SERVICE MANUAL
Ver. 1.1 2007.07
When a Super Audio CD is played
Playing frequency range
2 Hz to 100 kHz
Frequency response
2 Hz to 40 kHz (−3 dB)
Dynamic range
100 dB or more
Total harmonic distortion rate
0.003 % or less
Wow and flutter
Value of measurable limit
(±0.001 % W. PEAK) or
less
When a CD is played
Frequency response
2 Hz to 20 kHz
Dynamic range
96 dB or more
Total harmonic distortion rate
0.0035 % or less
Wow and flutter
Value of measurable limit
(±0.001 % W. PEAK) or
less
Sony Corporation
9-887-356-02
Home Audio Division
2007G05-1
Published by Sony Techno Create Corporation
© 2007.07
SCD-XA1200ES
SPECIFICATIONS
Output connectors
Jack type Output
level
ANALOG
Phono
2 Vrms (at
OUT
jacks
50 kilohms)
−18 dBm
DIGITAL
Square
(CD) OUT
optical
OPTICAL*
output
connector
DIGITAL
Coaxial
0.5 Vp-p
(CD) OUT
output
COAXIAL*
connector
PHONES
Stereo
5 mW
phone jack
* Output only the audio signals of the CD
Model Name Using Similar Mechanism
CD Mechanism Type
Base Unit Name
Optical Traverse Unit Name
General
Laser
Load
impedance
Over 10
kilohms
(Light
Power requirements
emitting
Power consumption
wave length:
Dimensions (w/h/d)
660 nm)
75 ohms
Mass (approx.)
Supplied accessories
32 ohms
Audio connecting cord
Remote commander
Battery
Design and specifications are subject to change
without notice.
SUPER AUDIO CD PLAYER
AEP Model
SCD-XE597
CDM66D-DVBU50
DVBU50
DBU-3
Semiconductor laser
(Super Audio CD: λ= 650
nm) (CD: λ= 780 nm)
Emission duration:
continuous
230 V AC, 50/60 Hz
15 W
430 × 124 × 390 mm incl.
projecting parts
7.2 kg
Red and White × 2 (2)
Black × 1 (2)
RM-ASU001 (1)
R6 (size-AA) (2)
Advertisement
Table of Contents
Related Manuals for Sony SCD-XA1200ES
Summary of Contents for Sony SCD-XA1200ES
- Page 1 * Output only the audio signals of the CD (±0.001 % W. PEAK) or Battery R6 (size-AA) (2) less Design and specifications are subject to change without notice. SUPER AUDIO CD PLAYER Sony Corporation 9-887-356-02 Home Audio Division 2007G05-1 Published by Sony Techno Create Corporation © 2007.07...
-
Page 2: Table Of Contents
COMPONENTS IDENTIFIED BY MARK 0 OR DOTTED LINE WITH MARK 0 ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY. -
Page 3: Servicing Notes
SCD-XA1200ES SECTION 1 SERVICING NOTES CLEANING OF OPTICAL PICK-UP LENS NOTES ON HANDLING THE OPTICAL PICK-UP In cleaning the lens of optical pick-up, use the air blower. BLOCK OR BASE UNIT Never use a cotton swab for cleaning the lens of optical pick-up, The laser diode in the optical pick-up block may suffer electrostatic which otherwise causes a trouble. -
Page 4: General
SCD-XA1200ES SECTION 2 This section is extracted from instruction manual. GENERAL Front Panel TIME/TEXT MENU MULTI/2CH SA-CD/CD POWER PHONES PHONE LEVEL PUSH ENTER A POWER switch F N button M MENU button Press to enter the menu. B TIME/TEXT button... -
Page 5: Disassembly
SCD-XA1200ES SECTION 3 DISASSEMBLY • This set can be disassembled in the order shown below. 3-1. DISASSEMBLY FLOW 3-2. CASE (Page 5) 3-3. LOADING PANEL ASSY 3-5. MAIN BOARD (Page 6) (Page 7) 3-4. MECHANISM DECK 3-6. FRONT PANEL ASSY... -
Page 6: Loading Panel Assy
SCD-XA1200ES 3-3. LOADING PANEL ASSY 3 four claws 4 loading panel assy cam (66) 1 Rotate the cam (66) with a screw driver in the direction of arrow A . 3-4. MECHANISM DECK (CDM66D-DVBU50) 3 three screws (BVTT3 × 8) -
