Page 2 Third Edition (November 2024) © Copyright Lenovo 2024. LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant to a General Services Administration “GSA” contract, use, reproduction, or disclosure is subject to restrictions set forth in Contract No. GS-...
Page 3: Table Of Contents
Reset or restore Windows ... Retaining serial numbers ... Use Lenovo recovery options..Restoring the serial number of the system Use Window recovery options .
Page 4 (for selected models) ..How to input the product information with Lenovo Integrated Pen (for selected ThinkPad X13 ThinkPad system board self repair tool ..101 2-in-1 Gen 5 models)... . .
Page 5: About This Manual
Some statements in this manual might not be applicable to the computer. • Before servicing a product, be sure to read all the information under Chapter 1 “Safety information” on page 1 and Chapter 2 “Important service information” on page 19. © Copyright Lenovo 2024...
Page 6 ThinkPad X13 Gen 5 and ThinkPad X13 2-in-1 Gen 5 Hardware Maintenance Manual...
Page 7: Chapter 1. Safety Information
• Fan louvers on the machine help to prevent overheating of internal components. Do not obstruct fan louvers or cover them with labels or stickers. Electrical safety Observe the following rules when working on electrical equipment. © Copyright Lenovo 2024...
Page 8 Important: • Use only approved tools and test equipment. Some hand tools have handles covered with a soft material that does not insulate you when working with live electrical currents. • Many customers have, near their equipment, rubber floor mats that contain small conductive fibers to decrease electrostatic discharges (ESD).
Page 9: Safety Inspection Guide
4. Check for cracked or bulging batteries. 5. Remove the cover. 6. Check for any obvious non-ThinkPad / non-Lenovo alterations. Use good judgment as to the safety of any non-ThinkPad / non-Lenovo alterations. 7. Check inside the unit for any obvious unsafe conditions, such as metal filings, contamination, water or other liquids, or signs of fire or smoke damage.
Page 10: Grounding Requirements
2. Ensure that the ESD protective devices you use have been certified (ISO 9000) as fully effective. When handling ESD-sensitive parts: • Keep the parts in protective packages until they are inserted into the product. • Avoid contact with other people. •...
Page 11 DANGER DANGER DANGER DANGER DANGER DANGER Chapter 1 Safety information...
Page 12 ThinkPad X13 Gen 5 and ThinkPad X13 2-in-1 Gen 5 Hardware Maintenance Manual...
Page 13 PERIGO PERIGO PERIGO Chapter 1 Safety information...
Page 14 PERIGO PERIGO PERIGO PERIGO PERIGO DANGER DANGER ThinkPad X13 Gen 5 and ThinkPad X13 2-in-1 Gen 5 Hardware Maintenance Manual...
Page 15 DANGER DANGER DANGER DANGER DANGER Chapter 1 Safety information...
Page 16 DANGER VORSICHT VORSICHT VORSICHT VORSICHT ThinkPad X13 Gen 5 and ThinkPad X13 2-in-1 Gen 5 Hardware Maintenance Manual...
Page 17 VORSICHT VORSICHT VORSICHT VORSICHT Chapter 1 Safety information...
Page 18 ThinkPad X13 Gen 5 and ThinkPad X13 2-in-1 Gen 5 Hardware Maintenance Manual...
Page 19 Chapter 1 Safety information...
Page 20 ThinkPad X13 Gen 5 and ThinkPad X13 2-in-1 Gen 5 Hardware Maintenance Manual...
Page 21 Chapter 1 Safety information...
Page 22 ThinkPad X13 Gen 5 and ThinkPad X13 2-in-1 Gen 5 Hardware Maintenance Manual...
Page 23 Chapter 1 Safety information...
Page 24 ThinkPad X13 Gen 5 and ThinkPad X13 2-in-1 Gen 5 Hardware Maintenance Manual...
Page 25: Chapter 2. Important Service Information
– “FRU identification” on page 20 Important: • Advise customers to contact the Lenovo Customer Support Center if they need any assistance in obtaining or installing any software fixes, drivers, and UEFI BIOS downloads. Telephone numbers for Lenovo Support are available at: https://pcsupport.lenovo.com/supportphonelist...
Page 26: How To Use Error Message
Dynamic Configure To Order (CTO) model This model provides the ability for a customer to configure a Lenovo solution from a Web Site, and have this configuration sent to fulfillment, where it is built and shipped directly to the customer. The machine label and eSupport will load these products as the 4-character MT, 4-character model, and 2-character country code.
Page 27: Chapter 3. General Checkout
Before checking problems with the computer, determine whether the damage is covered under the warranty by referring to the following list: © Copyright Lenovo 2024...
Page 28: Checkout Guide
Note: If you are unable to isolate and repair the problem yourself after running the program, save and print the log files created by the program. You need the log files when you speak to a Lenovo technical support representative.
