in the concrete (fi g. 4): • Check that the gate (size, mounting system, fl uid direction, and dimensions) matches its location on site. Refer to the corresponding assembly drawings.
-
Page 7: Assembly Positions
WALL PENSTOCK - MX SERIES WALL PENSTOCK - MX SERIES ASSEMBLY POSITIONS This type of gate is mounted on vertical walls with a square, round or rectangular opening; this opening may be at a certain height (fi g. 6) or fl ush with the ground (fi g. 5). Gate position is always vertical. - Page 8 (2), the watertight seals, and the gate’s body (1). Fig. 7 For other types of accessories and options installed or incorporated with the MX Series gate (mechanical locking systems, limit switches, electrovalves, junction boxes, etc.), refer to the installation and maintenance user manual for these components, which is included with the gate documentation.
- Page 9 WALL PENSTOCK - MX SERIES DRIVE MX Series gates can be operated by a wide variety of drives, according to project, installation, or usage requirements. Manual drives (handwheel, gearbox, lever, etc.) should not be subjected to excessive force (max. 25 kgF) to ensure the gate closes correctly.
-
Page 10: Electric Actuator
WALL PENSTOCK - MX SERIES WALL PENSTOCK - MX SERIES ELECTRIC ACTUATOR If the gate incorporates a motorised drive, it will be accompanied by the electrical actuator supplier’s instructions and technical documentation. Check the connections and operation diagram. Follow the electric actuator manufac- turer’s instructions when starting up the equipment. -
Page 11: Maintenance
WALL PENSTOCK - MX SERIES MAINTENANCE CMO Valves shall not be liable if the gate valve su ers damage due to incorrect or unauthorised handling or improper assembly and commissioning, thus voiding the warranty. Manipulating or modifying the knife gate valve is forbidden... -
Page 12: Important Safety Aspects
WALL PENSTOCK - MX SERIES WALL PENSTOCK - MX SERIES IMPORTANT SAFETY ASPECTS To work under ideal safety conditions, the drives must be in idle position and disconnected from their power source (electric, pneumatic or hydraulic) with the air tanks depressurised. Drives with fail-safe position (spring return) must be in these safety positions or locked. - Page 13 WALL PENSTOCK - MX SERIES WALL PENSTOCK - MX SERIES REPLACING THE SEALING JOINT (Fig. 9) Make sure there is absolutely no pressure and fl uid in the duct. 2. Release the yoke and the stoppers (when fi tted) and remove the complete through conduit from the body in order to facilitate the change of sealing joint.
-
Page 14: Maintenance Of The Pneumatic Actuator
The pneumatic cylinders in our valves are manufactured and assembled at our premises. The maintenance of these cylinders is simple, if your need to replace any elements and you have any questions please consult CMO Valves. Below is an exploded diagram of the pneumatic actuator (fi... -
Page 15: Components List
WALL PENSTOCK - MX SERIES WALL PENSTOCK - MX SERIES MAINTENANCE OF OTHER DRIVES For maintenance of other types of drives mounted on the reduced bore valve, such as manual geared motors, electric actuators and hydraulic actuators, follow the manufacturer’s recommendations as indicated in their user manual and technical documentation. - Page 16 Use only original spare parts. For any request or inquiry, contact CMO Valves, stating the material or component required and the order or project number. The following chapter and the website www.cmovalves.com include catalogues and technical information that can help identify the parts and elements of the gates.
- Page 17 NORTH AMERICA EUROPE ASIA MIDDLE EAST AFRICA AUSTRALIA & OCEANIA SOUTH AMERICA CMO VALVES CMO VALVES CMO VALVES HEADQUARTERS MAIN MADRID FRANCE OFFICES & FACTORY Amategi Aldea, 142 C/ Rumania, 5 - D5 (P.E. Inbisa) 5 chemin de la Brocardière 20400 Tolosa 28802 Alcalá...