Page 7: Main Board
SCD-XA1200ES 3-5. MAIN BOARD 1 wire (flat type) (13 core) (CN702) 2 wire (flat type) (31 core) (CN703) MAIN board 8 two screws (BVTT3 × 8) 6 connector screw (CN301) 3 connector (CN151) 9 MAIN board 4 connector (CN901) 5 connector... -
Page 8: Base Unit (Dvbu50)
SCD-XA1200ES 3-7. BASE UNIT (DVBU50) 2 base unit (DVBU50) 1 floating screw (DIA. 12) 3-8. WALTZ-RF BOARD, OPTICAL TRAVERSE UNIT (DBU-3) 6 three step screws (M3) 7 optical traverse unit (DBU-3) 2 claw 3 flexible flat cable (24 core) 5 WALTZ-RF board... -
Page 9: Loading Board, Motor (L) Assy (Loading) (M151)
SCD-XA1200ES 3-9. LOADING BOARD, MOTOR (L) ASSY (LOADING) (M151) 5 belt (LD) 6 two screws (B2.6 × 4) 4 gear (LD) 1 two claws 3 tray (66) 9 motor (L) assy (loading) (M151) 8 LOADING board 7 Remove two solders. -
Page 10: Test Mode
SCD-XA1200ES SECTION 4 TEST MODE PANEL CHECK MODE Procedure: 1. While shorting the land A of the figure below and ground, knob, press the [POWER] button and pressing the . AMS > to turn the power on. 2. When enter the panel check mode, fluorescent indicator tube and LEDs all light up for 5 seconds. - Page 11 SCD-XA1200ES TEST MODE 1. Entering The Test Mode While press the [MENU] button and knob, press the . AMS > [POWER] button to turn the power on and enter the test mode and display “DIAG MODE”. 2. Operating The Test Mode Procedure: 1.
-
Page 12: Electrical Adjustments
SCD-XA1200ES Ver. 1.1 SECTION 5 ELECTRICAL ADJUSTMENTS Adjust it as follows after the optical traverse unit (DBU-3), WALTZ- 3. OPTICAL SENSITIVITY CHECK RF board, MAIN board, master controller (IC705), SA-CD/CD Connection: decoder (IC706) and EEPROM (IC702) are replaced. oscilloscope Adjustments Frow MAIN board 1. - Page 13 SCD-XA1200ES 4. MODE SETTING FOR SHIPPING Perform this setting when the EEPROM (IC702) on the MAIN board is replaced. Procedure: 1. While pressing the [MENU] button and jog press . AMS > the [POWER] button to turn the power on and enter the Test Mode and display “DIAG MODE”.
-
Page 14: Diagrams
SCD-XA1200ES SECTION 6 DIAGRAMS 6-1. BLOCK DIAGRAM – MAIN Section – J341 WAVE SHAPER COAXIAL Q341 DIGITAL (CD) SA-CD/CD DECODER IC706 OPTICAL DOUT958 TRANSCEIVER OPTICAL IC330 1 RFIP ATOP 61 AIP 56 DIP SIGO RFIN CDDATA, CDBCK, CDLRCK, DSL, DSR,... -
Page 15: Block Diagram - Amp Section
SCD-XA1200ES 6-2. BLOCK DIAGRAM – AMP Section – RV881 PHONE LEVEL LINE AMP J881 IC309 (2/2) – 2 PHONES MUTING Q403 LINE AMP IC309 (1/2) – 1 MUTING Q503 J352 2CH OUT J351 CDDATA, CDBCK, CDLRCK, DSL, DSR, LINE AMP... -
Page 16: Block Diagram - Panel/Power Supply Section
SCD-XA1200ES 6-3. BLOCK DIAGRAM – PANEL/POWER SUPPLY Section – DISPLAY CONTROLLER MASTER CONTROLLER IC801 IC705 (2/2) T101 ISFI MAIN POWER IFSO TRANSFORMER XSCK1 IFSC XIFCS SEGMENT DRIVE XIFINT XRST 59 45 FIP33 FL801 Q821 FLUORESCENT RESET SIGNAL –33V INDICATOR XRESET... - Page 17 SCD-XA1200ES • Note for Printed Wiring Boards and Schematic Diagrams • Circuit Boards Location Note on Printed Wiring Board: Note on Schematic Diagram: TRANS board • X : parts extracted from the component side. • All capacitors are in µF unless otherwise noted. (p: pF) •...