Page 29: Quick Test Programs
Vantage app installed. To download and install a quick test program, go to , and follow the instructions https://www.lenovo.com/diags on the Web site. To run a test using quick test program, do the following: Step 1.
Page 30: Bootable Diagnostic Programs
If the computer you are servicing is not installed with the UEFI diagnostic program, you can download a bootable diagnostic program from the Lenovo Support Web site. The bootable diagnostic program enables you to view system information and test some hardware devices in your computer, such as memory, storage devices, the LCD, and system board buses.
Page 31: Checking The Built-In Battery And Operational Charging
Checking the built-in battery and operational charging This system supports only batteries specially designed for this specific system and manufactured by Lenovo or an authorized manufacturer. The system does not support unauthorized batteries or batteries designed for other systems.
Page 32 Wire Voltage (V dc) +2.5 to +3.2 Black Ground • If the voltage is correct, replace the system board. • If the voltage is not correct, replace the coin-cell battery. • If the coin-cell battery discharges quickly after replacement, replace the system board. ThinkPad X13 Gen 5 and ThinkPad X13 2-in-1 Gen 5 Hardware Maintenance Manual...
Page 33: Chapter 4. Related Service Information
When the latest maintenance diskette and the system program service diskette become available, they will be posted on: https://support.lenovo.com Reset or restore Windows To reset or restore Windows, refer to the information below： Use Lenovo recovery options Step 1. Go to https://support.lenovo.com/HowToCreateLenovoRecovery Step 2.
Page 34: Power-On Password
The system management password can also protect the system information stored in UEFI BIOS like a supervisor password, but it has lower authority by default. The system management password can be set through the UEFI BIOS menu or through Windows Management Instrumentation (WMI) with the Lenovo client-management interface.
Page 35: How To Remove The Power-On Password
Lenovo cannot reset your passwords or recover data from the storage drive. You can contact a Lenovo-authorized service provider to have the storage drive replaced. A fee will be charged for parts and service. If the storage drive is a CRU (Customer Replaceable Unit), you can also contact Lenovo to purchase Chapter 4...
Page 36: How To Remove The Hard Disk Password
To put the system back to operational status, the only Lenovo and Lenovo-authorized service solution would be to replace the storage drive with a scheduled fee.
Page 37: Power Management
If a supervisor password has been set and is known to the service technician, do the following to remove the system management password Step 1. Turn on the computer. Step 2. When the ThinkPad logo is displayed, immediately press F1. Step 3.
Page 38: Symptom-To-Fru Index
If you have defined one of the following actions as the event that causes the system to go into hibernation mode, perform that action. • Closing the lid. • Pressing the power button. Also, the computer goes into hibernation mode automatically after a period of inactivity specified in power plan settings.
Page 39 Symptom or error FRU or action, in sequence 0188 Replace the system board. Invalid RFID Serialization Information Area. 0189 Replace the system board. Invalid RFID configuration information area - The EEPROM checksum is not correct. 0190 1. Charge the battery. Critical low-battery error 2.
Page 40: Error Messages
• We recommend that you speak to our Customer Support Center before attempting to service the computer yourself so that you can be directed to the correct documentation and repair information.It might be recommended to have a Lenovo-authorized service provider repair your computer depending on the complexity of the error or fault.
Page 41 Blinking patterns Error codes Solutions 0001: Reset error (platform reset not de- 1. Remove the ac power adapter and the asserted) removable battery if your computer has one. Then, reset the computer by doing one of the following: • For models with the emergency-reset hole, insert a straightened paper clip into the emergency-reset hole to cut off power supply temporarily.
Page 42: No-Beep Symptoms
Blinking patterns Error codes Solutions 0288: Computer display error 1. Reconnect the display cable on both the system board side and the computer display side (service provider only) and check the LCD panel. 2. If step 1 does not work, connect an external display to your computer and check the status (customer or service provider).
Page 43: Lcd-Related Symptoms
If the LCD you are servicing has two or less visible defective pixels, it should not be considered faulty. However, if the LCD has three or more visible defective pixels, it will be deemed as defective by Lenovo and it should be replaced.
Page 44: Intermittent Problems
Table 4. LCD-related symptoms FRU or action, in sequence Symptom or error No beep, power-on indicator on, and a blank LCD during 1. Run LCD Self Test. POST. 2. Replace the system board. • LCD backlight not working. 1. Reseat the LCD connectors. •...
Page 45: Lenovo Memory Self Repair (For Intel Models Only)
LCD assembly Lenovo Memory Self Repair (for Intel models only) Lenovo Memory Self Repair (hereafter referred to as repair tool) enables you to repair memory single-bit or single-row failure with internal redundant resources. It is recommended that you use the repair tool in the following situations: •...
