- Page 1 Installation Manual LEX3L www.gromaudio.com www.gromaudio.com/support.html...
-
Page 2: Table Of Contents
CONTENTS Package contents......................3 CHAPTER 1 — INSTALLATION.................3 1.1 Before Installation 1.2 Tools 1.3 Vehicle Installation 1.4 Safety Guidelines & Appropriate Use Connect supplied Display Harness Cable to factory Display....5 Connect VLine Interface cable to Factory Head unit......6 Connecting to VLine..................6 Routing the GPS Antenna..................7 Routing the Microphone..................8... -
Page 3: Package Contents
GROM-VLINE SYSTEM PACKAGE CONTENTS VTOYA3 Video Cable MCFTOY1+LEXTOYF Power VLine module Interface Cable GPS Antenna Microphone USB Extension cable *NOTE for VLite VT2: The GPS Antenna and the USB Extension Cable are not included in the VLite VT2 package. You can order them separately if desired. CHAPTER 1 —... -
Page 4: Safety Guidelines & Appropriate Use
wiring installation requires special technical skills and experience. If you do not feel comfortable doing the installation please consult with your local car audio shop or installation professional for instructions or assistance if necessary. Carefully remove the factory Stereo and Display out of the dash cavity with proper tools. -
Page 5: Connect Supplied Display Harness Cable To Factory Display
Connect the supplied VTOYA3 video cable to the factory LCD display Locate the 10-pin main display port on the rear of the stereo LCD display. Disconnect the factory display cable from the rear of the stereo LCD display. Then, plug in the supplied VTOYA3 cable and reconnect the dis- connected car factory cable into the female plug of the provided VTOYA3 video cable. -
Page 6: Connect Vline Interface Cable To Factory Head Unit
Connect the VLine Interface MCFTOY1 +LEXTOYF cable to the factory stereo Locate the 16-pin connector and unplug it. Plug in supplied MCFTOY1+LEXTOYF Interface power cable. Reconnect what was disconnected from the rear of the stereo back into the female plug of the supplied interface cable. -
Page 7: Routing The Gps Antenna
Routing the GPS Antenna The GPS Antenna module is supplied with double sided tape. It can be mounted to the top of dashboard or to outside of vehicle whichever you prefer. Route to desired location. We recommend mounting on inside of vehicle on passenger side of the Dashboard as shown below. -
Page 8: Routing The Microphone
Routing the microphone Route the microphone to a location where it will be able to pick up the voice clearly. We recommend mounting the microphone near the rearview mirror but not directly on the windshield glass. Avoid sticking it to a hard surface, as it will pick up more noise. -
Page 9: Mounting The Vline Module
Testing the VLine operation Test VLine operation before fully mounting the LCD display, stereo and dash- board. WARNING: Make sure to reconnect all unplugged connectors, except external CD changer, back to the vehicle before cycling the ignition. Cycle the ignition and enter the external CD mode of your stereo. Press CD / Disc button a few times until in VLine mode. -
Page 10: Understanding Vline Ports
Understanding the VLine Ports HDMI Output WiFi / Bluetooth Antenna USB1 iPhone GPS / AV / Camera Input USB 1 HDMI IN HDMI OUT USB 2 CAMERA AV1 HDMI Input MicroSD Card Microphone (Pin side up*) USB2 OTG/USB storage USB1 iPhone connection Any other USB device (Keyboard / Mouse) USB2... -
Page 11: Chapter 2 - Getting Started
CHAPTER 2 — GETTING STARTED 2.1 Initializing After connecting the VLine module to the stereo, an Ignition Cycle will have to be performed for the stereo to discover Vline and allow Vline to self configure. To INITIALIZE: 1. Put Ignition Switch to “ACC” or “ON” position 2. - Page 12 Track selection can be done with the stereo’s SEEK TRACK ^ and v buttons or steering wheel buttons. I mportant! Factory CD changer Equipped vehicles When installing the GROM-VLINE module, It may be necessary for some vehicles to disconnect external CD changer, mounted in the g love c ompartment, a rmrest or t runk.
-
Page 13: Troubleshooting And Tips
Using External Keyboard or Mouse You can attach external USB mouse or keyboard to any USB ports of VLine, for easier operation, when you need to type-in password, or apply firmware update. Adjusting Audio Bass, Treble, Balance/Fade for VLINE Mode - using Factory UI Use the Factory UI icon to get to the factory UI and adjust sound settings. -
Page 14: Warranty
Unless otherwise prescribed by law, GROM Audio shall not be liable for any personal injury, property damage and or any incidental or consequential damages of any kind (including water damage) resulting from malfunctions, defects, misuse, improper installation or alteration of this product. -
Page 15: Grant Of License
IN CONNECTION WITH ANY BUSINESS, LOSS OF ANY GOODWILL, OR DAM- AGES. THE TERM ‘INCIDENTAL DAMAGES’ REFERS TO THE EXPENSES OF TRANSPORTING THE PRODUCTS TO THE GROM AUDIO SERVICE CENTER, LOSS OF THE END-USERS [ORIGINAL PURCHASER’S] TIME, LOSS OF THE USE OF THE PRODUCT, BUS FARES, CAR RENTALS OR OTHER COSTS RELATED TO THE CARE AND CUSTODY OF THE PRODUCT. - Page 16 PROPERLY, RESULTING FROM THE USE OR INABILITY TO USE THE PRODUCTS, INCLUDING ANY DAMAGES INCURRED DUE TO THE NEGLIGENT OPERATION OF A MOTOR VEHICLE, IN CONJUNCTION WITH THE USE OF SAID PRODUCTS. THE END USER ACKNOWLEDGES ITS RESPONSIBILITY FOR THE USE OF THE PRODUCT.
- Page 17 - in a manner that would distract the driver or that may otherwise cause injury or death to vehicle occupants or bystanders. GROM Audio is not in any way responsible for any such use by you. In all cases, GROM Audio may limit or revoke your use for any reason and at any time.
-
Page 18: Third Party Materials
By using the Third Party Materials, you agree to comply with the use terms of the provider of such Third-Party Materials. GROM AUDIO does not warrant or endorse and does not assume and will not have any liability or responsibility to you or any other person for any Third Party Materials or for any other materials, products, or services of third parties. - Page 19 A. INDEMNIFICATION OF GROM AUDIO, ITS AGENTS AND EMPLOYEES. By Purchasing, Installing and Using the Products, You, the End- User, agree to indemnify, defend and hold harmless, GROM AUDIO, and it s Affiliates, Directors, Officers, Agents and Employees from any Liabilities, Damage, Loss, Claim and Expense (including reasonable Attorney’s Fees) arising out of the...
-
Page 20: Grom Audio Compatibility Disclaimer
GROM AUDIO. Quantit- ies are subject to availability. E. ENTIRE AGREEMENT. These terms and conditions constitute the entire...