-
Page 18: Printed Wiring Board - Waltz-Rf Board
SCD-XA1200ES • See page 17 for Circuit Boards Location. 6-4. PRINTED WIRING BOARD – WALTZ-RF Board – : Uses unleaded solder. WALTZ-RF BOARD WALTZ-RF BOARD (SIDE B) (SIDE A) CN003 R055 R018 R054 C026 C046 R053 C036 R052 C040 C038... -
Page 19: Schematic Diagram - Waltz-Rf Board
SCD-XA1200ES • See page 31 for Waveforms. • See page 33 for IC Pin Function Description. 6-5. SCHEMATIC DIAGRAM – WALTZ-RF Board – WALTZ-RF BOARD CN002 C011 0.01 C001 0.01 C004 C027 0.01 6.3V C002 0.01 C044 C039 0.01 (Page 22) -
Page 20: Printed Wiring Board - Main Section (1/2)
SCD-XA1200ES • Semiconductor • See page 17 for Circuit Boards Location. 6-6. PRINTED WIRING BOARD – MAIN Section (1/2) – : Uses unleaded solder. Location Ref. No. Location D321 D509 WALTZ-RF (Page 18) D511 MAIN BOARD (COMPONENT SIDE) BOARD CN002... -
Page 21: Printed Wiring Boards - Main Section (2/2)
SCD-XA1200ES • See page 17 for Circuit Boards Location. 6-7. PRINTED WIRING BOARDS – MAIN Section (2/2) – : Uses unleaded solder. MAIN BOARD (CONDUCTOR SIDE) LOADING BOARD S272 LOADING CN151 S271 OPTICAL LOADING M151 (LOADING) DIGITAL (CD) 1-645-721- (21) -
Page 22: Schematic Diagram - Main Section (1/5)
SCD-XA1200ES • See page 31 for Waveforms. • See page 33 for IC Pin Function Description. 6-8. SCHEMATIC DIAGRAM – MAIN Section (1/5) – IC703 (1/5) µPC2918T +1.8V REGULATOR C714 C706 C754 C751 100p C776 C779 C781 C789 +3.3V C709... -
Page 23: Schematic Diagram - Main Section (2/5)
SCD-XA1200ES 6-9. SCHEMATIC DIAGRAM – MAIN Section (2/5) – (2/5) (Page 22) D509 DAP202UT106 R852 SPDLSTOP VC_DSP R831 R840 R897 R877 C814 100k 470k 470k 0.22 MDS0 C796 C793 R858 C815 C825 R878 120k 0.015 0.0015 470k C800 MDP0 R860... -
Page 24: Schematic Diagram - Main Section (3/5)
SCD-XA1200ES • See page 32 for IC Block Diagrams. • See page 33 for IC Pin Function Description. 6-10. SCHEMATIC DIAGRAM – MAIN Section (3/5) – (3/5) (Page 23) RB612 RB607 (Page 22) (Page 22) CN703 RB606 FL606 R701 IFSI0... -
Page 25: Schematic Diagram - Main Section (4/5)
SCD-XA1200ES • See page 31 for Waveforms. • See page 32 for IC Block Diagrams. 6-11. SCHEMATIC DIAGRAM – MAIN Section (4/5) – AUR-MUTE (4/5) AUL-MUTE AU_M/2 +3.3V R330 (Page 22) C281 2200p RB301 R328 R323 4.7k Q301 Q303 Q305... -
Page 26: Schematic Diagram - Main Section (5/5)