Page 46 ThinkPad X13 Gen 5 and ThinkPad X13 2-in-1 Gen 5 Hardware Maintenance Manual...
Page 47: Chapter 5. Special Keys
Other general keyboard shortcuts Key combination Function description Open the Snipping Tool. Adjust the keyboard backlight (for selected models). Go to beginning. Go to end. Fn+Insert Function as Insert Key. Fn+Tab Open Magnifier. Fn+4 Enter sleep mode. © Copyright Lenovo 2024...
Page 48 Send system request. Fn+N Open system information Window. Fn+G Enable / Disable the tapping gesture to launch TrackPoint Quick Menu. For more keyboard shortcuts, go to https://support.lenovo.com/us/en/solutions/windows-support ThinkPad X13 Gen 5 and ThinkPad X13 2-in-1 Gen 5 Hardware Maintenance Manual...
Page 49: Chapter 6. Locations
Chapter 6. Locations Locating computer controls and connectors Front ThinkPad X13 Gen 5 Description Description Item Item Microphone* Infrared camera / camera* Webcam privacy shutter* Touch screen* © Copyright Lenovo 2024...
Page 50 Description Description Item Item Power button / power button with Speaker fingerprint reader* NFC (near field communication) mark* Trackpad ® TrackPoint pointing stick TrackPoint Three Buttons * for selected models Webcam privacy shutter Slide the webcam privacy shutter to cover or uncover the camera lens. It is designed to protect your privacy. ThinkPad X13 2-in-1 Gen 5 ThinkPad X13 Gen 5 and ThinkPad X13 2-in-1 Gen 5 Hardware Maintenance Manual...
Page 51 Description Description Item Item Microphone* Infrared camera / camera* Webcam privacy shutter* Touch screen Power button / power button with Speaker fingerprint reader* Trackpad NFC (near field communication) mark* ® TrackPoint pointing stick TrackPoint Three Buttons * for selected models Webcam privacy shutter Slide the webcam privacy shutter to cover or uncover the camera lens.
Page 52: Left And Right
USB-A connector (USB 5Gbps, Always (Thunderbolt™ 4) On USB) Audio connector Smart card reader* Lenovo Integrated Pen (for ThinkPad X13 Nano-SIM-card tray* 2-in-1 Gen 5 only)* USB-A connector (USB 5Gbps) HDMI™ connector Security-lock slot * for selected models...
Page 53: Bottom
Bottom ThinkPad X13 Gen 5 ThinkPad X13 2-in-1 Gen 5 Emergency-reset hole Emergency-reset hole can help you to recover computer when the computer stops responding and you cannot turn it off by pressing the power button. Do the following to reset your computer: 1.
Page 54 Note: Some Lenovo computers include a display that can be rotated 360 degrees. When those products are used as a tablet computer, the temperatures of all the accessible parts are within an acceptable range as defined in IEC 62368-1.
Page 55: Locating Frus And Crus
Lenovo will ship the CRU to you. CRU information and replacement instructions are shipped with your product and are available from Lenovo at any time upon request. You can find a list of CRUs for your product in this Hardware Maintenance Manual. An electronic version of this manual can be found at .
Page 56: Major Frus And Crus
Major FRUs and CRUs ThinkPad X13 Gen 5 ThinkPad X13 Gen 5 and ThinkPad X13 2-in-1 Gen 5 Hardware Maintenance Manual...
Page 57 Notes: • Depending on the computer model, your computer might look different from the illustration above. • The Lenovo factory recovery USB key is used to restore the Microsoft Windows operating system. It might not come with the computer, and a user might order it from https://pcsupport.lenovo.com/...
Page 58 ThinkPad X13 2-in-1 Gen 5 Table 6. Major FRUs and CRUs FRU description Self-service Optional-service Base cover assembly Thermal fan assembly ThinkPad X13 Gen 5 and ThinkPad X13 2-in-1 Gen 5 Hardware Maintenance Manual...
Page 59 Notes: • Depending on the computer model, your computer might look different from the illustration above. • The Lenovo factory recovery USB key is used to restore the Microsoft Windows operating system. It might not come with the computer, and a user might order it from https://pcsupport.lenovo.com/...
Page 60: Lcd Frus And Crus
LCD FRUs and CRUs ThinkPad X13 Gen 5 ThinkPad X13 Gen 5 and ThinkPad X13 2-in-1 Gen 5 Hardware Maintenance Manual...
Page 61 Table 7. LCD FRUs and CRUs FRU description Self-service Optional-service LCD bezel sheet LCD bezel LCD panel Camera cable Camera shutter* Dummy camera shutter* Microphone rubber Camera module* Dummy camera module* LCD cover assembly Wireless-LAN antenna kit LCD cable LCD hinges * for selected models Note: Depending on the computer model, your computer might look different from the illustration above.
