GROM Audio VLINE LEX6 Installation Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
INSTALLATION
MANUAL
LEX6
www.gromaudio.com
www.gromaudio.com/support.html

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VLINE LEX6 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GROM Audio VLINE LEX6

Summary of Contents for GROM Audio VLINE LEX6

  • Page 1 INSTALLATION MANUAL LEX6 www.gromaudio.com www.gromaudio.com/support.html...

  • Page 2: Table Of Contents

    CONTENTS Package contents......................3 CHAPTER 1 — INSTALLATION.................3 1.1 Before Installation 1.2 Tools 1.3 Vehicle Installation 1.4 Safety Guidelines & Appropriate Use Connect supplied Display Harness Cable to factory Display....5 Connect VLine Interface cable to Factory Head unit......6 Connecting to VLine..................6 Routing the GPS Antenna..................7 Routing the Microphone..................8...

  • Page 3: Package Contents

    GROM-VLINE SYSTEM PACKAGE CONTENTS VLine module GVMF MCFLEX6 Display Harness Power Harness GPS Antenna Microphone USB Extension cable CHAPTER 1 — INSTALLATION 1.1 Before Installation Before starting work with any wiring, please wait 90 seconds after turning the Ignition to the OFF position and disconnecting the negative (-) terminal of the battery.

  • Page 4: Safety Guidelines & Appropriate Use

    wiring installation requires special technical skills and experience. If you do not feel comfortable doing the installation please consult with your local car audio shop or installation professional for instructions or assistance if necessary. Carefully remove the factory Stereo and Display out of the dash cavity with proper tools.

  • Page 5: Connect Supplied Display Harness Cable To Factory Display

    Connect supplied Display Harness Cable to factory Display Locate BLUE Display port on rear of Multi Display ECU. If the port is Empty, plug in supplied video cable (GVMF) into port and leave female portion of cable with nothing attached. If there is cable plugged in, disconnect factory Display cable (typically Blue in color).

  • Page 6: Connect Vline Interface Cable To Factory Head Unit

    Connect VLine Interface cable to Factory Head unit Locate 12-pin and 8-pin connectors at the back of the stereo, as shown on one illustration on page 5. Unplug what was previously connected, if anything. Leave these connectors unpluged. Plug in supplied Power Audio Wiring Harness Interface cable (MCFLEX6) into both 8-pin and 12-pin .

  • Page 7: Routing The Gps Antenna

    Routing the GPS Antenna The GPS Antenna module is magnetic as well as supplied with double sided tape. It can be mounted to the top of dashboard or to outside of vehicle whichever you prefer. Route to desired location. We recommend mounting on inside of vehicle on passenger side of the Dashboard as shown below.

  • Page 8: Routing The Microphone

    Routing the Microphone Route microphone to a location where it will be able to pick up voice clearly. We recommend to mount MIC nearby the rear view mirror but not directly on windshield glass. Avoid sticking to the hard surface as it will pick up more noise.

  • Page 9: Mounting The Vline Module

    Mounting the VLine Module Mount module in location free of any moving parts. We strongly recommend mounting the module in an easily accessible location such as the glove compartment for easy access to the USB ports and in case of needing to upgrade firmware on the VLine module.

  • Page 10: Understanding Vline Ports

    Understanding VLine Ports WiFi / Bluetooth Not Used Antenna USB1 iPhone GPS / AV / Camera Input USB 1 HDMI IN HDMI OUT USB 2 CAMERA AV1 HDMI Input MicroSD Card Microphone (Pin side up*) USB2 OTG/USB storage USB1 iPhone connection Any other USB device (Keyboard / Mouse) USB2 USB flash drive...

  • Page 11: Chapter 2 - Getting Started

    CHAPTER 2 — GETTING STARTED 2.1 Initializing After connecting the VLine module to the stereo, an Ignition Cycle will have to be performed for the stereo to discover Vline and allow Vline to self configure. To INITIALIZE: 1. Put Ignition Switch to “ACC” or “ON” position 2.
  • Page 12 Adjusting Audio Bass, Treble, Balance/Fade for VLINE Mode. To adjust, press SCAN button 3(three) times. Factory display will switch from VLine Interface into factory CD changer interface to adjust Audio settings. Press SCAN button 3 (three) times again to switch back into VLine Interface mode again Track selection can be done with the stereo’s SEEK TRACK ^ and v buttons or steering wheel buttons.

  • Page 13: Support

    Unless otherwise prescribed by law, GROM Audio shall not be liable for any personal injury, property damage and or any incidental or consequential damages of any kind (including water damage) resulting from malfunctions, defects, misuse, improper installation or alteration of this product.

  • Page 14: Grant Of License

    BETWEEN YOU, AS “THE END USER”, AND GROM Audio (“GROM”). PLEASE CAREFULLY READ THE TERMS AND CONDITIONS OF THIS AGREEMENT BEFORE USING THE GROM PRODUCTS. BY USING THE GROM PRODUCT AND THE SOFTWARE INSTALLED ON THE GROM PRODUCT, YOU ARE AGREEING TO BE BOUND BY THE TERMS OF AGREEMENT.

  • Page 15: Operational Warning And Safety Instructions

    IN CONNECTION WITH ANY BUSINESS, LOSS OF ANY GOODWILL, OR DAMAGES. THE TERM ‘INCIDENTAL DAMAGES’ REFERS TO THE EXPENSES OF TRANSPORTING THE PRODUCTS TO THE GROM AUDIO SERVICE CENTER, LOSS OF THE END-USERS [ORIGINAL PURCHASER’S] TIME, LOSS OF THE USE OF THE PRODUCT, BUS FARES, CAR RENTALS OR OTHER COSTS RELATED TO THE CARE AND CUSTODY OF THE PRODUCT.
  • Page 16 INJURY OR DEATH. IF YOU, THE END-USER ALLOW ANOTHER PERSON TO USE THE VEHICLE, IT IS YOUR RESPONSIBILITY TO THOROUGHLY BRIEF THAT OTHER USER, ON THE SAFETY REQUIREMENTS FOR OPERATING THE VEHICLE AND THE PRODUCTS INSTALLED THEREIN. (B) SAID DISCLAIMERS SHALL APPLY TO THE USE OF SAID PRODUCTS, EVEN IF GROM HAS BEEN INFORMED OF, KNEW OF, OR SHOULD HAVE KNOWN OF THE LIKELIHOOD OF SUCH DAMAGES.
  • Page 17 - in a manner that would distract the driver or that may otherwise cause injury or death to vehicle occupants or bystanders. GROM Audio is not in any way responsible for any such use by you. In all cases, GROM Audio may limit or revoke your use for any reason and at any time.
  • Page 18 By using the Third Party Materials, you agree to comply with the use terms of the provider of such Third-Party Materials. GROM AUDIO does not warrant or endorse and does not assume and will not have any liability or responsibility to you or any other person for any Third Party Materials or for any other materials, products, or services of third parties.
  • Page 19 A. INDEMNIFICATION OF GROM AUDIO, ITS AGENTS AND EMPLOYEES. By Purchasing, Installing and Using the Products, You, the End- User, agree to indemnify, defend and hold harmless, GROM AUDIO, and it s Affiliates, Directors, Officers, Agents and Employees from any Liabilities, Damage, Loss, Claim and Expense (including reasonable Attorney’s Fees) arising out of the...
  • Page 20 Should you experience incompatibility issues, you may contact us via our support page. GROM Audio also carries a standard 30 day return policy. ENGINE/SYSTEM NOISE DISCLAIMER Engine / system noise may occur in some installations and is not easily predictable.