SCD-XA1200ES 6-12. SCHEMATIC DIAGRAM – MAIN Section (5/5) – (5/5) D983 IC985 1SR154-400TE25 BA12FP-E2 +12V REGULATOR C995 D984 1SR154-400TE25 CN981 C934 C933 D964 C932 1SS355TE-17 D981 1000 1SR154-400TE25 AGND D936 C981 C954 C953 1SR154-400TE25 0.01 (Page 30) D931 D933 1SR154-400TE25... -
Page 27: Schematic Diagram - Display Board
SCD-XA1200ES • See page 31 for Waveforms. • See page 33 for IC Pin Function Description. 6-13. SCHEMATIC DIAGRAM – DISPLAY Board – CN805 R826 C804 R820 C819 KEY1 0.01 R819 (Page 30) CN802 REMOTE CONTROL FIP38 RECEIVER R818 C803... -
Page 28: Printed Wiring Boards - Panel Section
SCD-XA1200ES • See page 17 for Circuit Boards Location. 6-14. PRINTED WIRING BOARDS – PANEL Section – : Uses unleaded solder. DISPLAY BOARD 1-870-785- (12) FLUORESCENT INDICATOR MAIN BOARD TUBE CN703 (Page 20) KEY-L BOARD KEY-R BOARD CN810 CN813 CN811... -
Page 29: Printed Wiring Boards - Power Supply Section
SCD-XA1200ES • See page 17 for Circuit Boards Location. 6-15. PRINTED WIRING BOARDS – POWER SUPPLY Section – : Uses unleaded solder. AC INLET BOARD T102 SUB POWER TRANSFORMER C111 C110 CN113 L110 MAIN LINE BOARD FILTER CN981 (Page 21) -
Page 30: Schematic Diagram - Key/Power Supply Section
SCD-XA1200ES 6-16. SCHEMATIC DIAGRAM – KEY/POWER SUPPLY Section – R864 R863 R862 R861 4.7k 2.2k 2.2k CN813 S865 S863 S862 S861 KEY1 S891 POWER T102 TIME/TEXT MULTI/2CH SA-CD/CD MENU (Page 27) SUB POWER TRANSFORMER CN892 C891 0.0022 250V L110 LINE FILTER... - Page 31 SCD-XA1200ES • Waveforms – WALTZ-RF Board – – MAIN Board – – DISPLAY Board – IC001 tl (SIGO) IC706 uk (DSPHREFO) IC801 4 (X2) (CD play mode) 3.4 Vp-p 2.1 Vp-p 354 ns 200 ns 1.5 Vp-p 500 mV/DIV, 200 ns/DIV...
- Page 32 SCD-XA1200ES • IC Block Diagrams – MAIN Board – IC200, 230, 260 DSD1751DBQR DSDL DBCK DSDR DSCK FILTER PSCK PBCK MODE PDATA FILTER CONTROL MULTI-LEVEL (X8 DF) DELTA-SIGMA PLRCK MODULATOR DGND ZEROR/ZEROA ZEROL/NA MULTI-LEVEL VOUTL ANALOG VOUTR VCOM AGND IC701 M51957BFP-600C...
- Page 33 SCD-XA1200ES • IC Pin Function Description WALTZ-RF BOARD IC001 SP3726A (SA-CD/CD RF AMP, FOCUS/TRACKING ERROR AMP) Pin No. Pin Name Description RFIP RF signal input from the optical traverse unit RFIN RF signal input terminal Not used Tracking low-pass filter terminal...
- Page 34 SCD-XA1200ES Pin No. Pin Name Description Ground terminal (for RF block and serial port) 54, 55 FNN, FNP Differential filter normal signal output terminal 56, 57 DIP, DIN Analog signal input terminal for RF single buffer RF AGC gain control terminal...