Page 62 ThinkPad X13 2-in-1 Gen 5 Table 8. LCD FRUs and CRUs FRU description Self-service Optional-service LCD panel assembly Strip Cover Hinge cover Camera cable Camera shutter* Dummy camera shutter* Microphone rubber Camera module ThinkPad X13 Gen 5 and ThinkPad X13 2-in-1 Gen 5 Hardware Maintenance Manual...
Page 63 Table 8. LCD FRUs and CRUs (continued) FRU description Self-service Optional-service AL foil LCD cover assembly Wireless-LAN antenna kit LCD cable LCD hinges * for selected models Note: Depending on the computer model, your computer might look different from the illustration above. Chapter 6 Locations...
Page 64: Miscellaneous Parts
Miscellaneous parts Table 9. Miscellaneous part FRU descriptions Self-service Optional-service Screw kit • For ThinkPad X13 Gen 5: – M2.5 x L3.5, black (6) – M2.5 x L5.0, black(6) – M2.0 x L2.5, black (10) – M1.6 x L2.1, black (18) –...
Page 65: Connector And Cable Guide
• Spec Connector and cable guide This topic provides information to help Lenovo-authorized service technicians identify connectors and cables for replacement purpose. To view each FRU and the exploded illustration of the computer, see “Major FRUs and CRUs” on page 50 and “LCD FRUs and CRUs” on page 54.
Page 66 Table 10. System board connector and cable guide Internal cable required Connector/feature Cable connection Wireless-WAN-module slot Insert a wireless-WAN module into (internal) this slot. LCD connector (internal) LCD cable Connect one end to the LCD panel and the other end to this connector.
Page 67: Looking Up Fru Information
Nano-SIM-card slot (external) Insert a Nano Subscriber Identity Module (SIM) card into this slot. Looking up FRU information For detailed FRU information, including part numbers, descriptions, and substitution part numbers, go to: https://support.lenovo.com/partslookup Chapter 6 Locations...
Page 68 ThinkPad X13 Gen 5 and ThinkPad X13 2-in-1 Gen 5 Hardware Maintenance Manual...
Page 69: Chapter 7. Fru Replacement Notices
• Keep the screw kit in your tool bag. For the part number of the screw kit, go to: https://support.lenovo.com/partslookup Tighten screws as follows: • Plastic to plastic Turn an additional angle of 90 degrees after the screw head touches the surface of the plastic part. © Copyright Lenovo 2024...
Page 70: Sensor Calibration (For Thinkpad X13 2-In-1 Gen 5 Only)
Step 1. Download the Windows Sensor Calibration Tool by following steps: Note: This Sensor Calibration Tool is limited to Lenovo service providers. You can contact a Lenovo-authorized service provider to have your system board or LCD unit replaced. Go to https://support.lenovo.com...
Page 71: Retaining Serial Numbers
Connect a USB memory key to the computer. Step 2. Go to https://www.lenovo.com/maintenanceutilities and follow the instructions on the screen to create a Maintenance Key. Note: Only an authorized Lenovo service technician can access the above Web site. Chapter 7 FRU replacement notices...
Page 72: Retaining The Uuid
Go to and follow the instructions on the screen to https://www.lenovo.com/maintenanceutilities create a Maintenance Key. Note: Only an authorized Lenovo service technician can access the above Web site. Step 3. Restart the computer. Step 4. When the logo screen is displayed, press Esc. The ThinkPad Config Information Update Utility interface is displayed.
Page 73: Reading Or Writing The Eca Information
To check what ECAs have been previously applied to the machine, use the ECA Information Read/Write function on the LENOVO ThinkPad Hardware Maintenance Diskette or Maintenance Key. Step 1. Insert the latest version of LENOVO ThinkPad Hardware Maintenance Diskette or Maintenance Key, and then restart the computer. Step 2.
Page 74 ThinkPad X13 Gen 5 and ThinkPad X13 2-in-1 Gen 5 Hardware Maintenance Manual...
Page 75: Chapter 8. Removing Or Replacing A Fru
Click Power Options, and then click Choose what the power buttons do on the left pane. Step 3. Click Change settings that are currently unavailable at the top. Step 4. If prompted by User Account Control (UAC), click Yes. © Copyright Lenovo 2024...
Page 76: Removing The Nano-Sim Card And Nano-Sim-Card Tray (For Selected Models)
Note: If the computer you are servicing has a nano-SIM card installed, remove the card with the tray together. Lenovo Integrated Pen (for selected ThinkPad X13 2-in-1 Gen 5 models) Step 1. Remove the Lenovo Integrated Pen as shown below.
Page 77: Base Cover Assembly
2. Turn off the computer and disconnect the computer from ac power and all connected cables. 3. Close the computer display and turn over the computer. 4. Remove the Lenovo Integrated Pen. See “Lenovo Integrated Pen (for selected ThinkPad X13 2-in-1 Gen 5 models)” on page 70.
Page 78: Applying Labels To The Base Cover Assembly
If the computer does not start up after you reinstall the base cover assembly, disconnect the ac power adapter and then reconnect it to the computer. Applying labels to the base cover assembly Notes: • Depending on the country or region of delivery, the labels might be slightly different from the ones in the following illustration.
Page 79: Pen Dummy (For Selected Thinkpad X13 2-In-1 Gen 5 Models)
Item Item SVT label Country label IMEI label Asset tag Service QR code Genuine Microsoft label S/N label COA label USA RTC Battery warning label Pen dummy (for selected ThinkPad X13 2-in-1 Gen 5 models) For access, remove these FRUs in order: 1.
Page 80: M.2 Solid-State Drive, Bracket, And Thermal Pad
Step 2. Install the pen dummy in reverse order. M.2 solid-state drive, bracket, and thermal pad Attention: The M.2 solid-state drive is sensitive. Inappropriate handling might cause damage and permanent loss of data. When handling the M.2 solid-state drive, observe the following guidelines: •...
Page 81: Wireless Wan Module, Bracket, And Thermal Pad (For Selected Models)
The following information is only for the computer with user-installable modules. Ensure that you use only a Lenovo-authorized wireless module specifically tested for this computer model. Otherwise, the computer will generate an error-code beep sequence when you turn on the computer.
Page 82 Before you start, read Generic Safety and Compliance Notices Attention: Do not touch the contact edge of the wireless WAN module. Otherwise, the wireless WAN module might get damaged. For access, do the following: 1. Disable the built-in battery. See “Disabling the built-in battery” on page 69. 2.
Page 83 For ThinkPad X13 Gen 5 Step Screw (quantity) Color Torque M2 × 2.3 mm, flat-head, nylon-coated (1) Black 0.181 Nm (1.85 kgf-cm) For ThinkPad X13 2-in-1 Gen 5 Step Screw (quantity) Color Torque M2 × 2.5 mm, flat-head, nylon-coated (1) Black 0.181 Nm (1.85 kgf-cm)
Page 84: Cable Guide
Built-in battery Before you start, read Generic Safety and Compliance Notices CAUTION: Use only the Lenovo-authorized battery specified for the computer. Any other battery could ignite or explode. ThinkPad X13 Gen 5 and ThinkPad X13 2-in-1 Gen 5 Hardware Maintenance Manual...
Page 85 Batteries supplied by Lenovo for use with your product have been tested for compatibility and should only be replaced with approved parts. A battery other than the one specified by Lenovo, or a disassembled or modified battery may not be covered by warranty.
Page 86: Thermal Fan Assembly
Step Screw (quantity) Color Torque White 0.181 Nm M2 × 4.5 mm, flat-head, nylon-coated (4) (1.85 kgf-cm) Step 2. Before installing the built-in battery, thoroughly check the battery compartment and ensure that there are no foreign or sharp objects that could cause damage to the battery. Step 3.
Page 87: Speaker Assembly Of Thinkpad X13 Gen 5
• Do not press the top of the fan cover and the fan hub. • If you are installing back the same thermal fan assembly you have removed (not installing a new one), before you attach the fan assembly to the computer, clean all thermal grease that has been used and then apply new thermal grease.
Page 88 Torque Step Screw (quantity) Color M1.6 x 2.1 mm, flat-head, nylon-coated (3) Black 0.15 Nm (1.0 kgf-cm) Step 2. Install the speaker assembly: • For models without a smart card reader, install the speaker assembly in reverse order. • For models with a smart card reader, install the speaker assembly as below. If there is a sponge or mylar applied on the smart card reader before the speaker assembly installation, remove it.
Page 89 Install the speaker assembly. When in step , press the speaker assembly to ensure the speaker assembly is firmly attached to the mylar. Remove the dummy card if available. When installing: • Ensure that the connector is attached firmly. • Ensure that the cable is routed properly. Chapter 8 Removing or replacing a FRU...
Page 90: Speaker Assembly Of Thinkpad X13 2-In-1 Gen 5
• Ensure that the cable is routed properly. Coin-cell battery of ThinkPad X13 Gen 5 DANGER Use only the Lenovo-authorized battery specified for the computer. Any other battery could ignite or explode. For access, remove these FRUs in order: • “Base cover assembly” on page 71 •...
Page 91 • Reset the system date and time in the BIOS menu. Coin-cell battery of ThinkPad X13 2-in-1 Gen 5 DANGER Use only the Lenovo-authorized battery specified for the computer. Any other battery could ignite or explode. For access, remove these FRUs in order: •...