- Page 35 SCD-XA1200ES MAIN BOARD IC705 HD6432238RP02TEV (MASTER CONTROLLER) Pin No. Pin Name Description SDATA_DAC Serial data output to the D/A converter SCLK_DAC Serial data transfer clock signal output to the D/A converter SLATR_DAC Serial data latch pulse signal output to the D/A converter...
- Page 36 SCD-XA1200ES Pin No. Pin Name Description Not used Not used Read enable signal output to the SA-CD/CD decoder Write enable signal output to the SA-CD/CD decoder XWRST Reset signal output to the SA-CD/CD decoder "L": reset XWAIT Wait signal input from the SA-CD/CD decoder SMUTE Soft muting on/off control signal output to the SA-CD/CD decoder "H": muting on...
- Page 37 SCD-XA1200ES MAIN BOARD IC706 CXD2754Q (SA-CD/CD DECODER) Pin No. Pin Name Description CKVDD Power supply terminal (+1.8V) (for clock multiplier PLL) CKVSS Ground terminal (for clock multiplier PLL) MCKI System clock (11.2896 MHz) signal input terminal 4, 5 System clock setting terminal Fixed at 11.2896 MHz in this set...
- Page 38 SCD-XA1200ES Pin No. Pin Name Description DSPHREFI Phase reference signal input terminal (for DSD output phase modulation) Not used DSPHREFO Phase reference signal output to the D/A converter (for DSD output phase modulation) VDDSD0 Power supply terminal (+3.3V) (for DSD data output)
- Page 39 SCD-XA1200ES Pin No. Pin Name Description XCAS Column address strobe signal output to the SD-RAM VDC7 Power supply terminal (+1.8V) (for core) VSC7 Ground terminal (for core) XMWR Write enable signal output to the SD-RAM MCKE Clock enable signal output to the SD-RAM...
- Page 40 SCD-XA1200ES Pin No. Pin Name Description SSIMON0 Not used Pull-in signial input from the SA-CD/CD RF amplifier (for internal Tracking zero crossing signal PI_F generation) Tracking error signal input from the SA-CD/CD RF amplifier (for internal Tracking zero crossing TE_F...
- Page 41 SCD-XA1200ES DISPLAY BOARD IC801 uPD780232GC-706-8BT-A (DISPLAY CONTROLLER) Pin No. Pin Name Description VDD1 Power supply terminal (+3.3V) VSS1 Ground terminal System clock input terminal (5 MHz) System clock output terminal (5 MHz) Not used System reset signal input from the reset signal generator "L": reset XRESET For several hundreds msec.
-
Page 42: Exploded Views
SCD-XA1200ES SECTION 7 EXPLODED VIEWS NOTE: • -XX and -X mean standardized parts, so they • Items marked “*” are not stocked since they The components identified by mark 0 or dotted line with mark 0 are may have some difference from the original are seldom required for routine service. -
Page 43: Display Board Section
SCD-XA1200ES 7-2. DISPLAY BOARD SECTION not supplied not supplied (ACSW board) not supplied (DISPLAY board) not supplied (KEY-L board) not supplied not supplied (HP board) J881 RV881 not supplied supplied not supplied supplied with J881 (KEY-R board) not supplied supplied... -
Page 44: Front Panel Section
SCD-XA1200ES 7-3. FRONT PANEL SECTION not supplied supplied supplied Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 2-685-314-01 PANEL, FRONT 4-246-561-21 BASE (R), PANEL 4-246-564-21 ESCUTCHEON (B) 4-246-563-21 ESCUTCHEON (A) 4-246-562-22 BASE (L), PANEL 4-250-643-01 SHEET (ES-A), ADHESIVE... -
Page 45: Main Board Section