Page 92: Coin-Cell Battery Of Thinkpad X13 2-In-1 Gen 5
Step 2. When installing: • Ensure that the connector is attached firmly. • Reset the system date and time in the BIOS menu. Smart card reader-Trackpad-NFC cable of ThinkPad X13 Gen 5 (for selected models) For access, remove these FRUs in order: •...
Page 93: Trackpad And Trackpad Cable Of Thinkpad X13 Gen 5
Step 2. When installing: Ensure that the connectors are attached firmly. Smart card reader-Trackpad-NFC cable of ThinkPad X13 2-in-1 Gen 5 (for selected models) For access, remove these FRUs in order: • “Base cover assembly” on page 71 • “Built-in battery” on page 78 •...
Page 94 Step 1. Remove the Trackpad and Trackpad cable as shown below. Step Screw (quantity) Color Torque M1.6 × L2.1 mm, flat-head, nylon-coated (7) Black 0.181 Nm (1.85 kgf-cm) Notes: • A mylar might cover the Trackpad, and ensure that you attach the mylar to the Trackpad after replacement.
Page 95 2. Install the Trackpad with jig as shown. 3. Install the screws to fix the Trackpad. 4. Remove the jig. Chapter 8 Removing or replacing a FRU...
Page 96: Trackpad And Trackpad Cable Of Thinkpad X13 2- In-1 Gen 5
Trackpad and Trackpad cable of ThinkPad X13 2-in-1 Gen 5 For access, remove these FRUs in order: • “Base cover assembly” on page 71 • “Built-in battery” on page 78 • “Smart card reader-Trackpad-NFC cable of ThinkPad X13 2-in-1 Gen 5 (for selected models)” on page 87 Note: There might exist a waterproof mylar covering the Trackpad, remove the mylar before replacement.
Page 97 Step Screw (quantity) Color Torque M1.6 × L2.1 mm, flat-head, nylon-coated (7) Black 0.181 Nm (1.85 kgf-cm) Notes: • A mylar might cover the Trackpad, and ensure that you attach the mylar to the Trackpad after replacement. • Ensure that the connector is attached firmly. Step 2.
Page 98 3. Install the screws to fix the Trackpad. 4. Remove the jig. ThinkPad X13 Gen 5 and ThinkPad X13 2-in-1 Gen 5 Hardware Maintenance Manual...
Page 99: Nfc Card Of Thinkpad X13 Gen 5
NFC card of ThinkPad X13 Gen 5 For access, remove these FRUs in order: • “Base cover assembly” on page 71 • “Built-in battery” on page 78 Step 1. Remove the NFC card as shown below. Step 2. Install the NFC card in reverse order. NFC card of ThinkPad X13 2-in-1 Gen 5 For access, remove these FRUs in order: •...
Page 100: Smart Card Reader (For Selected Models)
Step 2. Install the NFC card in reverse order. Smart card reader (for selected models) For access, remove these FRUs in order: • “Base cover assembly” on page 71 • “Built-in battery” on page 78 • “Speaker assembly of ThinkPad X13 Gen 5” on page 81 •...
Page 101: Wireless Wan Antennas Of Thinkpad X13 Gen 5 (For Selected Models)
• “Base cover assembly” on page 71 • “Built-in battery” on page 78 • “Speaker assembly of ThinkPad X13 Gen 5” on page 81 • “Speaker assembly of ThinkPad X13 2-in-1 Gen 5” on page 84 Step 1. Remove the dummy smart card reader as shown below. Step Screw (quantity) Color...
Page 102: Wireless Wan Antennas Of Thinkpad X13 2-In-1 Gen 5 (For Selected Models)
Step Screw (quantity) Color Torque M1.6 × 2.6 mm, flat-head, nylon-coated (4) White 0.181 Nm (1.85 kgf-cm) Step 2. When installing: Ensure that the connector is attached firmly. Wireless WAN antennas of ThinkPad X13 2-in-1 Gen 5 (for selected models) For access, remove these FRUs: •...
Page 103: Pen Charger Cable (For Selected Thinkpad X13 2-In-1 Gen 5 Models)
Step Screw (quantity) Color Torque M1.6 × 2.5 mm, flat-head, nylon-coated (4) Black 0.181 Nm (1.85 kgf-cm) Step 2. When installing: Ensure that the connector is attached firmly. Pen charger cable (for selected ThinkPad X13 2-in-1 Gen 5 models) For access, remove these FRUs: •...
Page 104: System Board
• After replacing the system board, use the Maintenance Utility to bind the model type, serial number, and Brand ID of the computer with the new system board. Refer to https://support.lenovo.com/us/en/solutions/ for instructions on how to do that. As an alternative, you also can use the Golden Key U1 tool HT506954 for that purpose.
Page 105: Replace The System Board
• Avoid bending a system board and hard pushing to prevent cracking at each BGA (Ball Grid Array) chipset. For access, remove these FRUs in order: • “Removing the nano-SIM card and nano-SIM-card tray (for selected models)” on page 70 •...
Page 106 Step Screw (quantity) Color Torque M2 × 2.5 mm, flat head, nylon-coated (8) Black 0.181 Nm (1.85 kgf-cm) Step 2. Install the system board in reverse order. Notes: • Ensure that the cable is attached firmly. • Apply thermal grease on the thermal fan assembly if needed. For details, see “Thermal fan assembly”...
Page 107: How To Input The Product Information With Thinkpad System Board Self Repair Tool
The process of writing product information can only be used once and if unsure, consider getting support from a Lenovo-authorized service technician. Step 1.
Page 108: Cable Guide For Coin-Cell Battery Of Thinkpad X13 Gen 5
• For models without fingerprint reader, to avoid electrical short circuits, ensure that the acetate tape fully wraps the fingerprint reader connector. Inappropriate handing might cause machine damage. Cable guide for coin-cell battery of ThinkPad X13 Gen 5 For access, remove these FRUs: •...
Page 109: Cable Guide For Coin-Cell Battery Of Thinkpad X13 2-In-1 Gen 5
Step Screw (quantity) Color Torque Black 0.181 Nm M1.6 × 2.1 mm, flat-head, nylon-coated (1) (1.85 kgf-cm) Step 2. When installing: Ensure that the connector is attached firmly. Cable guide for coin-cell battery of ThinkPad X13 2-in-1 Gen 5 For access, remove these FRUs: •...
Page 110: Lcd Unit
Torque Step Screw (quantity) Color M1.6 × 2.5 mm, flat-head, nylon-coated (1) Black 0.181 Nm (1.85 kgf-cm) Step 2. When installing: Ensure that the connector is attached firmly. LCD unit Note: If you replace the system board of ThinkPad X13 2-in-1 Gen 5, remember to make the sensor calibration.
Page 111 Table 11. Screw specification of ThinkPad X13 Gen 5 Step Screw (quantity) Color Torque M 2.5 × 5 mm, flat-head, nylon-coated (6) Black 0.294 Nm (3.0 kgf-cm) Table 12. Screw specification of ThinkPad X13 2-in-1 Gen 5 Step Screw (quantity) Color Torque M 2.5 ×...
Page 112: Keyboard Assembly
Step 2. When installing: Ensure that the connectors are attached firmly. Attention: When you route the cables, ensure that they are not subject to any tension. Tension could cause the cables to be damaged by the cable guides, or a wire to be broken. Keyboard assembly For access, remove these FRUs: •...
Page 113: Lcd Bezel Sheet And Lcd Bezel (For Thinkpad X13 Gen 5 Only)
Step 2. Install the strip cover in reverse order. LCD bezel sheet and LCD bezel (for ThinkPad X13 Gen 5 only) For access, remove these FRUs in order: • “Base cover assembly” on page 71 • “LCD unit” on page 104 Step 1.
Page 114: Lcd Hinges Of Thinkpad X13 2-In-1 Gen 5
• “Base cover assembly” on page 71 • “LCD unit” on page 104 • “LCD bezel sheet and LCD bezel (for ThinkPad X13 Gen 5 only)” on page 107 Step 1. Remove the LCD hinges as shown below. Table 13. Screw specification Step Screw (quantity) Color...
Page 115: Lcd Panel, Lcd Cable And Elastic Adhesive Tapes Of Thinkpad X13 Gen 5
Table 14. Screw specification Step Screw (quantity) Color Torque M2.5 × 3.0 mm, flat-head, nylon-coated (6) Black 0.294 Nm (3.0 kgf-cm) Step 2. Install the LCD hinges in reverse order. LCD panel, LCD cable and elastic adhesive tapes of ThinkPad X13 Gen 5 For access, remove these FRUs in order: •...
Page 116 2. Turn over the LCD panel and detach the LCD cable from the LCD panel as shown. Step 2. Install the LCD panel, LCD cable and elastic adhesive tapes as shown below. 1. Peel off the release liners from one side of the new elastic adhesive tapes. Apply the tapes to the correct locations.
Page 117: Lcd Panel, Lcd Cable And Elastic Adhesive Tapes Of Thinkpad X13 2-In-1 Gen 5
2. Attach the LCD cable to the LCD panel as shown. Turn over the LCD panel to secure the LCD panel with tapes. LCD panel, LCD cable and elastic adhesive tapes of ThinkPad X13 2-in-1 Gen 5 For access, remove these FRUs in order: •...
Page 118 1. Pull out each tape slowly in the direction as shown until the adhesive tapes are all released from LCD unit. Use your palms to slide down the LCD panel in the direction as shown to loosen its hooks. Note: Do not pull the tapes too fast, otherwise, the tapes might snap. 2.