SCD-XA1200ES 7-4. MAIN BOARD SECTION supplied not supplied (TRANS board) not supplied not supplied not supplied T101 (AC INLET board) supplied supplied J110 supplied T102 not supplied not supplied not supplied not supplied not supplied Note: If Ref. No. 154 is replaced, install it after bending it in the same form as that before replacement. -
Page 46: Mechanism Deck Section (Cdm66D-Dvbu50)
SCD-XA1200ES 7-5. MECHANISM DECK SECTION (CDM66D-DVBU50) not supplied not supplied optical pick-up section (DVBU50) M151 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 4-227-899-31 SCREW (DIA. 12), FROATING 4-232-711-01 GEAR (LD) 1-645-721-11 LOADING BOARD 3-053-844-01 YOKE... -
Page 47: Optical Pick-Up Section (Dvbu50)
SCD-XA1200ES 7-6. OPTICAL PICK-UP SECTION (DVBU50) Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 4-218-253-52 SCREW (M2.6), +BTTP 3-053-847-31 INSULATOR A-4750-527-A WALTZ-RF BOARD, COMPLETE 4-240-953-05 HOLDER (66D) 4-981-923-01 SCREW (M), STEP 0 555 A-1109-164-A OPTICAL TRAVERSE UNIT (DBU-3) -
Page 48: Electrical Parts List
SCD-XA1200ES SECTION 8 AC INLET ACSW DISPLAY ELECTRICAL PARTS LIST NOTE: • Items marked “*” are not stocked since they • Due to standardization, replacements in the The components identified by mark 0 or dotted line with mark 0 are parts list may be different from the parts are seldom required for routine service. - Page 49 SCD-XA1200ES DISPLAY KEY-L KEY-R LOADING MAIN Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark < SWITCH > R826 1-216-833-11 METAL CHIP 1/10W R827 1-216-845-11 METAL CHIP 100K 1/10W S861 1-762-875-21 SWITCH, KEYBOARD (MENU) R828 1-216-845-11 METAL CHIP...
- Page 50 SCD-XA1200ES MAIN Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark C305 1-164-156-11 CERAMIC CHIP 0.1uF C713 1-117-681-11 ELECT CHIP 100uF C714 1-126-246-11 ELECT CHIP 220uF C321 1-162-917-11 CERAMIC CHIP 15PF C715 1-164-156-11 CERAMIC CHIP 0.1uF C322...
- Page 51 SCD-XA1200ES MAIN Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark C783 1-117-681-11 ELECT CHIP 100uF D509 8-719-941-09 DIODE DAP202U D511 8-719-941-09 DIODE DAP202U C785 1-126-246-11 ELECT CHIP 220uF D921 8-719-053-18 DIODE 1SR154-400TE-25 C787 1-164-156-11 CERAMIC CHIP 0.1uF...
- Page 52 SCD-XA1200ES MAIN Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark J351 1-785-489-11 JACK, PIN 6P (ANALOG 5.1CH OUT FRONT/ R438 1-216-815-11 METAL CHIP 1/10W SURROUND/ CENTER/SUB WOOFER) R439 1-216-813-11 METAL CHIP 1/10W J352 1-785-868-21 JACK, PIN 2P (ANALOG 2CH OUT)
- Page 53 SCD-XA1200ES MAIN WALTZ-RF Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark A-4750-527-A WALTZ-RF BOARD, COMPLETE R885 1-216-835-11 METAL CHIP 1/10W ************************* R886 1-216-844-11 METAL CHIP 1/10W R888 1-216-835-11 METAL CHIP 1/10W < CAPACITOR > R889 1-216-864-11 SHORT CHIP...
- Page 54 SCD-XA1200ES WALTZ-RF TRANS Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark < TRANSISTOR > ACCESSORIES ************ Q001 8-729-903-46 TRANSISTOR 2SB1132-P Q002 8-729-903-46 TRANSISTOR 2SB1132-P 1-479-825-11 REMOTE COMMANDER (RM-ASU001) (including battery cover) < RESISTOR > 1-757-960-22 CORD, CONNECTION...
- Page 55 SCD-XA1200ES MEMO...
-
Page 56: Revision History
SCD-XA1200ES REVISION HISTORY Clicking the version allows you to jump to the revised page. Also, clicking the version at the top of the revised page allows you to jump to the next revised page. Ver. Date Description of Revision 2006.08 2007.07...