Page 119: Camera-And-Microphone Module And Cable Of Thinkpad X13 Gen 5 (For Selected Models)
2. Attach the LCD cable to the LCD panel as shown. Turn over the LCD panel to secure the LCD panel with tapes. Camera-and-microphone module and cable of ThinkPad X13 Gen 5 (for selected models) For access, remove these FRUs in order: •...
Page 120: Camera-And-Microphone Module And Cable Of Thinkpad X13 2-In-1 Gen 5 (For Selected Models)
Step 1. Remove the camera-and-microphone module and cable as shown below. Step 2. Install the camera-and-microphone module and cable in reverse order. Camera-and-microphone module and cable of ThinkPad X13 2-in-1 Gen 5 (for selected models) For access, remove these FRUs in order: •...
Page 121: Camera Shutter Or Dummy Camera Shutter
Step 2. Install the camera-and-microphone module and cable in reverse order. Camera shutter or dummy camera shutter For access, remove these FRUs in order: • “Base cover assembly” on page 71 • “LCD unit” on page 104 • “Strip cover (for ThinkPad X13 2-in-1 Gen 5 only)” on page 106 •...
Page 122: Wireless Lan Antenna Of Thinkpad X13 Gen 5 (For Selected Models)
Step 2. Install the camera shutter or dummy camera shutter in reverse order. Wireless LAN antenna of ThinkPad X13 Gen 5 (for selected models) For access, remove these FRUs in order: • “Base cover assembly” on page 71 • “LCD unit” on page 104 •...
Page 123: Antenna Locations Of Thinkpad X13 Gen 5
• “LCD unit” on page 104 • “Strip cover (for ThinkPad X13 2-in-1 Gen 5 only)” on page 106 • “LCD hinges of ThinkPad X13 2-in-1 Gen 5” on page 108 • “LCD panel, LCD cable and elastic adhesive tapes of ThinkPad X13 2-in-1 Gen 5” on page 111 Step 1.
Page 124: Antenna Locations Of Thinkpad X13 2-In-1 Gen 5
Wireless LAN antenna (auxiliary)* Wireless LAN antenna (main)* Wireless WAN antenna (MIMO2)* Wireless WAN antenna (auxiliary)* Wireless WAN antenna (main)* Wireless WAN antenna (MIMO1)* * for selected models Antenna locations of ThinkPad X13 2-in-1 Gen 5 ThinkPad X13 Gen 5 and ThinkPad X13 2-in-1 Gen 5 Hardware Maintenance Manual...
Page 125: Lcd Cover Assembly
Wireless LAN antenna (main and auxiliary) Wireless WAN antenna (main)* Wireless WAN antenna (auxiliary)* * for selected models LCD cover assembly For access, remove these FRUs in order: • “Base cover assembly” on page 71 • “LCD unit” on page 104 •...
Page 126 ThinkPad X13 Gen 5 and ThinkPad X13 2-in-1 Gen 5 Hardware Maintenance Manual...
Page 127: Appendix A. Notices
Lenovo representative for information on the products and services currently available in your area. Any reference to a Lenovo product, program, or service is not intended to state or imply that only that Lenovo product, program, or service may be used. Any functionally equivalent product, program, or service that does not infringe any Lenovo intellectual property right may be used instead.
Page 128 Trademarks Lenovo, Lenovo logo, ThinkPad, ThinkPad logo, TrackPoint, and UltraConnect are trademarks of Lenovo. Intel, Intel Optane, and Thunderbolt are trademarks of Intel Corporation or its subsidiaries in the U.S. and/or other countries. Linux is the registered trademark of Linus Torvalds in the U.S. and other countries.
Page 129: Appendix B. Abbreviation Table
Electrically Erasable Programmable Read-Only Memory Extensible Firmware Interface Electrostatic discharge Field Replaceable Unit General Announce Variant Integrated circuits Liquid Crystal Display Machine type and model POST Power-on self-test RFID Radio-frequency identification Supervisor password UUID Universally unique identifier © Copyright Lenovo 2024...
Page 130 ThinkPad X13 Gen 5 and ThinkPad X13 2-in-1 Gen 5 Hardware Maintenance Manual...
Page 132 Part Number: SP41L93288 Printed in China (1P) P/N: SP41L93288 *1PSP41L93288*...

This manual is also suitable for:

Thinkpad x13 2-in-1 gen 5 Thinkpad x13 gen 5 cat41Thinkpad x13 2-in-1 gen 5 cat4121lu 21lv 21lw ... Show all

Lenovo 21LW001KIX Hardware Maintenance Manual

Quick Links

Need help?

Questions and answers

Related Manuals for Lenovo 21LW001KIX

Summary of Contents for Lenovo 21LW001KIX

This manual is also suitable for:

Table of Contents
